Blue Wave ACCELERATOR Manuel utilisateur
ACCELERATOR 4in1 MULTI-GAME
TABLE ASSEMBLY INSTRUCTIONS
NG1016M
Please Do Not Hesitate to
Contact Our Consumer Hotline
at 800-759-0977
with Any Questions That May
Arise During Assembly or
Use of This Product!
THANK YOU!
Thank you for purchasing this product.
We work around the clock and around the globe to ensure that our products
maintain the highest possible quality. However, in the rare case of issues
during assembly or use of this product, please contact our Consumer Hotline
at 800-759-0977 for immediate assistance before contacting your retailer.
Please read the warranty information at the back of these assembly
instructions for further details.
IMPORTANT! PLEASE READ THESE ASSEMBLY INSTRUCTIONS
IN ENTIRETY BEFORE ASSEMBLING YOUR PRODUCT.
2
PARTS IDENTIFIER (NOT TO SCALE)
3
P1 NGP6000
1 pc
TABLE BODY
P3 NGP6002 P4 NGP6003
2 pcs
LEG PANEL 1 pc
TABLE TENNIS
WHITE BOARD LEG LEVELER
4 pcs
P2 NGP6001
4 pcs
LEG
P5 NGP6004
P6 NGP6005
2 pcs
BASKETBALL ARM
P8 NGP6007 P9 NGP6008
1 pc
BASKETBALL RIM 1 pc
BASKETBALL BALL RETURN NET
1 pc
P7 NGP6006
1 pc
BACKBOARD
P10 NGP6009
P11 NGP6010
2 pcs
STRIKER
P13 NGP6012 P14 NGP6013
1 pc
TABLE TENNIS NET 2 pcs
TABLE TENNIS POSTS TABLE TENNIS BALL
2 pcs
P12 NGP6011
2 pcs
PUCK
P15 NGP6014
P16 NGP6015
2 pcs
TABLE TENNIS PADDLE
P18 NGP6017 P19 NGP6018*
1 pc
ERASER 4 pcs
1/4”x3/4” BOLT 26mm BOLT
4 pcs
P17 NGP6016
2 pcs
MARKER
P20 NGP6018*
P21 NGP6018*
4 pcs
NUT
P23 NGP6018* P24 NGP6018*
16 pcs
1/4”x1-1/8” BOLT 12 pc
1/2” SCREW AIR PUMP
1 pc
P22 NGP6018*
20 pcs
WASHER
P25 NGP5035
P26 NGP6018*
1 pc
ALLEN WRENCH *Items included in Hardware Pack, NGP6018
A
B
For replacement parts please call 800-759-0977.
ASSEMBLY TIPS
4
1. Find a clean, level surface to begin the assembly of your game table. The table will be
partially assembled upside down and then turned over onto its legs. This is a heavy game
and turning it over will require at least two strong adults.
2. Remove all of the contents from box and verify that you have all of the parts shown on
Note: Some parts may be pre-installed
or pre-assembled.
understand the text before beginning each assembly step.
4. When installing parts that have more than one screw or bolt, hand tighten all
5. Electric screwdrivers may be helpful during assembly; however, please set a low torque
and use extreme caution because screws may be stripped or overtightened, resulting in
damaged parts, if the electric screwdriver’s torque is set too high.
WARNINGS!
READ AND FOLLOW ALL ASSEMBLY, OPERATION AND SAFETYINSTRUCTIONS CAREFULLY.
CHOKE HAZARD - THIS TABLE CONTAINS SMALL BALLS AND PARTS
NOT SUITABLE FOR CHILDREN UNDER 3 YEARS OF AGE.
THANK YOU!
5
ASSEMBLY INSTRUCTIONS
1. Attach one LEG P2 to each corner of the TABLE BODY P1 using BOLTS P23 and WASHERS P22.
2. Attach LEG PANELS P3 to inside of LEGS P2 on each end of table using SCREWS P24 in pre-drilled holes.
3. Install one LEG LEVELER P5 on bottom of each Leg. Carefully turn table over onto legs.
4. Attach BASKETBALL RIM P8 onto BACKBOARD P7 using SCREWS P24 in pre-drilled holes.
5. Attach two BASKETBALL ARMS P6 onto end of TABLE BODY P1 using BOLTS P23 and WASHERS P22.
6. Attach BACKBOARD P7 onto BASKETBALL ARMS P6 using four BOLTS P20 and NUTS P21 as shown.
ASSEMBLY INSTRUCTIONS (CONT.)
6
7. Attach the BALL RETURN NET P10 to the two BASKETBALL ARMS P6 using the Velcro strips as shown.
6. Attach the black straps on the front sides of the BALL RETURN NET P10 to the sides of table using
BOLTS P19 and WASHERS P22.
ASSEMBLY INSTRUCTIONS (CONT.)
7
P22
ASSEMBLY INSTRUCTIONS (CONT.)
8
Simply remove the basketball assembly to play AIR HOCKEY.
Place the dry erase board on top of the table
to create a DESK or ART/CRAFT AREA.
Flip the dry erase board over, insert the net posts
and net, and you’re ready for TABLE TENNIS.
CONGRATULATIONS!
9
CARE AND USE
1. This product is intended for INDOORuse only.
2. Do NOT sit, climb or lean on the table.
3. Do NOT drag the table when moving it as this will damage the legs.
You have now assembled your Game Table.
Please note the Care and Use instructions below to
ensure years of trouble free use of your game table.
180-DAY LIMITED WARRANTY
10
This product is warranted to the original purchaser to be free from defects in material or workmanship
for a period of 180 days from the date of the original retail purchase.
This warranty does not cover defects or damage due to improper installation, alteration, accident or
any other event beyond the control of the manufacturer. Defects or damage resulting from misuse,
abuse or negligence will void this warranty. This warranty does not cover scratching or damage that
may result from normal usage.
This product is not intended for institutional or commercial use; the manufacturer does not assume
any liability for such use. Institutional or commercial use will void this warranty.
This warranty is nontransferable and is expressly limited to the repair or replacement of the defective
product. During the warranty period, the manufacturer shall repair or replace defective parts at no
cost tothe purchaser. Shipping charges and insurance are not covered and are the responsibility of
the purchaser. Labor charges and related expenses for removal, installation or replacement of the
product or components are not covered under this warranty.
The manufacturer reserves the right to make substitutions to warranty claims if parts are unavailable
or obsolete.
The manufacturer shall not be liable for loss of use of the product or other consequential or incidental
costs, expenses or damages incurred by the consumer of any other use. The user assumes all risk of
injury resulting from the use of this product.
This warranty is expressly in lieu of all other warranties, expressed or implied, including warranties of
. Neither the manufac-
turer nor any of its representatives assumes any other liability in connection with this product.
All warranty claims must be made through the retailer where the product was originally
purchased. A purchase receipt or other proof of date of purchase will be required to process
all warranty claims. The model number and part numbers found within the assembly
instructions will be required when submitting any parts requests or warranty claims.
For further warranty information or inquiries, please call 800-759-0977
