Blomberg MEE 2020 Manuel utilisateur

General discription . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Microwave power settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Quick-Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Minute timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Microwave function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Automatic Programmes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Troubleshooting guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Care & Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

After-sales services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Important safety instructions.

Read careffully and keep for future reference.

CONTENTS

GENERAL DESCRIPTION

Turntable Wheel

support

Control Panel

Door open

button

Identification

label

• THE TURNTABLE :

ensures equal cooking of food throughout with no need to intervene.

- It may be used as a cooking dish.

- Rotation is controlled by the drive shaft and the wheel support.

- The turntable rotates in both directions.

- If it does not turn, verify that all components are properly positioned.

• THE WHEEL SUPPORT :

Do not try to rotate the roller ring manually, as you could damage the drive system.

If it does not turn smoothly, make sure that there is nothing in the well beneath the

turntable.

• MICROWAVE OUTPUT POWER : 750 W

INSTALLATION

• Make sure that your oven has not suffered any damage during transport (defor-

med door or door seal, etc.). If you see any signs of damage, contact your dea-

ler before use.

• Check the power voltage. If there is a PERMANENT undervoltage (200-210 volts),

consult your electrical installer.

Location

• The appliance should be installed at a distance of 85 cm above the floor.

• Place the oven on a flat and horizontal surface, away from any source of heat or steam.

• Make sure that nothing obstructs the ventilation louvers at the back of the

appliance.

• Make sure the electrical plug will be accessible after installation.

• Do not use your appliance immediately (wait approx. 1-2 hours) after transfer from a

cold place to a warm place as condensation may cause a malfunction.

• Your installation must be protected by a 10 Amp thermal fuse.

• It is mandatory to use a power point with a ground terminal, connected in accordan-

ce with current safety regulations.

• In your electrical installation, provide a device that is accessible to the installer, capable

of separating the appliance from the mains power and whose contact opening is at

least 3 mm at all of the poles.

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent

or similarly qualified persons in order to avoid a hazard.

Electrical connection

Before connection

INSTALLATION

360

600

310

560 min

350

370

592

4x25 mm

h 360

x 4

x 4 x 4

INSTALLATION

500

310

460 min

350

370

492

WARNING

• Your appliance is designed exclusively for the domestic purposes of defrosting, heating or

cooking foods. The manufacturer bears no responsibility in the case of improper usage.

• Only use ustensils that are suitable for use in microwave ovens.

• To avoid deterioration of your microwave oven, never operate it empty or without the

turntable.

• Never tamper with the lock mechanism of your microwave oven; you could cause damage

requiring repair by an authorised technician.

• When heating food in plastic or paper containers, keep an eye on the oven due to the

possibility of ignition.

• It is not advisable to use metal recipients, forks, spoons, knives, metal ties or staples for

deep-freeze bags.

• The contents of feeding bottles are baby food jars shall be stirred or shaken and the

temperature checked before consumption in order to avoid burns.

• Only allow children to use the oven without supervision when adequate instructions

have been given so that the child is able to use the oven in a safe way and understands

the hazards of improper use.

• Liquids and other foods must not be heated in sealed containers they are liable to explode.

• Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens

since they may explode, even after microwave heating has ended.

• Microwave heating of beverages can result in delayed eruptive boiling, therefore care

must be taken when handling the container.

• For small amounts (one sausage, a single croissant, etc.), place a glass of water along-

side the food item.

• Time settings that are too long may dry out and burn the food. To avoid such incidents,

never use the same cooking times as those recommended for traditional ovens.

• If smoke is observed, switch off or unplug the appliance and keep the door closed in

order to stifle any flames.

A Display for time of day, cooking time, func-

tion mode, power etc.

B Multi-function button to set the time of

day and display the selected microwave

power etc.

C Power knob to select microwave power

D Rotary knob toselect the cookingf time or

the weight when using automatic pro-

grammes.

EButton for automatic programmes for

defrosting and cooking.

