PXI‑CORE Edge controller

en User manual

PXI-CORE Edge controller Table of contents | en 3

Bosch Security Systems B.V. User manual 2023-03 | V01 | F01U395004

Table of contents

1Important product information 5

1.1 Disposal instructions 5

1.2 FCC Statement - Wired Class A digital device (unintentional radiator) 5

1.3 CE Class A Statement 5

1.4 FCC suppliers declaration of conformity 5

1.5 KCC Statement 6

2About this manual 7

2.1 Intended audience and use 7

2.2 Copyright notice 7

2.3 Trademarks 7

2.4 Notice of liability 7

3About the PXI-CORE 8

3.1 Introduction 8

3.2 Quick start 8

4Detailed installation procedures and instructions 10

4.1 Mechanical installation 10

4.1.1 Parts included 10

4.1.2 Mounting 10

4.2 Electrical installation 13

4.2.1 Ethernet ports 14

4.2.2 Power supply XD10 14

4.2.3 SD card slot CF01 16

4.2.4 Battery case GB01 17

5Web-based graphical user interface 17

5.1 User 17

5.1.1 Change the password 17

5.1.2 Logging out 17

5.2 Settings 17

5.2.1 Connectivity 17

5.2.2 Date & Time 18

5.2.3 Users & Permissions 18

5.2.4 Certificates & Keys 18

5.2.5 SSH 18

5.2.6 Proxy 18

5.2.7 Shutdown 18

5.2.8 Licenses 18

5.2.9 Information 18

5.2.10 Storage 18

5.3 Diagnostics 19

5.4 About 19

5.4.1 Open Source Components 19

5.5 Not used functions 19

6Troubleshooting 21

6.1 Connection problems 21

6.2 App installation problems 22

7Maintenance 23

7.1 Preventive maintenance 23

7.2 Corrective maintenance 23

4en | Table of contents PXI-CORE Edge controller

2023-03 | V01 | F01U395004 User manual Bosch Security Systems B.V.

7.3 Battery change 24

8Technical data 25

PXI-CORE Edge controller Important product information | en 5

Bosch Security Systems B.V. User manual 2023-03 | V01 | F01U395004

1 Important product information

Warning!

Operation of this equipment in a residential environment could cause radio interference.

1.1 Disposal instructions

Old electrical and electronic appliances.

Electrical or electronic devices that are no longer serviceable must be collected

separately and sent for environmentally compatible recycling (in accordance with the

European Waste Electrical and Electronic Equipment Directive).

To dispose of old electrical or electronic devices, you should use the return and

collection systems put in place in the country concerned.

1.2 FCC Statement - Wired Class A digital device (unintentional

radiator)

Changes or modifications not expressly approved by the party responsible for compliance

could void the user's authority to operate the equipment.

Note: This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is

likely to cause harmful interference in which case the user will be required to correct the

interference at his own expense.

1.3 CE Class A Statement

Warning!

The operation of this equipment in a residential environment could cause radio interference

1.4 FCC suppliers declaration of conformity

Product(s):

Material Commercial code Material description

F.01U.395.004 PXI-CORE Edge controller

Compliance statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful interference, and

2. this device must accept any interference received, including interference that may cause

undesired operation.

6en | Important product information PXI-CORE Edge controller

2023-03 | V01 | F01U395004 User manual Bosch Security Systems B.V.

Responsible party

Bosch Security Systems LLC

130 Perinton Parkway

14450 Fairport, NY, USA

www.boschsecurity.us

1.5 KCC Statement

기자재명 : PXI-CORE Edge controller

모델명 : PXI-CORE

수입업체(상호)명 : 로버트보쉬코리아유한회사

제조국 : 독일 (Germany)

제조일자 : 별도표기

R-R-RB9-PXICORE 제조자 : Bosch Security Systems B.V.

