Bosch FMR-7033 Manuel utilisateur

FMR-7033

Installation Instructions

Addressable Fire System

Controller

EN | 2FMR-7033 | Installation Instructions | Contents

2 Bosch Security Systems, Inc. | 9/08 | F01U010583-01

Contents

Contents ...........................................................................2

1.0 Introduction ......................................................3

2.0 Description........................................................3

3.0 Device Mounting .............................................3

3.1 Mounting the FMR-7033 to a Surface .............3

3.2 Mounting the FMR-7033 to an Electrical Box3

4.0 Wiring the FMR-7033 ......................................4

5.0 Powering the FMR-7033 .................................4

6.0 Installing the FMR-7033 Instruction Label

and Slide ............................................................5

7.0 Setting the FMR-7033’s Address ...................5

8.0 Programming the FMR-7033 ........................5

9.0 Troubleshooting the FMR-7033 ...................5

10.0 Specifications ....................................................6

11.0 Operating the FMR-7033................................7

Figures

Figure 1: Removing the FMR-7033 Cover...............3

Figure 2: Location of the FMR-7033 Base Mounting

Holes ............................................................4

Figure 3: Wiring the FMR-7033’s Terminal Strip....4

Figure 4: Installing the Instruction Label and Slide.5

Figure 5: FMR-7033 Keypad Addresses ...................5

Figure 6: Keypad Features..........................................7

Tables

Table 1: FMR-7033 Wiring Guidelines ...................4

Table 2: FMR-7033 Troubleshooting Tips..............6

Table 3: FMR-7033 Specifications............................6

FMR-7033 |Installation Instructions | 1.0 Introduction

Bosch Security Systems, Inc. | 9/08 | F01U010583-01 3

1.0 Introduction

These instructions cover the installation of the Bosch

Security Systems, Inc. (Bosch) FMR-7033 Addressable

Fire System Controller in a fire system supervised by a

Bosch FPD-7024 Fire Alarm Control Panel (FACP).

Follow these instructions to avoid personal

injury and/or damage to equipment.

Install, test, and maintain these devices

according to these instructions, NFPA 72,

Local Codes, and the Authority Having

Jurisdiction (AHJ). Failure to follow these

instructions might result in failure of the

device to initiate a proper response. Bosch

is not responsible for improperly installed,

tested or maintained devices.

2.0 Description

The FMR-7033 Addressable Fire System Controller is

a four-wire alphanumeric LCD keypad that combines

fire system annunciator and controller functions. It

operates identically to the built-in user interface on the

FACP. Up to four FMR-7033 controllers might be

connected to an FPD-7024.

The FMR-7033 can be surface mounted, mounted to a

single or double gang box or to a four-inch square box.

3.0 Device Mounting

The FMR-7033 should be mounted no higher than

shoulder height of the shortest person using the system.

Remove the keypad’s cover by inserting a small flat-

head screwdriver in each slot at the bottom of the base.

Press up and pull the cover off (Figure 1).

Figure 1: Removing the FMR-7033 Cover

(Bottom front view of FMR-7033)

1 - Keypad Keys

2 Insert small flat screwdriver in each slot to

remove FMR-7033 cover

3.1 Mounting the FMR-7033 to a Surface

1. Use the base as a template and mark the location

of the mounting holes (use any holes).

2. Provide an opening in the mounting surface for

the wiring.

3. Partially install the mounting screws.

Do not tighten the mounting screws.

3.2 Mounting the FMR-7033 to an

Electrical Box

Refer to Figure 2 on page 5 to select mounting holes.

Do not tighten the mounting screws.

FMR-7033 |Installation Instructions | 4.0 Wiring the FMR-7033

4 Bosch Security Systems, Inc. | 9/08 | F01U010583-01

Figure 2: Location of the FMR-7033 Base

Mounting Holes

Inside of FMR-7033 Keypad

DO NOT USE THIS PIN!!

Back of FMR-7033 Keypad

1- Address Pins

2- Terminal Strip

3- Double Gang Mounting Slots

4- Terminal Strip Opening

DO NOT USE AS A WIRE ENTRANCE.

5- Sounder Opening

6- Wire Entrance

7- Single Gang Mounting Slots

4.0 Wiring the FMR-7033

Ensure that power is removed from all

wiring before routing. Keypad wiring cannot

be shared with multiplex, option bus,

telephone or siren wiring.