F CLEAR button to cancel settings.

G START button to start the selected func-

tion and to switch on QUICK-START.

HButton fot switching the turntable off.

IButton for opening door.

CONTROL PANEL

Example : 12:15 hrs

1.Plug the appliance into the mains. The display starts to flash

‘0000::0000’. The dots between the digits blink rapidly.

2.Press the Multi-function button beneath the display (top left

side). The dots between the digits blink faster.

3.While keeping the Multi-function button pressed, set the time

of day with the rotary knob1)

Release the button as soon as the time of day is displayed. The

dots between the digits blink slowly. The appliance is now ready

for use.

00:00

12:15

1) The rotary knob can be turned clockwise ( to increase) or counterclockwise (to decrease).

The time of day can be corrected at any moment by pressing the Multi-function button

and simultaneously turning the rotary knob.

SETTING THE CLOCK

MICROWAVE POWER SETTINGS

750 Watt - Heating liquids

700 Watt - To start a cooking sequence, start roasting, stewing, etc.

- Cooking vegetables

- Cooking dishes

- Defrosting and heating of deep frozen ready made meals

- Heating refrigerated ready made meals

600 Watt - Finish cooking casseroles

500 Watt - Cooking egg based dishes

450 Watt - Finish cooking dishes

350 Watt - Cooking of delicate dishes

250 Watt - Heating baby food in glass jars

- Soaking rice

- Heating delicate dishes

- Melting of gelatin

150 Watt - Defrosting meat, fish and bread

80 Watt - Defrosting cheese, cream and butter

- Defrosting cakes with cream or butter icing

- To make dough rise

- Warming cold dishes, drinks, softening butter

The minute timer with alarm can also be used as a general purpose reminder. For

example, you could use it to set the time it takes to boil an egg on the hob.

The timer works without switching on the appliance, as long as no other functions have

been selected.

MINUTE TIMER

The QUICK-Start button provides full microwave power from 30 seconds up to 2 minutes

and 30 seconds, by 30 second-intervals. Each time you push the Quick-START button the

programme time is increased by 30 seconds.

Example : heating a cup of water (1 min 30 s)

1. Press the START button three times. The time appears in the dis-

play and the programme begins.

2. You may increase the time by 30 second-intervals while the pro-

gramme is running up to a limit of 2 minutes and 30 seconds by

pressing the START button 01:30

You cannot use Quick-START for programmes exceeding 2 minutes and 30 seconds.

QUICK-START

1. Select microwave power 00using the power knob (all the way to

the left).

2. Set the required time with the Rotary knob. The time of day

disappears from the display and the required length of time

appears.

3. Press the START button. The pre-set time will start to count

down. A triple bell rings when the timer has finished counting

down.

02:00

01:59

1. Set the required microwave power by turning the power knob.

The time of day disappears from the displayand the required

microwave power appears :

Turn to the left = lower power.

Turn to the right = higher power.

2. Set the required cooking time by turning the Rotary knob. The

chosen time appears in the display.

3. Press the START button. The selected time starts to count down.

750

01:15

01:14

Cooking times can be set as follows :

from 0 to 2 min in 5 second steps

from 2 to 5 min in 10 second steps

from 5 to 10 min in 20 second steps

from 10 to 20 min in 30 second steps

starting from 20 min in 1 minute steps

Maximum programme lenght is 60 minutes.

Metal items must be kept at least 2 cm from the cavity wall and the oven door.

THE MICROWAVE FUNCTION

Example : 1 min 15 s on microwave output level 750 W

Example : Defrosting 1 kg chicken

1. Press the button for automatic programmes until the desired

programme appears in the display.

2. Use the Rotary knob to set the weight in grams.

3. Press the START button. The display shows the necessary time.

4. If you want to modify the settings, you have to press the CLEAR

button and start again.

1000

29:57

AUTOMATIC PROGRAMMES

Midway through the programme, three short rings will be heard. Stir or turn the

food item at this time. The oven does not switch off.
