Boneco F225 Manuel utilisateur

F225–F235

MANUAL

READ AND SAVE THESE INSTRUCTIONS

LIRE ET SAUVEGARDER CES INSTRUCTIONS

LEA Y GUARDE ESTAS INSTRUCCIONES

Instructions for use 3

Mode d’emploi 19

Instrucciones de uso 35

INSTRUCTIONS FOR USE

BONECO F225–F235

en TABLE OF CONTENTS

Technical data 5

Introduction 6

Items included 6

Overview and part names 7

Start-up 8

Handling 9

Alignment 9

Height adjustment 9

Timer function 10

Use 10

Setting the OFF timer 10

Setting the ON timer 10

These are the benefits of the BONECO app 11

About the BONECO app 11

Scope of services 11

Bluetooth and factory settings 12

Switching off Bluetooth 12

Factory settings 12

Source of the BONECO app 13

BONECO app for iOS 13

App for Android 13

Connecting the app to the BONECO F225–F235 14

Preparing for first use 14

Connection 14

Positioning tips 15

Notes on output 15

Air-conditioning System (AC) 15

Fresh air 15

Multiple floors 15

Rooms with high ceilings 15

Cleaning 16

Safety instructions 16

Cleaning the housing 16

Cleaning the fan blades 16

Disassembly and storage 17

Technical data*

Model BONECO F225–BONECO F235

Power supply voltage 24V DC

Power consumption 22 W

Operation noise level 34 – 64 dB(A)

Air flow 847 CFM (1439 m3/h) (maximum level)

Air-speed 14.8 ft./s (4.5 m/s) (maximum level)

Dimensions L×W×H BONECO F225 14.8 ×14.8 ×33.5 in (375×375× 852 mm) (with one connector piece)

BONECO F235 14.8× 14.8× 47.7 in (375 × 375 × 1212 mm) (with two connector pieces)

Weight (empty) BONECO F225 13.2 lbs (6.0 kg)

BONECO F235 16.8 lbs (7.6 kg)

TECHNICAL DATA

* Subject to change

ITEMS INCLUDED

BONECO fan unit Removable connector piece

(F225: 1×/ F235: 2×)

Base

Manual Safety instructions

DEAR CUSTOMER,

Congratulations on your purchase of the BONECO Air

Shower Fan. These high-performance units seamlessly

adapt to your needs. When set to the lower output levels,

they provide a pleasant breeze in your home on hot days.

On the other hand, if you use an air-conditioning system,

the unit's powerful fan distributes the air throughout the

room ensuring a uniform temperature.

In developing the BONECO Air Shower Fan, low mainte-

nance and durability were of primary importance. The fan

blade's one-of-a-kind shape creates a uniform air flow

using minimal energy, which is also good for the environ-

ment. The elegant design harmonizes with any decorative

style so that you can use your BONECO Air Shower Fan

throughout the entire year.

We hope you enjoy your new BONECO Air Shower Fan!

INTRODUCTION

BONECO F225 and BONECO F235 are only different

in that the BONECO F235 includes a second connec-

tor piece.

You can use the fan unit with one, with a second or

without connector pieces. It can be customized to

your needs.

Power supply

3 3

OVERVIEW AND PART NAMES

1ON–OFF / Output regulator

2Fan head

3Button for unlocking

4Split supportive pole

5Foot stand with power cord

6Display

BONECO F225

Air Shower Ventilator

BONECO F235

Air Shower Ventilator

START-UP

Only place the base on a stable, level surface. Insert the connector piece into the base. Set the fan unit onto the connector piece.

Plug the power cord into a power outlet. Adjust the output using the control or the

BONECO app.

Press the button to switch on the appliance.

HANDLING

All BONECO Air Shower fans are designed for easy han-

dling. The output is adjusted in 32 levels using a single

control.

ALIGNMENT

The fan unit can be manually tilted 270 degrees.

The fan unit does not rotate a full 360 degrees.

HEIGHT ADJUSTMENT

All electrical components are completely integrated in the

connector. Therefore, you can adjust the height at any

time by adding connector pieces or by pulling them off

after pressing down the knob to unlock them.

For safety reasons, a maximum of two connector

pieces can be used at once (F235).

HANDLING

270°

USE

The timer function lets you determine how long the

BONECO F225–F235 should run before it switches off

automatically (OFF timer).

Alternatively, you can specify a time period for the appli-

ance to wait before switching on automatically (ON timer).

For example, you can use this function to ensure that the

BONECO F225–F235 will switch itself on before you re-

turn home. When you get back, you’ll have the perfect

home climate waiting for you.

SETTING THE OFF TIMER

1. Switch on the appliance using the  button.

2. Select the desired fan level.

3. Hold the button for 3 seconds until the indicator

«0h» flashes in the display.

4. Use the controller to set the hours until switch-off.

After approximately 5 seconds without input, the

selected value is accepted and the TIMER symbol is

shown on the display.

The appliance runs for the specified period before switch-

ing off.

5. To terminate the timer early, hold the button for

3 seconds and select «0h». Alternatively, you can

switch off the appliance using the button.

SETTING THE ON TIMER

1. Switch off the appliance using the button.

2. Hold the button for 3 seconds until «0h» flashes

in the display.

3. Use the controller to set the hours until switch-on.

After approximately 5 seconds without input, the se-

lected value is accepted and the remaining duration

in hours is shown on the display.

4. Select the desired fan level.

The appliance switches on after the defined time and op-

erates at the selected fan level.

5. To deactivate the ON timer early, hold thebutton

for 3 seconds and select «0h». Alternatively, you can

switch on the appliance using the button.

TIMER FUNCTION