Up to three keypads can be used on any

single 1,000 ft (305 m) run of #18 AWG

(1.2 mm) wire. Refer to the FACP’s

installation guide for more detailed

instructions.

Table 1: FMR-7033 Wiring Guidelines

Wiring Specifications Value

Wire Gauge #18 AWG (1.2 mm)

Wire Type Non-shielded; 4-wire

Maximum number of keypad

allowed per system

Distance allowed between FACP

and Keypad

2000 ft (610 m)

Maximum distance of keypad

wiring and bus

4000 ft (1219 m)

To wire the FMR-7033 Fire System Controller:

1. Route the wiring from the FACP to the keypads.

Refer to the FACP’s installation guide for details.

2. Bring the base wiring through the wire entrance

in the keypad’s base. Refer to Item 6 in Figure 2

for wire entrance location.

3. Connect the wiring to the FMR-7033’s terminal

strip. Refer to Figure 3.

4. Place the keypad onto the base.

5. While feeding the excess wiring out of the rear

of the base, press the cover straight in until it

latches.

Figure 3: Wiring the FMR-7033’s Terminal Strip

+12V

Com

Data In

Data Out

1 - FMR-7033 Terminal Strip

2 - FPD-7024 Option Bus

5.0 Powering the FMR-7033

The power supplied to the FMR-7033 from the R and

B terminals on the FACP is 12 VDC with a maximum

draw of 100 mA per FMR-7033 keypad. This power is

supplied from a 24 VDC battery when AC power fails.

FMR-7033 |Installation Instructions | 6.0 Installing the FMR-7033 Instruction Label and Slide

Bosch Security Systems, Inc. | 9/08 | F01U010583-01 5

For battery standby calculations, assume that the

FMR-7033 draws 75 mA from the 24 VDC battery.

The FPD-7024 FACP uses a switching power supply to

convert 24 VDC battery power to 12 VDC option bus

power. This conversion reduces the current drawn

from the battery.

6.0 Installing the FMR-7033

Instruction Label and Slide

An instruction label is provided for placement on the

pullout slide. The slide can be installed to pull from the

left or right (slide it into rear of base).

Use care when installing the label. Place it

as close to the pull-tab as possible.

Figure 4: Installing the Instruction Label and

Slide

Slide in either side

Back of FMR-7033 Keypad

Label

(writing on other side)

7.0 Setting the FMR-7033’s

Address

Each keypad must have its own address

set with its address pins. This address

must not conflict with the addresses of

other keypads or other option bus devices.

Each keypad address can support only one

device. All keypads must also be

programmed at the FACP.

Select the keypad address (1-15) by placing the

shorting jumpers over the address pins as shown in

Figure 5.

Figure 5: FMR-7033 Keypad Addresses

1248

Address 1

Address 4

Address 7

Address 10

Address 13

1248

Address 2

Address 5

Address 8

Address 11

Address 14

1248

Address 3

Address 6

Address 9

Address 12

Address 15

8.0 Programming the

FMR-7033

The control panel does not recognize the keypad until

the option bus is updated.

To update the option bus from the local keypad:

1. Enter programming mode using the correct

programming code.

2. Select menu item 3 – System.

3. Select menu item 4 – Option Bus

4. Select menu item 1 – Update Bus

5. Press */back to exit from programming mode.

Ensure that the number of devices found

on the bus agrees with the number

installed.

9.0 Troubleshooting the

FMR-7033

Refer to Table 2 on page 6 when troubleshooting

problems with the FMR-7033.

FMR-7033 |Installation Instructions | Specifications

6 Bosch Security Systems, Inc. | 9/08 | F01U010583-01

Table 2: FMR-7033 Troubleshooting Tips

FMR-7033 Keypad

Notification

Possible Causes

Continuous keypad sounder

plus “System Fault” display

- The yellow and green

ground wires are

disconnected.

- The keypad is not

programmed properly at

the FACP.

- The FACP

malfunctioned. Replace

the FACP.

FACP does not respond to

keypad input

- The keypad’s address

was not set.

Three-beep error tone at all

keypads

- Invalid key input.

10.0 Specifications

Table 3: FMR-7033 Specifications

Nominal Supply Voltage 12 VDC from Option Bus

Standby Current 100 mA (75 mA for battery

calculation)

Alarm Current 100 mA (75 mA for battery

calculation)

Environment Use Indoor/Dry

Operating Temperature +32°F to 120°F (0°C to

+49°C)

Relative Humidity 93%

Width 6.25 in (15.9 cm)

Height 4.6 in (11.7 cm)

Depth 1.3 in (2.9 cm)

Listings and Approvals UL864, FM

Wiring Supervised Communication

Circuit Class B, Style 4

FMR-7033 |Installation Instructions | 11.0 Operating the FMR-7033

Bosch Security Systems, Inc. | 9/08 | F01U010583-01 7

11. Use the [Test] key to select one of seven

special test modes (refer to FPD-7024 O&I

Guide; P/N F01U008458).

