Bluetti EB200P Manuel utilisateur
EB200P Portable Power Station
Please read and fully understand this manual before use and keep it handy for future reference.
User Manual
Please read and fully understand this manual before use and keep it handy for future reference.
CONTENTS
1. BRIEF INTRODUCTION
2. ABBREVIATION
3. SAFETY INSTRUCTION
4. IN THE BOX
5. FUNCTIONS
6. LET'S GET STARTED
7. TOUCHSCREEN GUIDE
8. CHARGING
9. DISCHARGING
10. APPLICATION SCENARIO
11. EXAMPLES OF LOADS
12. ESTIMATION OF OPERATING TIME
13. TECHNICAL SPECIFICATIONS
14. TROUBLESHOOTING
15. FAQ (Frequently Asked Questions)
16. DECLARATION
......………………………………….........................………01
.....…………………………………………......................................01
......………………………............................………………01
....…………………………………............................................………02
.....………………………………...........................................…………04
......…………………………............................………………05
......……………............…………................………………05
.....…………………...………..…..............................................………08
….....…………………………..……….....................................……11
…….......…………………...................…………….......11
…….......…………..……….........................………………11
…........……..……………....…………………12
………..........………………............………………13
…………......…………...……….......................……………14
…………..…….......……........…………………15
………………………….....……….....................................………16
1. BRIEF INTRODUCTION
2. ABBREVIATION
3. SAFETY INSTRUCTION
- 01 -
The EB200P features a 2200W pure sine wave inverter and 2048Wh LiFePO4 battery pack,
enough to power your daily essential electricity needs. Furthermore, it has the built-in 30A
NEMA TT-30 receptacle designed for the RV and the fast-charging 100W PD3.0 USB-C port.
Additionally, with an MPPT controller which can handle up to 900W solar input perfectly, it
supports AC + Solar 1400W Max. and dual AC 1000W Max. Charging. In short, it can be
referred to be an optimum power station for home and outdoor use.
● DO keep the EB200P power station away from the fire and heat.
● DO operate the EB200P in a dry and well-ventilated place. If it gets moisturized or damp,
please dry it thoroughly before use.
● Be sure to check all materials before use. In case of any abnormality such as breakage,
crack, leakage, and AC line breakage, please stop using the EB200P immediately.
● DO NOT use wet hands to touch EB200P or connector plug. It may cause electric shock
hazards.
● DO NOT use metal to contact the AC output interfaces. It may cause electric shock,
overheating, fire, and other dangers.
● DO NOT obstruct fan openings to ensure proper ventilation in use. Otherwise, permanent
damage to the EB200P may occur.
● BMS: Battery Management System
● MPPT: Maximum Power Point Tracking
● SOC: State of Charge
● AC: Alternating Current
● DC: Direct Current
● PV: Solar Panel(s) Charging (Photovoltaic)
● Grid: Home Power Supplied by Utility
● DOD: Depth of Discharge
●ECO Mode: A power-saving setting for the EB200P. When it is on, the AC power will
automatically turn off over 4 hours low (≤50W) or no load to save power drain from the
inverter.
- 02 -
● DO NOT move the EB200P in use since vibrations and sudden impacts may lead to poor
connections to the hardware inside.
● Please read and fully understand the operating instructions of the electrical products to be
connected. Failure to operate the electrical products properly may result in accidents or
injuries.
● Please use the original charger and cables only designed for the EB200P. BLUETTI is not
liable for damage caused by third-party equipment, which also may invalidate your warranty.
● Please use the EB200P power station carefully and keep children away from it.
● Warning: In case of fire, ONLY dry powder fire extinguisher works.
● Warning: DO NOT insert foreign objects into any ports of the EB200P (AC, DC, or ventilation
holes). The power station generates the same potentially lethal AC power as a household
wall outlet.
● Warning: It is hazardous for anyone other than the authorized person to carry out any
service or repair operation involving replacing the internal battery or other equipment
components.
4. IN THE BOX
Power Station (EB200P) 1PCS
Adapter
For AC charging.
No.
1
1PCS2
PV Charging Cable (XT90 - MC4)
For solar charging, up to 15A, 900W. 1PCS3
Multifunctional DC Charging Cable (XT90-Aviation)
Expand the charging methods via PV input port. 1PCS5
Car Charging Cable
(XT90 - Cigarette Lighter Port)
Charge the EB200P by car.
1PCS4
Picture Category Quantity
Standard Accessories
1PCS
- 03 -
No.
1PCS
1PCS
Warranty Card
Certificate of QC PASS
7
8
User Manual6
Picture Category Quantity
Lead-acid Battery Charging Clamp
Charging EB200P through lead-acid battery only.
DO NOT charge the lead-acid battery via this cable. Optional
Input
Cable
Multifunctional Input Cable
(XT90 - DC7909)
Expand the charging methods via AC input port.
No.
