Date: November 1, 2005

Ref: AR18-05-B010

Version 1.4

DVR1A & DVR1C Compatible Multiplexer brands

General

On the DVR1A and DVR1C you can connect only one camera or multiple cameras via a multiplexer.

These recorders are compatible with a number of multiplexers. To use all features of the DVR1A & C

in combination with a multiplexer the specified protocol of this multiplexer must be programmed in the

units. This protocol (for detection of the camera number) is required to view images via the web

software (DVR1C only) and to make movie files on the compact flash card.

For all the other DVR1A & C features the multiplexer protocol is not required.

Multiplexer table

The following table lists multiplexer brands that are tested and been found to be compatible with the

DVR1A and DVR1C digital video recorders:

Manufacturer Model System DVR1A (V1.10A) DVR1C (V1.10C)

Bosch/Philips LTC2600 range PAL Listed Listed

Bosch Eazeo VSS8394/xxT PAL Listed No (use DVR1B)

Kalatel CBR-16CDTx PAL Listed Listed

DM SLDX16C PAL PAL Listed Listed

ATV DPX16m & DPX9m PAL Custom Custom

Bosch/Philips LTC2600 range NTSC Listed Listed

Bosch Eazeo VS8394/xxT NTSC Listed No (use DVR1B)

Kalatel CBR-16CDT NTSC Listed Custom

DM SLDX16C NTSC NTSC Listed Custom

Robot MV99P NTSC Listed Listed

Pelco MX4016CD NTSC Custom Custom

Sanyo MPX-CD162 NTSC Custom Custom

ATV DPX16m & DPX9m NTSC Custom Custom

Panasonic WJ-FS616 NTSC Custom Custom

Bosch/Philips LTC 2622/90 (V 4.02) NTSC Custom Custom

Listed: Multiplexer model is listed in the “multiplexer menu” of the connected DVR1

Custom: Custom code is available and must be entered in the “Custom menu” of the connected DVR1

Known custom multiplexer parameters

NTSC PAL

Kalatel 128 021 128 022

CBR 16CD 000 017 000 018

128 014 128 015

000 010 128 011

000 000 000 000

000 007 000 007

000 000 000 000

Field code line 12 11

Date: November 1, 2005

Ref: AR18-05-B010

Version 1.4

NTSC PAL

DM 128 030 128 030

SLDX16C 128 060 128 060

128 090 128 090

000 120 128 120

000 000 000 000

000 140 000 140

000 010 000 010

000 000 000 000

Field code line 15 20

NTSC PAL

Robot 128 130 128 130

MV99P 000 142 000 142

128 154 128 154

000 166 128 166

000 000 000 000

000 014 000 014

000 000 000 000

Field code line 13 ??

NTSC PAL

Pelco 128 141 128 141

MX4016CD 000 152 000 152

128 163 128 163

000 174 128 174

000 002 000 002

000 007 000 007

000 000 000 000

Field code line 20 ??

NTSC PAL

Sanyo 128 074 128 074

MPX-CD162 000 088 000 088

128 102 128 102

000 116 128 116

000 006 000 006

000 007 000 007

000 000 000 000

Field code line 14 ??

Date: November 1, 2005

Ref: AR18-05-B010

Version 1.4

NTSC PAL

ATV 128 112 128 112

DPX16m & 000 115 000 115

DPX9m 128 119 128 119

000 122 000 122

000 000 000 000

000 033 000 033

000 000 000 000

Field code line 15 15

NTSC

PANASONIC 006 136

WJ-FS616 007 036

007 086

007 136

006 136

007 036

007 086

007 136

Field code line 15

NTSC

Bosch/Philips multiplexer 006 100

LTC 2622/90 (V 4.02) 005 100

004 100

003 100

006 100

005 100

004 100

003 100

Field code line 11

Note: Only the Bold codes are tested with release V1.00 of the DVR1C and DVR1A. All other codes

are NOT tested and therefore we can not guarantee that this will work.

MULTIPLEXER NOT LISTED

If your multiplexer is not listed and no (correct) custom code is available please consult your sales

representative.
