Tumble dryer

WQG233D0NL

User manual and

installation instructions

Translated from Dutch to English - www.onlinedoctranslator.com

Refer to the Digital User Guide for more

information.

Table of contents

1 Safety................................... 4

1.1 General instructions ............. 4

9 Programs ................................ 26

9.1 Automatic programs ..... 26

9.2 Time programs.................................. 271.2 Destination of the device

comb ............................................. 4

1.3 Restriction of users ...... 4

1.4 Safe installation...................... 5

1.5 Safer use ................................ 7

10 Accessories.............................. 29

11 Laundry................................... 30

11.1 Preparing laundry.......... 30

1.6 Safe cleaning and

maintenance ............................................ 10 12 The Ministry in essence......... 30

12.1 Switching on the device ............ 30

12.2 Set program .............. 30

2 Avoiding material damage ...... 11

3 Environmental protection and saving

ring................................................ 11

12.3 Filling the drum with

laundry ............................................ 30

3.1 Disposal of the packaging .... 11

3.2 Saving energy.................. 11

3.3 Energy saving mode ........ 12

12.4 Starting the program ... 31

12.5 Loading laundry ................ 31

12.6 Program cancel................... 31

12.7 Taking out laundry ................ 31

12.8 Switching off the device .......... 31

12.9 Fluff filter ............................. 31

4 Setup and connection ............. 12

4.1 Unpacking the device .................. 12

4.2 Scope of delivery .................... 12 12.10 Filter system of the bottom

unit ................................ 33

4.3 Requirements regarding the installation

location ................................ 13 12.11 Condensation water tank ........ 34

4.4 Water drain hose................... 14

4.5 Adjusting the device .......... 16 13 Child lock ................................ 35

13.1 Activating the child lock ............... 35

13.2 Deactivating child lock............ 35

4.6 Connecting the device

electrically................................................. 16

5 Getting to know your device......... 17

5.1 Device .................................... 17

5.2 Control panel.................. 18

14 Basic settings .................... 35

15 Cleaning and maintenance .......... 36

15.1 Tips for cleaning and

maintenance................................... 36

6 Display ....................................... 19

7 Buttons .................................... 22 15.2 Bottom unit ....................... 36

15.3 Humidity sensor ................ 39

8 Drying purpose .................................... 25

8.1 Changing drying target................... 25

8.2 Adjusting the drying target............. 25

16 Troubleshooting ................ 40

17 Transport, storage and

disposal................................... 45

17.1 Preparing the device for

transport ................................ 45

17.2 Disposal of your old

device ............................................ 45

18 Service................................... 46

18.1 Product number (E no.) and

production number (FD) ........... 46

19 Consumption values .................... 47

20 Technical data............. 48

NLSafety

1 Safety

Please observe the following safety precautions.

1.1 General instructions

¡Read these instructions for use carefully.

¡Keep the instructions for use and product information for later

for use or for subsequent owners.

¡Do not connect the device in case of transport damage.

1.2 Destination of the device

Only use the device:

¡for dryer-suitable and water-washed textiles

to dry and freshen up.

¡for domestic use and in closed areas within the home

normal environment.

¡up to an altitude of 4000 m above sea level.

1.3 Restriction of Users

This appliance can be operated by children aged from 8 years and above

and persons with reduced physical, sensory or mental capabilities or lack

of experience and/or knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way and have

understood the resulting hazards. understood. Children are not allowed

to play with the device.

Cleaning and user maintenance shall not be carried out by children

unless they are supervised.

Make sure that children under 3 years of age and pets cannot reach

the device.

SafetyNL

1.4 Safe installation

Observe the safety regulations when installing the device.

WARNING ‒ Risk of electric shock! Improper

installations are dangerous.

▶Only connect and use the device according to the information on

the rating plate.

▶Only connect the device to an alternating current mains via a

properly installed earthed socket.

▶The protective earth system of the electrical domestic installation

must be installed in accordance with the electrical regulations.

The installation must have a sufficiently large core diameter.

▶When using an earth leakage circuit breaker, only use a type

with the sign.

▶Never power the device via an external switching device, for

example a timer switch or remote control.

▶Never connect the appliance to a circuit that is regularly switched

on and off by the utility company.