11.0 Operating the FMR-7033

12. Use the [Disable] key to disable or re-enable

inputs NACs or relays (outputs), and the

dialer.

Figure 6: Keypad Features

Alarm

Si lenc ed

Su pe r viso ry

Tr oub le

123

456

789

Program

Enter

Silence

Drill

Test

Disable

Reset

ACK

Back

History

TE ST WEEK LY

78910

13. Use the [Drill] key to activate the NACs

manually. It creates a history log entry and can

be optionally reported to the central station.

14. The [Reset] key (programmable from 1 to 16

sec) briefly turns off power to the detectors to

reset them and clears any off-normal

conditions.

15. Use the [Acknowledge] key to silence local

keypad sounders and to view off-normal

conditions.

16. The [Silence] key quiets the bell or sirens for

an alarm or trouble condition only if the system

is so configured.

1. The two-line character display can show all

messages normally displayed on an FPD-7024

or an FMR-7036 keypad.

2. The red Alarm LED lights whenever the system

registers an alarm and was not reset.

3. The yellow Silenced LED lights when the user

manually silences an alarm or trouble

condition. It turns off when the condition that

was silenced is corrected.

4. The yellow Supervisory LED lights whenever

the system registers a supervisory condition.

5. The yellow Trouble LED lights whenever the

system detects a problem with wiring or

internal circuitry. The Trouble LED flashes

while programming mode is active and

whenever inputs are not active, such as during

smoke power reset or alarm verification.

6. Scroll keys are used to move through the off-

normal events indicated on the display.

7. During the programming, use the [Back] key to

exit from menus or exit from the programming

mode entirely.

8. Use the [Programming] key to select the

programming mode.

9. Use the [History] key to view system events.

10. Use the [Enter] key to accept data when in the

programming mode.

F01U010583-01

Bosch Security Systems, Inc.

130 Perinton Parkway

Fairport, NY 14450-9199

(800) 289-0096

www.boschsecurity.com

Table des matières

Autres manuels Bosch Contrôleurs

Bosch

Bosch rexroth HMS01 Manuel utilisateur

Bosch

Bosch REGIN RC Multi Manuel utilisateur

Bosch

Bosch Rexroth IndraControl L40 Manuel technique

Bosch

Bosch Intuvia BUI255 Manuel utilisateur

Bosch

Bosch rexroth CS610 Manuel utilisateur

Bosch

Bosch Rexroth NYS04.2-ST-02-LMSN-NY4073 Manuel utilisateur

Bosch

Bosch EasyControl CT200B Manuel utilisateur

Bosch

Bosch MPC-C Series Manuel utilisateur

Bosch

Bosch WORCESTER Sense II Manuel utilisateur

Bosch

Bosch BMS-BAC Manuel utilisateur

Bosch

Bosch Rexroth VT-HNC100 3X/S Series Manuel utilisateur

Bosch

Bosch Access Modular Controller 2 Manuel utilisateur

Bosch

Bosch Rexroth IndraMotion MTX micro Fiche d'information produit

Bosch

Bosch BRC3100 Manuel utilisateur

Bosch

Bosch E2800 Manuel utilisateur

Bosch

Bosch Rexroth IndraDrive MPH-02 Instructions d'utilisation et d'installation

Bosch

Bosch ADS-AMC2-4R4CF Manuel utilisateur

Bosch

Bosch Rexroth SYHNC100-SEK 3 Series Manuel utilisateur

Bosch

Bosch DSA-N2E8XG-12AT Manuel utilisateur

Bosch

Bosch BRC3100 Manuel utilisateur

Bosch

Bosch Rexroth lndraDrive HCS02.1E-W0012 03 Series Manuel utilisateur

Bosch

Bosch Rexroth ctrlX SAFETY SAFEX-C.12 Manuel utilisateur

Bosch

Bosch KJR-120C1/BTF-E Mode d'emploi

Bosch

Bosch Rexroth OptiFeed-FS EcoDrive 03 FLP04VRS Instructions d'utilisation et d'installation

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
