BluDot Woodsy Guide de démarrage rapide
Woodsy Storage Ladder
DESIGNED IN 2021
ASSEMBLY NOTES | REV 00
@BLUDOT
We design all our pieces in our Minneapolis studio. Follow
along on Instagram for some sneak peeks into the process.
NEED A HAND?
844.425.8368 for assistance.
2 | 844.425.8368 WOODSY STORAGE LADDER
Pt. 1405 Pt. 8036
2 2QTY QTY
Pt. 1114 Pt. 9005
2 1QTY QTY
Ladder Wall Mount
1 1QTY QTY
Parts & Hardware
SERVICE@BLUDOT.COM |3ASSEMBLY NOTES
PT. 1405 X 2PT. 8036 X 2
PT. 1114 x 2PT. 9005 x 1
16” Inches Apart
58 7/8 Inches
Above the Floor
Step 02
INSTALL THE LADDER.
Slide the ladder onto the wall mount. Secure
the ladder using the provided set screws as
shown.
Step 01
INSTALLING THE WALL MOUNT.
Hardware is included for installation. Please
consult your local hardware professional to
determine the hardware best suited for your
wall type.
Use the wall mount as a template to mark the
holes. With a level and a measuring device, be
sure the holes are 58 7/8” above the floor.
If the mounting location is not positioned on
a stud, drill a 1/4” hole in the marked location
and insert anchor as shown. If the mounting
location is located on a stud, this step of
installing an anchor may be skipped. Instead,
drill a 1/8” pilot hole in the marked location.
Attach the wall mount to the wall using the
included hardware as shown.
BLU DOT DESIGN & MANUFACTURING, INC. DESIGNED IN MINNEAPOLIS, MN
Additional Information
CLEAN
Clean with a slightly damp, soft cloth. To remove dirt and fingerprints, use a quality cleaner formulated
for wood furniture. Wipe completely dry with a soft cloth in the direction of the wood grain.
Step 03
LEVEL THE LADDER.
If the ladder is not firmly seated on the ground,
adjust the glides on the bottom of each leg to
the desired positon.