▶If the device is built-in, the mains plug of the mains connection

cable must be freely accessible, or if free access is not possible,

an all-pole disconnection device must be installed in the

permanently installed electrical installation in accordance with

the installation instructions.

▶When setting up the device, ensure that the power cord is not

pinched or damaged.

Damaged insulation of the power cord is dangerous.

▶Never bring the power cable into contact with hot appliance

parts or heat sources.

▶Never bring the power cord into contact with sharp points or

edges.

▶Never kink, pinch or alter the power cord.

NLSafety

WARNING ‒ Risk of fire!

Using an extended power cord and unauthorized adapters is

dangerous.

▶Do not use extension cords or multiple sockets.

▶If the power cord is too short, contact customer service.

▶Use only adapters approved by the manufacturer.

WARNING ‒ Risk of injury!

The high weight of the device can cause injuries when lifting.

▶Do not lift the device alone.

If this appliance is installed incorrectly in a washer-dryer column,

the installed appliance could fall down.

▶Only stack the dryer on a washing machine with the dryer

manufacturer's connection set

→

"Accessories", page 29

Any other installation method is not

permitted.

▶Do not install the appliance in a washer-dryer column if the dryer

manufacturer does not offer a suitable connection set.

▶Do not install appliances from different manufacturers and with

different depths and widths in a washer-dryer column.

▶Do not place a washer-dryer column on a platform, as the

appliances may tip over.

WARNING ‒ Risk of suffocation!

Children can pull packaging material over their heads and become

entangled and suffocate.

▶Keep packaging materials away from children.

▶Do not allow children to play with packaging materials.

CAUTION ‒ Risk of injury!

The device may vibrate or move during operation.

▶Set up the device on a clean, flat and sturdy surface.

SafetyNL

▶Level the device using the device feet and a spirit level.

There is a risk of tripping if hoses and mains connection cables are

not properly laid.

▶Lay the hoses and connecting cables in such a way that people

cannot trip over them.

If the appliance is moved by protruding parts, such as the loading

door, the parts may break off.

▶Do not move the device by protruding parts.

CAUTION ‒ Risk of cutting!

Sharp edges on the device can cause cuts if touched.

▶Do not touch the device on sharp edges.

▶Use safety gloves when installing and transporting the device.

1.5 Safer use

WARNING ‒ Risk of electric shock!

A damaged device or power cord is dangerous.

▶Never use a damaged device.

▶Never pull on the power cord to disconnect the device from the

mains. Always pull the plug on the power cord.

▶If the device or the power cord is damaged, immediately unplug

the power cord from the socket or switch off the fuse in the

meter cupboard.

▶Contact the service department. →

Page 46

Penetrating

moisture can cause an electric shock.

▶Only use the device in closed rooms.

▶Never expose the device to excessive heat and humidity.

▶Do not use a steam cleaner, high-pressure cleaner, hoses or

nozzles to clean the device.

NLSafety

WARNING ‒ Risk of health hazard! Children could become

trapped in the device and endanger their lives.

▶Do not place the appliance behind a door that blocks or prevents

the appliance door from opening.

▶In the case of discarded appliances, unplug the power cord from

the socket, then cut the power cord and damage the lock of the

appliance door in such a way that the appliance door no longer

closes.

WARNING ‒ Risk of suffocation!

Children can inhale or swallow small parts and choke.

▶Keep small parts away from children.

▶Do not allow children to play with small parts.

WARNING ‒ Risk of explosion!

Coal dust or flour in the vicinity of the appliance can lead to

explosions.

▶Keep the area around the device clean during use.

WARNING ‒ Risk of poisoning!

The condensation water from this device is not drinking water and may be

contaminated with fluff.

▶Do not drink or use the condensation water from the device.

Washing and care products can lead to poisoning if ingested.

▶If accidentally swallowed, consult a doctor.

▶Keep washing and care products out of the reach of children.

SafetyNL

WARNING ‒ Risk of fire!

The refrigerant R290 in this device is environmentally friendly but

flammable and can ignite upon contact with open flames or ignition

sources.

▶Open flames and other ignition sources away from it

keep the device.

WARNING ‒ Risk of explosion!

Residues in the fluff filter can ignite during drying.

