Blue Technix Argos 3D-P320 Manuel utilisateur
Argos 3D -
P320
Quick Start Guide
Version 1
© Bluetechnix 2015
Bluetechnix
Waidhausenstraße 3/19
A-1140 Vienna
AUSTRIA
www.bluetechnix.com
Argos3D-P320 –Quick Start Guide
Document No.: 900-308 / A
Publication date: October 12, 2015
Subject to change without notice. Errors excepted.
This document is protected by copyright. All rights reserved. No part of this document may be reproduced or
transmitted for any purpose in any form or by any means, electronically or mechanically, without expressly
written permission by Bluetechnix GmbH.
Windows is a registered trademark of Microsoft.
© Bluetechnix 2015
Table of Contents
1Unboxing .......................................................................................................................................... 5
1.1 In the box .................................................................................................................................. 5
1.2 Opening your Argos3D–P320 ................................................................................................... 5
1.3 Connecting your Argos3D–P320 .............................................................................................. 6
1.4 Connector Overview ................................................................................................................. 6
1.4.1 Connecting the power supply............................................................................................ 7
1.4.2 Connecting the Ethernet Cable ......................................................................................... 7
2Downloading the Evaluation Software ............................................................................................. 8
2.1 Support website........................................................................................................................ 8
2.2 Start-up screen ......................................................................................................................... 9
2.3 Prepare your Network Interface Card (NIC) ............................................................................ 10
3Start using your Argos3D–P320 with ‘BltTofSuite’ ........................................................................ 11
4System Requirements & Support................................................................................................... 13
4.1 Bluetechnix ToF Suite ............................................................................................................. 13
4.2 Support ................................................................................................................................... 13
5Product History .............................................................................................................................. 14
5.1 Version Information ................................................................................................................. 14
5.1.1 Argos3D–P320 ................................................................................................................. 14
5.2 Anomalies................................................................................................................................ 14
5.3 Document Revision History .................................................................................................... 14
6Index............................................................................................................................................... 15
© Bluetechnix 2015
© Bluetechnix 2015
All Rights Reserved.
The information herein is given to describe certain components and shall not be considered as a guarantee
of characteristics.
Terms of delivery and rights of technical change reserved.
We hereby disclaim any warranties, including but not limited to warranties of non-infringement, regarding
circuits, descriptions and charts stated herein.
Bluetechnix makes and you receive no warranties or conditions, express, implied, statutory or in any
communication with you. Bluetechnix specifically disclaims any implied warranty of merchantability or fitness
for a particular purpose.
Bluetechnix takes no liability for any damages and errors causing of the usage of this board. The user of this
board is responsible by himself for the functionality of his application. He is allowed to use the board only if he
has the qualification. More information is found in the General Terms and Conditions (AGB).
Information
For further information on technology, delivery terms and conditions and prices please contact Bluetechnix
(http://www.bluetechnix.com).
Warning
Due to technical requirements components may contain dangerous substances.
Quick Start Guide - Argos 3D - P320 Last change: 12 October 2015
Version 0.1
© Bluetechnix 2015 Page 5 | 15
1Unboxing
1.1 In the box
Argos3D–P320
CAT5/7 Ethernet Cable
Quick Start Guide
Power Supply *
* Note
The power supply’s operating temperature is specified from 0 to +40°C. This represents not
the effective working temperature of the Argos3D–P320 sensor!
1.2 Opening your Argos3D–P320
To access the connector compartment unscrew the two screws on the Argos3D-P320 front and take
off the connector compartment lid.
Figure 1-1: Argos3D–P320 connector compartment screw positions
Quick Start Guide - Argos 3D - P320 Last change: 12 October 2015
Version 0.1
© Bluetechnix 2015 Page 6 | 15
1.3 Connecting your Argos3D–P320
1.4 Connector Overview
a. Power Connector
b. Ethernet
c. General purpose input 1 & 2
d. General purpose output 1 & 2
e. Modulation Light Interface
f. Trigger
g. RS232 / RS485
h. DIP-Switch
i. Reset-Button
j. Debug-UART
k. Status LED
Marks Pin #1
b a c f
ed g i
h j
k
Figure 1-2: Argos3D–P320 connectors and interfaces
Note
Please follow the next steps in the right order to get your ‘Argos3D-P320’ up and running
correctly.
Quick Start Guide - Argos 3D - P320 Last change: 12 October 2015
Version 0.1
© Bluetechnix 2015 Page 7 | 15
1.4.1 Connecting the power supply
To ensure, that your Argos3D–P320 works correctly, connect the ‘Argos3D’to a 12-30V DC power supply
using connector (a) and wait for approximately 20 seconds until the camera boots up.
Pin assignment on the power connector (a): Pin #1: +12V to +30V, Pin#2: GND
Note
The power supply connector is protected against wrong polarity but the ‘Argos3D’ will not
work in case you don’t use the correct polarity! If the Argos3D–P320 doesn’t work please
check the power supply polarity first!
1.4.2 Connecting the Ethernet Cable
Plug in the Ethernet cable (b) and connect your Argos3D–P320 to your PC.
Figure 1-3: Argos3D–P320 with connected power supply and Ethernet cable
Quick Start Guide - Argos 3D - P320 Last change: 12 October 2015
Version 0.1
© Bluetechnix 2015 Page 8 | 15
2Downloading the Evaluation Software
Please log in to our support website at https://support.bluetechnix.com/ and download the Argos-P320
customer software package. This package also includes the Bluetechnix ToF-Suite.
2.1 Support website
Select ‚free access‘
Figure 2-1: Download Evaluation Package
Quick Start Guide - Argos 3D - P320 Last change: 12 October 2015
Version 0.1
© Bluetechnix 2015 Page 9 | 15
2.2 Start-up screen
Figure 2-2: Start-up screen
Please select your product: Argos 3D –P320
Please follow the instructions on the WEB-Site
Quick Start Guide - Argos 3D - P320 Last change: 12 October 2015
Version 0.1
© Bluetechnix 2015 Page 10 | 15
2.3 Prepare your Network Interface Card (NIC)
Once you have connected your Argos3D–P320 to a Network Interface Card (NIC) of your PC give this NIC
the IP-Address 192.168.0.1 with a subnet mask of 255.255.255.0.
No driver must be installed on your PC!
The Argos3D–P320 uses IP-Address 192.168.0.10 with subnet mask 255.255.255.0.