PXI-CORE Edge controller About this manual | en 7

Bosch Security Systems B.V. User manual 2023-03 | V01 | F01U395004

2 About this manual

The purpose of this user manual is to provide the required information needed for the

installation (hardware and software) and access to the web-based Graphical User Interface of

the Bosch PXI‑CORE edge controller.

This manual, or an update, in pdf format is available as download from

www.boschsecurity.com.

2.1 Intended audience and use

This manual is intended for everyone who is authorized to install and configure the PXI‑CORE

edge controller and related products.

Intended use of the equipment

– The device may only be operated under the mounting and installation conditions specified

in this document.

– The device may only use component configurations, software and firmware specified in

this document.

2.2 Copyright notice

Unless otherwise indicated, this publication is the copyright of Bosch Security Systems B.V. All

rights are reserved.

2.3 Trademarks

Throughout this document trademark names may have been used. Rather than put a

trademark symbol in every occurrence of a trademark name, Bosch Security Systems states

that the names are used only in an editorial fashion and to the benefit of the trademark owner

with no intention of infringement of the trademark.

2.4 Notice of liability

While every effort has been taken to ensure the accuracy of this document, neither Bosch

Security Systems nor any of its official representatives shall have any liability to any person or

entity with respect to any liability, loss or damage caused or alleged to be caused directly or

indirectly by the information contained in this document.

Bosch Security Systems reserves the right to make changes to features and specifications at

any time without prior notification in the interest of ongoing product development and

improvement.

8en | About the PXI-CORE PXI-CORE Edge controller

2023-03 | V01 | F01U395004 User manual Bosch Security Systems B.V.

3 About the PXI-CORE

3.1 Introduction

The PXI-CORE Edge controller is the HW base unit for smart integration. It consists of a

compact DIN-rail mountable hardware unit, Linux operating system and firmware. Smart

integration stands for integration between Bosch Building Technology systems and devices.

Next to this HW base unit the dedicated Intelligent control SW App for the PXI-CORE Edge

controller is required which is sold separately. Information of the Intelligent control App will

reveal the features and supported systems and devices.

This smart integration solution connects to IP based systems and devices utilizing the

available IP interface. The Intelligent control App is running on the PXI-CORE Edge controller.

Installation, updates and configuration of this App can be done remotely from any location via

the web-GUI. The PXI-CORE Edge controller is equipped with a Trusted Platform Module

(TPM) 2.0, has a full secure boot support, secured HTTPS web interface connection and

supporting CA signed certificates for authentication. All to ensure a high level of cyber

security.

3.2 Quick start

This quick start section of the manual describes the required steps to make the PXI‑CORE, and

installed application(s), up and running fast. For detailed instructions, refer to

Detailed

installation procedures and instructions, page 10

Quick start procedure:

1. Connect the PXI‑CORE to the:

– Ethernet network (D) ( XF51). Connect your configuration device (PC, laptop, tablet)

to the same network that the PXI-CORE is connected to.

– External 24V power supply (F) (XD10).

2. Power on the PXI-CORE via the connected power supply.

3. Check the device LED bar (H):

– red: power-up.

– blinking blue: starting up.

– green: ready to use.

4. Open your web browser and enter the IPv6 address (see product label):

– Example IPv6 address: https://[fe80::2680:34ff:fe84:62e0]. Be sure to type the

correct address (e.g. double colon after https://[fe80).

– Accept the risk for the self-signed certificate.

PXI-CORE Edge controller About the PXI-CORE | en 9

Bosch Security Systems B.V. User manual 2023-03 | V01 | F01U395004

– If this method fails, please refer to

Troubleshooting, page 21

5. Logon to the PXI‑CORE:

– Enter user name and password. Both: bosch (factory default)

6. Get or set an IPv4 address:

– Go to Settings > Connectivity > (XF51) eth1. Check if you have an IPv4 address

assigned from a DHCP server. If not, manually assign an IPv4 address clicking in the

plus (+) sign in IP addresses. Note that an IPv4 address is required to allow

communication to other BT products (Praesensa, Praesideo, B/G Series control

panels, ONVIF cameras).