▶Clean the fluff filter regularly.

Highly flammable objects, such as lighters or matches, can ignite

during drying.

▶Remove all highly flammable objects from the laundry pockets

before drying.

If unwashed laundry comes into contact with solvents, oil, wax,

wax remover, paint, grease or stain remover, it can ignite during

drying.

▶Do not dry unwashed laundry in this appliance.

▶Rinse the laundry thoroughly with hot water and detergent

before drying.

▶Do not use the appliance if the laundry is previously cleaned

with industrial chemicals.

WARNING ‒ Risk of fire!

If drying is stopped prematurely, the laundry has not been cooled

sufficiently and could catch fire.

▶Do not cancel the drying program prematurely.

▶If drying is stopped prematurely, immediately remove and

spread out the laundry.

CAUTION ‒ Risk of injury!

The cover plate may break when climbing or clambering onto the

device.

▶Do not climb or clamber onto the device.

NLSafety

The appliance may tip over when sitting or leaning on the open

door.

▶Do not sit or lean on the appliance door.

▶Do not place objects on the appliance door.

Reaching into the rotating drum can cause injury to the hands.

▶Wait until the drum has come to a complete stop before reaching into the

drum with your hand.

1.6 Safe cleaning and maintenance

Observe the safety regulations when cleaning and maintaining the

device.

WARNING ‒ Risk of electric shock! Improper

repairs are dangerous.

▶Only trained specialist personnel may carry out repairs on the

device.

▶Only original spare parts may be used to repair the device.

▶If the power cord of this appliance becomes damaged, it must

be replaced by the manufacturer, its service agent or a similarly

qualified person to avoid hazards. Penetrating moisture can

cause a shock.

▶Do not use a steam cleaner, high-pressure cleaner, hoses or

nozzles to clean the device.

WARNING ‒ Risk of injury!

Using non-original spare parts and non-original accessories is

dangerous.

▶Use only original spare parts and original accessories from the

manufacturer.

WARNING ‒ Risk of poisoning!

Toxic fumes can be produced when using solvent-based cleaning

agents.

▶Do not use cleaning agents containing solvents.

Table des matières

Autres manuels Bosch Séchoir

Bosch

Bosch WTW86561GB Installation Instructions, Instructions for Use, Programme... Manuel utilisateur

Bosch

Bosch WQG2450XES Manuel utilisateur

Bosch

Bosch WTG86400KE Manuel utilisateur

Bosch

Bosch WTY87879SN Manuel utilisateur

Bosch

Bosch WTB8620SZA Manuel utilisateur

Bosch

Bosch WTL 6507 Fiche technique

Bosch

Bosch WTB76550EU Guide rapide

Bosch

Bosch DV52J8700E Series Manuel utilisateur

Bosch

Bosch WTW87F90CH Manuel utilisateur

Bosch

Bosch Programme Table Manuel utilisateur

Bosch

Bosch WTM8327SZA Manuel utilisateur

Bosch

Bosch WTR85V90ES Manuel utilisateur

Bosch

Bosch Axxis WTA 4410 CN Manuel utilisateur

Bosch

Bosch WTW85491GB Manuel utilisateur

Bosch

Bosch WTW8549PSN Manuel utilisateur

Bosch

Bosch Vision 300 Series DLX WTVC4500 Manuel utilisateur

Bosch

Bosch WTN832L7SN Manuel utilisateur

Bosch

Bosch WTC82100US/02 Guide produit

Bosch

Bosch Nexxt 500 Series Guide d'installation

Bosch

Bosch WTG865H2UC/01 Manuel utilisateur

Bosch

Bosch WTC84101BY Manuel utilisateur

Bosch

Bosch WQG245R9GB Instructions d'utilisation et d'entretien

Bosch

Bosch WTY88809ES Manuel utilisateur

Bosch

Bosch WTU87RH1ES Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Electrolux

Electrolux EW2H328R2 Manuel utilisateur

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

Electrolux

Electrolux TP5080TW Manuel utilisateur

AEG

AEG TR838P4OB Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur

Frigidaire

Frigidaire CAQE7077KW0 Manuel du propriétaire

Sharp

Sharp KD-NHH9S7GW2-PL Manuel utilisateur
