INSTALLATION INSTRUCTIONS
EX85
MEGAPIXEL-IP INFRARED IMAGER™
MAN – 85 – 02
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep this instruction.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with manufacturer instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong is provided for your safety. If
the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the power where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in a way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
IMPORTANT
For best results, please read this Instruction Booklet prior
to installing the EX85 Megapixel-IP Infrared Imager™
WARNING!
CSA Certified / UL Listed CLASS 2 power adaptors must
be used in order to comply with electrical safety
standards.
This installation should be made by a qualified service
person and conform to all local safety codes.
Bosch Security Systems Inc. will not be responsible for
injuries or damages resulting from the improper
installation or use of any equipment sold by Bosch
Security Systems Inc., their agents, distributors or
dealers.
NOTE: This equipment has been tested and found to
comply with the limits for a digital device, pursuant to part
15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. As part of it's normal operation this
device can generate radio frequency energy and if not
installed and used in accordance with the installation
manual may cause interference to radio communications.
However, there is no guarantee that interference will not
occur on a particular installation. If the device does cause
interference to radio or television reception the user is
encouraged to try to correct the interference by one or
more of the following measures:
1) Fit Ferrite beads on all cable to and from the power
supply box, within the box walls.
2) Route the composite cable between the camera and the
power supply in steel conduit piping over the entire run of
the cable up to and including connection to a deep conduit
base fitted under the camera and a conduit fitting adaptor in
the wall of the PSU box.
3) Contact BOSCH Service Center for further advice.
INDEX – EX85 Megapixel-IP Infrared Imager™
DESCRIPTION...........................................................................1
UNPACKING..............................................................................2
PARTS LIST...............................................................................2
ITEMS REQUIRED FOR INSTALLATION.................................2
NETWORK SYSTEM REQUIREMENTS...................................3
INITIAL PREPARATIONS..........................................................4
GUIDELINES .............................................................................4
1. MOUNTING BRACKET PREPARATON ...................5
2. CABLE / BRACKET INSERTION...............................6
3. MOUNTING BRACKET ATTACHMENT....................7
4. CAMERA MOUNTING ..............................................8
5. CAMERA LENS ADJUSTMENTS............................11
6. LED ARRAY - POWER ADJUSTMENTS................14
7. VIEWING SOFTWARE SET-UP..............................15
8. APPLICATION MANAGER PROGRAM ..................17
9. CAMERA INSTALLER.............................................18
10. VIDEO SYSTEM......................................................21
11. SETTINGS...............................................................25
12. IMPORTANT CAMERA SETTINGS ........................39
13. CAMERA RE-ASSEMBLY.......................................40
14. TROUBLESHOOTING GUIDE - CAMERA..............41
15. TROUBLESHOOTING GUIDE – LEDs....................43
16. MOUNTING HOLES – DIAGRAM ...........................44
17. GENERAL SPECIFICATIONS.................................45
- 1 -
DESCRIPTION
The EX85 is the pinnacle of today’s most advanced
imaging technologies, combining megapixel sensors,
Black Diamond™ night vision technology and IP
connectivity.
The result is the most advanced level of imaging
performance for today’s critical security applications.
Crystal clear megapixel color by day delivers images with
amazing details. 420ft (130m) of award-winning Black
Diamond™ megapixel monochrome provides the
industry’s best IP night vision.
The EX85 incorporates the ruggedized enclosure, field-
proven for reliability in the worst outdoor environments.
- 2 -
UNPACKING
Care should be taken when unpacking the shipped unit.
Check the parts list and confirm all items have been
located. Inspect the equipment thoroughly to ensure
nothing was damaged in transit.
Contact BOSCH Service Center if a problem is noted,
see the rear page of this booklet for contact numbers.
PARTS LIST (items supplied with unit)
-EX85 Camera Assembly
-Installation Instructions booklet
-Allen Key
-EXMB028B or EXMB028W cable management
mounting bracket.
-EX85 Set-Up Software CD
ITEMS REQUIRED FOR INSTALLATION
(not supplied with units)
•Mounting hardware
•Mounting tools
•Computer with RJ45 Ethernet port
•Network switcher (standard or POE type)
•CAT5 Ethernet cable
- 3 -
NETWORK SYSTEM REQUIREMENTS
A dedicated PC is recommended for receiving image
streams from cameras and for archiving and display.
Minimum recommended requirements for the PC are as
follows:
•CPU: Core 2 Duo 2Ghz
•RAM: 1GB
•Video Card: NVIDIA, 128MB RAM
•Network Card: 100 base-T (one card required for
camera stream, a second card required for
remote viewing)
A 100Mbps or better network switch or router is required
to connect the camera to the network. A regular hub does
not provide collision management and is not suitable for
multi-camera systems. Category 5 cabling or better is
recommended, and must be installed according to all
applicable codes and regulations.
The camera is capable of accepting a standard network
connection. However, the camera unit will still require a
dedicated 12-24V power input.
The cameras can be accessed and controlled by two main
methods: through the included viewing software and
through HTTP commands from a web browser, such as
Internet Explorer.
- 4 -
INITIAL PREPARATIONS
•Determine the operating voltage at the
installation site. The camera‘s Voltage Regulator
Board accepts 12-24V AC/DC input without
change to internal connections.
•Determine the optimum mounting location for the
camera. See Section 4, Camera Mounting.
•All cameras have been tested and pre-focused
with telephoto setting as factory default prior to
shipment. If any adjustment needed, it is
advisable to check the camera’s operation before
installation.
GUIDELINES
The installation of the EX85 is shown in Sections 1 to 13.
It is important that these steps are followed in numerical
order.
It is also important to follow proper safety guidelines when
installing this product.