7. Install your application(s):

– 1) Go to and click Settings > Apps.

– 2) Set the PXI-CORE edge controller in Service Mode by clicking the blue Operation

mode/Service mode button.

– 3) When the LED (H) color changes from green to blinking blue, click the Install from

file button.

– 4) Browse to the application files and click the Install button to finalize the

installation process. You can select multiple files at once.

– 5) Set the PXI-CORE back in Operation Mode by clicking the blue Operation mode/

Service mode button.

– 6) The LED bar (H) color changes from blinking blue to green.

10 en | Detailed installation procedures and instructions PXI-CORE Edge controller

2023-03 | V01 | F01U395004 User manual Bosch Security Systems B.V.

4 Detailed installation procedures and instructions

This section provides mounting instructions and installation instructions. It provides

installation methods commonly encountered in commercial applications and all applicable

codes. Follow the mechanical installation and electrical installation steps in the order they are

set up in the next chapters.

Notice!

All work activities necessary for the installation, connection and commissioning are to be

carried out by electrically skilled persons only.

4.1 Mechanical installation

4.1.1 Parts included

Make sure that all parts are included and not damaged. If the packaging or any parts are

damaged, contact your shipper. If any parts are missing, contact your Sales or Customer

Service Representative.

The box contains the following parts:

Quantity Component

1 PXI‑CORE edge controller

1 24V power connector, RTB, 2‑pin (power supply not included)

Parts check and identification

A USB-C port

B Ethernet port XF10 (second network port for advanced

installations)

C Ethernet port XF50 (not used)

D Ethernet port XF51

E SD card slot (up to 32 GB). FAT32 formatted: can be

formatted via the GUI of the PXI-CORE

F 24V power connector, RTB, 2-pin

G Battery case

H LED bar

4.1.2 Mounting

Cabinet/terminal box mounting

The device has the degree of protection IP20 and is thus intended for the use in a closed

cabinet or terminal box of the degree of protection IP54 or higher. For environmental data,

including ambient temperatures, refer to

Technical data, page 25

Mounting on a mounting rail

Before mounting, be sure that the device is disconnected from voltage.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Bosch Contrôleurs

Bosch

Bosch Worcester Digital Twin Channel Programmer Manuel

Bosch

Bosch CLIMATE 5000 VRF RDCI Series Mode d’emploi

Bosch

Bosch Rexroth ctrl CORE Manuel utilisateur

Bosch

Bosch Lambdatronic LT4 ADV Manuel d'instructions

Bosch

Bosch MP 100 Manuel utilisateur

Bosch

Bosch 2600 Series Manuel utilisateur

Bosch

Bosch Twist Manuel utilisateur

Bosch

Bosch ME 200 Manuel utilisateur

Bosch

Bosch DSA-N2E8XG-12AT Manuel utilisateur

Bosch

Bosch Rexroth IndraMotion MTX micro Fiche d'information produit

Bosch

Bosch Rexroth IndraDrive MPH-02 Instructions d'utilisation et d'installation

Bosch

Bosch Rexroth lndraDrive HCS02.1E-W0012 03 Series Manuel utilisateur

Bosch

Bosch System Controller Manuel utilisateur

Bosch

Bosch AMC2 4W Manuel utilisateur

Bosch

Bosch MPC 2000 A Manuel utilisateur

Bosch

Bosch RC35 Guide rapide

Bosch

Bosch AMC2 Series Manuel utilisateur

Bosch

Bosch BMS-BAC Manuel utilisateur

Bosch

Bosch CS 550 Manuel utilisateur

Bosch

Bosch Rexroth lndraDrive HCS02 Series Manuel utilisateur

Bosch

Bosch Rexroth CKL Series Mode d’emploi

Bosch

Bosch Rexroth IndraDrive CsDrive System with HCS01 Manuel utilisateur

Bosch

Bosch WORCESTER Sense II Manuel utilisateur

Bosch

Bosch REXROTH IndraDrive Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
