Boombotix REX Manuel utilisateur
USER GUIDE
Join the party on Instagram! Check out
swagonomics.boombotix.com to see
how other Boombot REX owners are
living with their ultraportable speakers
in the wild.
Share some of your own photos by
hastagging #boombotix, and take part
in the Boombot movement!
What’s Included
Accessories
Features
Controls
Bluetooth Pairing & Line-In
Soundhub & Daisy Chain
Battery & Assembly
Warranty
4
5
6
7
8
9
10
11
12
Table of Contents
4
Boombot REX speaker
Auxiliary audio cable
Micro USB charging cable
2 in. Boombotix vinyl sticker
What’s Included
5
Replacement Grillkits
Wall Charger Kit
Replacement Cable Sets
Bike Handlebar Mount
Accessories
6
Features
functions:
Line In Line Out
Micro USB
7
Controls
On/Off Switch (Located on top)
indicates ON position
indicates OFF position
Center Button
• Tap to play/pause current track
• Tap to answer/end phone call
• Double tap to advance track
• Hold to activate voice assistant (SIRI)
Playback Buttons (+/-)
• Tap or hold for volume control
• Tap either (+) or (-) to deny incoming call
8
Bluetooth Pairing
Line-In
To connect to Boombot REX via direct line-in,
connect the IN port of the Boombot REX to
your device. Line-In device state is indicated
by a solid green LED. To switch back into
Bluetooth mode, simply remove the auxiliary
cable from the rear of the device.
1) Boombot REX will be discoverable im-
mediately after power on, indicated by a
blinking blue LED.
2) Open your device’s Bluetooth settings
and choose Boombot REX on list of devices.
3) To pair, simply select the device. Pairing
will occur automatically.
4) When successfully paired, LED will be
solid blue.
9
To use the Boombot REX as a Bluetooth
reciever, connect any other speaker to the
OUT port of the device with the auxiliary
cable. The Boombot REX will replicate the
stereo signal through the attached speaker.
Music playback out of the Boombot REX will
continue while in Soundhub mode.
To link multiple Boombot REX speakers in se-
ries, rst pair (either via Bluetooth or Line-In)
to your Boombot REX, which will serve as the
master speaker in the series. Any Boombot
REX speakers added to the sequence (by
connecting the OUT port of a connected
speaker in the series to the IN port of the
additional speaker) will replicate the signal
of the master speaker. Repeat as needed.
Soundhub
Daisy Chain
Battery
10
1. Use the included Micro USB cable to link
Boombot REX to your personal computer or
USB outlet. A full charge will take 2 hours.
2. When fully charged, LED will appear solid
green. Battery life is appoximately 6 hours.
3. LED will blink red at <10% capacity.
4. On iOS devices, Boombot REX battery me-
ter will be apparent in top menu bar.
To remove the grill of the Boombot REX, twist
15º counterclockwise. To replace grill, place
new grill slightly counterclockwise to speaker,
ush with device, and twist 15º clockwise.
Assembly
