Using juice extractor
How to dismantle and assemble
1. Read all instructions.
2. This appliance is not intended for use by persons with reduced physical,
sensory, or mental capabilities, or lack of experience and knowledge,
unless they are closely supervised and instructed concerning the use of
the appliance by a person responsible for their safety.
3.This appliance shall not be used by children. Keep the appliance and its
cord out of reach of children.
4. Close supervision is necessary when any appliance is used near children.
Children should be supervised to ensure that they do not play with the
appliance.
5. To protect against risk of electric shock, do not immerse cord, plug, or
motor base in water or other liquid.
6. Always turn appliance OFF and unplug cord from outlet when not in use,
before putting on or taking off parts, and before cleaning.
7. Avoid contacting moving parts. Keep fingers out of feed chute.
8. Never feed food by hand—always use the food pusher.
9. Always make sure the juice extractor is properly and completely
assembled before the motor is turned ON. The unit will not turn ON
unless properly assembled. Do not release safety locking arm while juice
extractor is in operation.
10. Be sure to turn the switch to the OFF position after each use. Make sure
the motor stops completely before disassembling.
11. Do not put fingers or other objects into the juice extractor feed chute
while it is in operation. If food becomes lodged in the opening, use food
pusher to push it down. When this method is not possible, turn the motor
OFF, unplug the cord from the outlet, and disassemble juicer to remove
the remaining food.
12. Do not use appliance for other than intended use.
13. Do not operate any appliance with a damaged supply cord or plug, or
after the appliance malfunctions or has been dropped or damaged in any
manner. Maintenance and repairs must be done by the manufacturer or
its service agent.
14. The use of attachments not recommended or sold by the appliance
manufacturer may cause fire, electric shock, or injury.
15. Do not use outdoors.
16. Do not leave juice extractor unattended while operating.
3. Place the pulp container into the
appliance by tilting it forward
slightly
4. Slide the pusher into the feeding by
aligning the groove in the pusher
with small protrusion towards the
inside of the feeding tube.
5. Switch on by turning the control
knob to select setting 1 ( low
speed ) or 2 (normal speed ) or P
(pulse ) to start.
6. Put the pre-cut pieces into the
feeding tube and gently press them
down towards the rotating filter
basket with the pusher. Make sure
the juice jug is placed under the
juice spout before making juice.
DISMANTLE:
Unplug the appliance from the power supply.
Release the lock arm.
Remove the pulp container,transparent
lid,pusher,pull the filter
basket upwards and the juice collector
separately.
ASSEMBLE:
Place juice collector on the motor unit, and insert filter basket.
Mount transparent lid onto the juice collector, and fasten the
lock arm upwards until it clicks into place.
Place the pulp container under the pulp spout and put the juice jug
under the juice spout. Plug in. It is ready to use.
• This appliance is equipped with a safety lock system. lf the transparent lid
is not correctly placed or the lock arm is unfastened,the appliance will not
function.
• Before starting,make sure the appliance is switched off, and that the
transparent lid and locking arm are fastened properly.
• Wash fruits and vegetables thoroughly.Cut fruits into small pieces so as
to be fitted into the feed tube. Remove the seeds or pits from these
fruits: prunes, apricots, cherries or oranges, lemons, melons etc. Peel off
fruits with thick skins or whose skins are inedible.
• Plug in and switch on the appliance and choose the desired speed
according to different fruits and vegetables.
• Put the pre-prepared fruits and vegetables into the feed tube and press
the pusher down gently.
NEVER USE FINGERS OR OTHER OBJECTS AS PUSHER.
• When pulp container or juice jug is full, switch it off and empty the
containers before continuing the process.
ATTENTION:
Do not run the juice extractor continuously for longer than 2 minutes. If
more than that time is required, occasionally switch it off to allow the
appliance to cool down.
CAUTION:
Remove large seeds or pit from fruits like apricot, peach, plum and
cherry etc.
Fruits and vegetables like banana, mango, papaya and coconut are not
recommended as well as hard fruits.
When the process is complete, switch the juicer off and unplug the unit.
7 8
17. Blades are sharp; handle carefully. Do not touch the small cutting blades in the
base of the stainless steel strainer basket.
18. Do not use the appliance if the rotating strainer basket or juice cover is
damaged.
19. Always use the juice extractor on a dry, level surface.
20. To reduce the risk of personal injury and/or damage to the appliance, do not
use bent, dented, or otherwise damaged strainer basket.
21. Do not operate without the pulp container in place.
22. Do not place on or near a hot gas or electric burner or in a heated oven.
23. Check that the appliance is OFF before plugging cord into wall outlet. To
disconnect, turn the control to OFF; then remove plug from wall outlet. To
unplug, grasp the plug and pull from the outlet. Never pull from the power cord.
How to dismantle and assemble
Operating instructions
