Blunet BL-32960M Manuel d'utilisation

DVR Installation & User’s Guide

BL-1680A/BL-32960M

(v 1.4)

Caution

Since this device is operation purpose and registered as suitable electromagnetic waves, seller or user

should be cautios on this point. If the device is sold or purchasedwrongly, it is required to replace as

Home use.

FCC Compliance Statement

Caution : Any changes or modifications in construction of this device which are not expressly approved

the party responsible for compliance could void the user's authority to operate the equipment.

NOTE : This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful interference to radio communications,

Operation of this equipment in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at his own expense.

Warning

This is a class A product. In a domestic environment this product may cause radio interference in which

case the user may be required to take adequate measures

Warning

1. In case of changing built-in lithum battery, it should be replaced as same or kindred one to prevent a

danger of explosion. Since old batteries could be a factor of environment contamination, be cautios to

treat them.

2. Do not throw the batteries to fire or heating. Neither short circuiut or disassembly is prohibited.

3. Do not charge the batteries provided with Remote Controller

Important Notice

1. Do not place heavy objects on the top of the product.

2. Product is for indoor use. It is not weatherproof. Use product with referring to its environmental

specifications (Temperature & Humidity). To clean the product, gently wipe the outside with a clean dry

cloth.

3. Product uses AC power of 110V ~ 240V. Be cautious not to cause electric damages to product.

4. Be careful not to drop the product. Physical shocks may harm the product including internal HDD. In

addition, be sure the product is secured after installation.

5. Product is made of metal. Therefore you can hurt human beings if you throw it to them or hit on them.

When installing product, be cautious to locate on safe places where children are unreachable.

6. If Product does not operate properly, please contact the closest BLUNET distributor for after sales

service. Tampering or disassembling the product will void the warranty.

7. Security surveillance laws may differ for each country. Therefore, please contact the local region first

to avoid any surveillance law violations.

The content of this manual can differ according to firmware or Software upgrading, and the standard and

appearance of products may be changed for the improvement of quality without an advance notice.