9
10
12V/30A Output Bundle
(Aviation - XT60, XT60 - SPC45)
Perfect for RV.
D300S PV Step Down Module
Step down the voltage of solar
panels (especially rigid panels) to adapt
to the EB200P solar input standard.
Optional
Output
Accessories
11
Optional
Accessories
12
Picture Category Type
Optional Accessories
- 04 -
5. FUNCTIONS
01
02
03
04
05
06
07
08
09
10
11
12
11 Power button
Long/Short press to turn ON/OFF the
EB200P.
01 DC 12V/10A cigarette lighter port
Output port for devices with corresponding
plug such as vehicle-use vacuum, refrigerator.
07 DC input port
The port to connect with solar panels for
PV charging, or with extra cables for car,
lead-acid battery, and extra AC adapter charging.
09 Wireless charging pad 15W x 2pcs
Place your phone (if wireless charging
supported) on the top of the EB200P
horizontally, and turn on the DC.
12 US AC output x 6 pcs
(EU/UK/AU AC output x 4pcs)
Standard AC receptacle: wildly used in
100-120V areas, generates the almost same
AC power as a household wall outlet.
High-voltage area uses special sockets.
10 Interaction LCD touchscreen
Control the EB200P with figures.
08 AC input port
Charging via the AC adapter.
02 DC 5521 12V/10A output x 2pcs
Traditional ports for routers/cameras, old
laptop, etc.
03 DC 12V/30A output
Special 30A output port adapted to most
appliances, perfect for RV.
05 USB-C 100W output
Output port to charge most devices at
100W Max, such as Pixel Phone, Macbook Pro.
04 USB-A 18W output x 2pcs
Quick charge USB-A ports.
06 USB-A 5V/3A output x 2pcs
Classic USB-A ports.
6. LET'S GET STARTED
(1) Startup: short press the power button, the indicator light will be on, and the machine
will be on standby.
(2) Shutdown: press and hold the power button for several seconds, and the indicator
light will be off and the machine will shut down.
(3) DC power switch and AC power switch are integrated into the interaction LCD screen,
press the 'DC ON/OFF' or 'AC ON/OFF' on the screen to turn on/off the DC/AC output.
7. TOUCHSCREEN GUIDE
Interaction LCD screen (Information Vision) supports below functions:
●Display the real-time voltage, current, power, temperature and state of charge and discharge.
● Adjust the output voltage, frequency, charging mode, power consumption mode, and time
information in the setting column.
●Support energy-saving, and enable Super ECO mode to save more than 30% of energy
loss.
● View all fault information and software versions independently.
BMS Over-current or short circuit protection
BMS Startup timeout
Normal startup
Normal shutdown
The indicator light flashes and then turns off.
The indicator light flashes and does not turn off.
The indicator light turns on.
The indicator light turns off.
The LED indicator lamp status explanation
- 05 -
- 06 -
Friendly Note:
● The LCD touchscreen is resistive. It is recommended to lightly tap or press the screen with
fingers until it 'beeps'.
● In order to maximize the lifespan of the LCD screen, please avoid direct sunlight.
(1) When pressing the power button, the mainpage of the LCD screen will display as Homepage.
(2) Click the 'Settings' to enter setting section (Figure 1), you can view the current system
language, AC output voltage, frequency, and DC input source.
Kindly Note: Please check the AC output voltage, frequency and other parameters for
the first startup.
a. PV/Car Charging Info
b. BMS Info
c. Date/Time
d. DC Load Info
e. DC ON/OFF Switch
f. AC ON/OFF Switch
g. Adapter Charging Info
h. AC Load Info
Voltage and Frequency Reference:
● JP output: 100V/50Hz
● US output: 120V/60Hz
● EU output: 230V/50Hz
● UK output: 230V/50Hz
● AU output: 240V/50Hz
DC Input Source: Select the right method you choose to charge the EB200P.
ECO Mode: When it is on, the AC power will automatically turn off over 4 hours low (≤50W）
or no load to save power drain from the inverter.
(Homepage) (Figure 1)
Press 'Next' to enter the date and time setting as below (Figure 2):
Backlight and Sleep time: set the proper value as your need for power saving.
Date and time: 2000-00-00; 00: 00: 00, make adjustments to set it right.
- 07 -
(3) Back to the Homepage, tap the 'Data' to enter the Data section (Figure 3).
● Tap the 'Product Info', you can view the product model, software version, BMS version,
and so on;
● Tap the 'Inverter & Charger Info', you can view the input and output information, which
can also be accessed directly from the shortcut on the Homepage;
●Tap the 'BMS Maintenance', you can view the status of battery, which can also be
accessed directly from the shortcut on the Homepage;
● Tap the 'Fault History', you can view all the fault information.
(4) Tap the 'Alarm' on the Homepage, you can view the current error information. The
fault indicator will display orange if there is a fault.
（Figure 3）
（Figure 2）
