UTR
-20-30-70 Tools for Dis/Assembly 2
Tool No. Tool Name Tool No. Tool Name Tool No. Name
1 J-011 2.5 mm Hex Key 6 J-035 Rubber Hammer 11 J-002 Flat Nose Plier
2 J-008 2.0 mm Rod 7 J-039 6mm Roc 12
3 J-032 Cross shape Plier 8 J-037 Special tools Air Inlet Body 13
4 J-033 5 mm Hex Inner Spanner 9 J-007 C- Shape Spanner 14
5 J-034 7 mm Hex Inner Spanner 10 J-049 Long Nose Plier 15
J-011 J-008 J-032 J-033 J-034
J-035 J-037 J-007
J-039 J-049
J-002
1
No Order No Description Price
A 50053 Hex Wrench $2.10
1 50004 Set Screws (2PK) U-Lap 30/70 $2.10
2 50005 3mm Tip Holder U-Lap 30/70 $10.00
3 50006 Front V=Cover U-Lap 30/70 $10.00
3-A 50007 O-Ring U-Lap 30/70-3A $1.00
4 & 4-B 50050 Fixed Ball & Bushing U-Lap 30/70 4-4B $18.65
5 50014 Sliding Bushing U-Lap 30/70 $7.15
5-A 50015 O-Ring U-Lap 30/70-5A $4.00
5-B 50016 Washer U-Lap 30/70-5B $1.00
6 50017 Front Body U-Lap 70 Only $48.00
6 50069 Front Body U-Lap 30 Only $48.00
6-A 50018 O-Ring U-Lap 30/70-6A $1.00
7 50019 Mainshaft U-Lap 30/70 $19.00
8 50021 Screw (4 PK) U-Lap 30/70 $8.72
9 50022 Bearing U-Lap 30/70-9 $11.75
10-B 50072 Plastic Crank Set* U-Lap 30/70 $18.00
11 50024 Bolt U-Lap 30/70 - 11 $6.50
12 50025 Front Turbine Cab U-Lap 30/70 $4.00
13 50026 Turbine U-Lap 70 Only $25.00
13 50051 Turbine U-Lap 30 Only $25.00
13-A 50027 Cooper Washer U-Lap 30/70 - 13A $1.25
14 50028 Bearing U-Lap - 70 -14 $16.25
15 50029 Bearing Fixer U-Lap 30/70 - 15 $15.50
16 50031 O-Ring U-Lap 30/70 - 16 $1.70
18 50035 Bearing U-Lap 30/70-18 $14.16
19 50036 Nut U-Lap 30/70-19 $1.70
19-A 50037 Nutu-Lap 30/70-19A $1.00
22-A 50038 O-Ring U-Lap 30/70-22A $1.00
22-B 50039 Air Inlet Body U-Lap 30/70 $16.25
23 50041 Rear Turbine Cab Set U-Lap 70-23 $35.00
S-1 50042 Switch Body U-Lap 30/70 $10.00
S-3 50044 O-Ring U-Lap 30/70-S3 $1.00
S-4 50045 O-Ring U-Lap 30/70-S4 $1.00
S-5 50043 C-Ring U-Lap 30/70-S5 $1.45
N-1 50046 On-Off Control U-Lap 30/70 $11.75
H-A 50000 Air Hose Set H-A $12.40
H-B 50002 Quick Joint U-Lap 30/70 H-B $2.90
H-C 50001 Mufer Pipe U-Lap 30/70 H-C $4.90
UTR 30-70 Repair Parts List
* Plastic Crank Set includes Plastic Crank (#10), Bearing (#18-1) & Washer (#17)
* Parts not sold separately.
