Bolymedia SG860C-12MHD Manuel utilisateur
Infrared Digital Scouting Camera
User’s Manual
Scouting Camera SG860C-12mHD
Content
1 Instruction..............................................................1
1.1 Camera Body Interfaces ...................................1
1.2 General Description........................................ 2
1.3 Application...................................................... 3
1.4 Shooting Information Display ........................ 3
1.5 Cautions .......................................................... 4
2 Quick Start Guide ................................................. 6
2.1 Power Supply .................................................. 6
2.2 Insert the SD Card.......................................... 7
2.3 Enter into Setup Mode ................................... 7
2.3.1 Preview and Playback ............................... 7
2.3.2 Customer Settings .................................... 7
2.3.3 Manual Capturing .................................... 7
2.3.4 View Images or Videos .............................8
2.3.5 Delete Images or Videos...........................8
2.4 Triggering Modes ........................................... 8
2.4.1 PIR Triggering .......................................... 8
2.4.2 Timer Triggering ......................................8
2.4.3 PIR&Timer Triggering ............................. 9
2.5 Enter into On Mode........................................ 9
3 Item Settings....................................................... 10
3.1 Camera Menu................................................ 10
3.2 Default Setting.............................................. 13
3.3 Power Off...................................................... 14
4 Mounting the Camera..........................................15
5 PIR Detection Zone............................................. 16
6 Technical Specifications ......................................17
7 Parts List ............................................................. 18
Page 1
1 Instruction
1.1 Camera Body Interfaces
Page 2
1.2 General Description
This camera is a surveillance device working
automatically. It can be triggered by any movement
of human (or animal) in a certain region of
interested (ROI) monitored by a highly sensitive
Passive Infra-Red (PIR) motion sensor, and then
take high quality pictures (up to 12 mega pixels) or
video clips.
It also can be triggered by a timer which means the
camera can capture pictures or video clips at
specified time intervals regardless of whether there
is a motion of human or animal.
The device is equipped with built-in full color white
LED light, it takes clear color pictures and videos
both day and night. The camera consumes very little
power (μA level) at surveillance mode.
It is designed for outdoor use and is resistant
against water and snow. Furthermore, the camera
can be used as a portable digital camera. Pictures or
videos can be taken manually by pressing on the
operation panel.
Page 3
1.3 Application
This camera can be used as an automatic
surveillance device for guarding and recording
unexpected intrusions to homes, shops, schools,
depots, offices, taxies, worksites etc. It can also be
used as trail camera for hunting or monitoring
animals by recording the traces of wild animals. It
can be left alone for weeks and months and it will
save event records automatically in digital format.
1.4 Shooting Information Display
When the camera is turned on (power switch is slid
to SETUP position), the current settings will be
displayed on the screen.
Page 4
Key notes:
“MENU” : to enter the program menu in
preview mode;
“▲”“▼”“◄”“►”: for parameter settings ;
“OK”: to save parameter settings and play
videos;
“ ”: to exchange between playback mode and
preview mode;
“DEL”: to delete an image or video in playback
mode;
“ ”: to capture a photo or record a video
manually.
1.5Cautions
★The working voltage of the camera is 6V.The
camera is supplied by 8 AA batteries or DC power
adapter with output of 6V. Please install batteries
according to shown polarity.
★Please insert the SD card when the power switch
is in OFF position before testing the camera. The
camera has no internal memory for saving images
or videos. If no SD card is inserted, the camera
will shut down automatically after a continuous
indication beep.
★Please do not insert or take out the SD card when
the power switch is in the ON position.
★It is recommended to format the SD card by the
camera when used for the first time.
★The camera will be in USB mode when connected
to a USB port of a computer. In this case, the SD
card function is as a removable disk.
Page 5
★In TEST mode, the camera will shut down
automatically after 3 minutes if no operation is
done. Please turn on the power again if you want
to continue to work with the camera.
SG860C-12mHD 2 Quick Start Guide
Page 6
2 Quick Start Guide
2.1 Power Supply
To supply power for the camera, four or eight size
AA batteries are needed.
1. High-density and high-performance alkaline
batteries (Recommended)
2. Rechargeable alkaline batteries
3. RechargeableNiMHbatteries
When in a low-battery state, the camera will be
automatically shut down. Please change the
batteries at this time.
Caution: Risk of explosion if battery is replaced by
an incorrect type. Also dispose of used batteries
according to the instructions.
Correct Disposal of this product. This marking
indicates that this product should not be disposed
with other household wastes throughout the EU. To
prevent possible harm to the environment or
human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable
reuse of material resources. To return your used
device, please use the return and collection systems
or contact the retailer where the product was
purchased. They can take this product for
environmental safe recycling.
SG860C-12mHD 2 Quick Start Guide
Page 7
2.2 Insert the SD Card
Insert SD card into the card slot. Please note that
the SD card is on the “write” (not locked) position
otherwise the camera will not function correctly. If
no SD card is inserted, the camera will shut down
automatically.
2.3 Enter into Setup Mode
There are 3 states in SETUP Mode: preview state
(preview the scene in front of the camera), setting
state (do customer settings), and playback state
(view photos or videos via the 2.0” LCD display).
2.3.1 Preview and Playback
After switching the camera to SETUP Mode, it
enters into the preview state.
Press to exchange between playback mode and
preview mode;
2.3.2 Customer Settings
Press MENU to manually customize the camera
settings which displayed on the screen. The detailed
operations will be described in “Advanced
Operations” chapter.
2.3.3 Manual Capturing
Press to manually capture photos or record
videos, again to stop the manual capturing of a
SG860C-12mHD 2 Quick Start Guide
Page 8
video clip in preview mode.
2.3.4 View Images or Videos
Press to view images or videos, the latest image
or video will be shown on the LCD screen. Press
“▲” or “▼” to view the previous or next image or
video and press OK to see a video.
2.3.5 Delete Images or Videos
Press DEL to delete images or videos. Note the DEL
button just works in Playback state. So if it’s in
Preview state, you should press to enter into
Playback state first.
2.4 Triggering Modes
There are 3 triggering modes of the camera: PIR
triggering ，Timer triggering and PIR&Timer
triggering.
2.4.1 PIR Triggering
PIR triggering is the default setting. The camera
works only when motions get detected, while, if PIR
sensitivity is set as PIR OFF, the camera stops PIR
triggering.
2.4.2 Timer Triggering
The Timer Interval default setting is OFF which
means the timer triggering is disabled. While
