Dishwasher

Instruction Manual

Dear customer,

Please read carefully right through this instruction booklet before installing or

operating your dishwasher. The following instructions should prevent the risk of

personal injury and/or damage to the appliance.

Please keep these documents in a safe place for later reference.

This operating manual has been written for several different machines, and some

of the features mentioned here may not apply to your particular model.

TABLE OF CONTENTS

1 Getting To Know Your

Machine 3

View of the Machine 3

Technical Specications 4

2 Safety Instructions 4

Before Installation 4

Before First Use 4

Child Safety 4

For daily operation 5

Problems 5

What should not be washed

in your dishwasher 5

3 Directions for Assembly 6

Safety notes for installation 6

Installing Your Dishwasher 6

Water connection 7

Connect water inlet hose 7

Water drainage 8

Electrical connection 8

Disposal 8

4 Using Your Dishwasher 9

Filling the dishwasher salt 9

When operating for the rst time 10

Filling the Rinse Aid Dispenser 11

Filling the Detergent Dispenser 11

Detergent 12

Multipurpose Detergents 13

Loading the dishwasher 13

Suggestions for loading the

dishwasher 14

Loading suggestions 15

5 Program Selection and

Operating Your Machine 17

Button and Button Descriptions 18

Program Selection 18

Adding Functions to the Program 19

Program Steps Follow-up 19

Canceling a Program 19

Changing a Program 19

Programming the Delayed Start 20

Usage of Child Lock 20

Salt Indicator 21

Rinse Aid Indicator 21

Rinse Aid Indicator Setting 21

Starting Your Machine 21

6 How to clean your

dishwasher 24

Cleaning the lters 24

Cleaning the spray arms 25

7 Troubleshooting 26

What to do if the dishwasher

will not run 26

The cleaning results are

unsatisfactory 26

Service 32

3GB

1Getting To Know Your Machine

View of the Machine



























1. Upper dish basket with shelf

2. Guide rail for the upper dish

basket

3. Salt container

4. Cutlery basket

5. Detergent dispenser

6. Door

7. Control panel

8. Filters

9. Lower sprayer arm

10. Lower basket

11. Upper sprayer arm

12. Housing (depends on the model)

13. Turbo fan heat drying system

(depends on the model)

4GB

Technical Specications

Permitted water pressure: 0,3 –10

bar (= 3 – 100 N/cm² = 0,01-1,0Mpa)

Electrical connection: 220-240 Volts,

10 Amps (see type plate)

Output: 1900-2200 W

Heat output: 1800 W

This device corresponds to the

following EU directives:

2006/95/EC: Low Voltage Directive

2004/108/EC: EMV Directive

DIN EN 50242: Electrical dishwasher

for home use Testing procedures for

practical service conditions

Because we continually strive to

improve our products, we may change

our specications and designs without

prior notice.

Note for Testing Institutes

The necessary information for

performance testing will be provided

upon request. The request can be

done by e-mail through:

Please do not forget to write the model

code and stock code information of

the appliance besides your contact

information in the e-mail. The model

code and stock code information can

be found on the rating label, which is

placed on the side of the door.

2Safety Instructions

Before Installation

Check the appliance for transit

damage. Never install or use damaged

machines. If in doubt, contact your

supplier.

Before First Use

• See Notes for Installation on page

• Have the grounding system

installed by a qualied electrician.

The manufacturer cannot be held

liable for any damage caused by

operating the appliance without

proper grounding.

• Before operating the system,

please check that the information

on the type plate corresponds to

the information on your power

supply.

• The dishwasher must be

disconnected from the mains

during installation.

• The appliance must not be

connected to the mains using

an extension cable. Extension

cables do not provide the

necessary safety (e.g. danger of

overheating).

• Always use the original plug

delivered with the appliance.

• The plug must be freely accessible

after the appliance has been

installed.

Child Safety

• Do not allow children to play with

the appliance.

• Dishwasher detergents are caustic

and may cause injury to the eyes,

mouth and throat. Please note the

safety instructions provided by the

[email protected]

5GB

manufacturers of the detergents.

• Never leave children unsupervised

while the appliance is open, as

the appliance may still contain

detergent leftovers.

• The water in the dishwasher is not

drinking water. Danger of caustic

injuries.

• Always place long and sharp/

pointed objects (e.g. serving forks,

bread knives) into the cutlery

basket with the pointed end down

or at on the upper basket to avoid

possible injuries.

For daily operation

• Use your appliance only for the

following domestic uses: Washing

household dishes.

• Do not use chemical solvents in

the appliance; there is a danger of

explosion.

• Do not sit or stand on the opened

door or place other objects on it.

The appliance may tip over.

• Do not open the door while the

appliance is running, as hot water

or steam may escape.

• Do not leave the door open – an

open door can be a hazard.

Problems

• Repairs and modications to the

appliance may only be carried

out by qualied customer service

personnel.

• In the event of a problem, or

before performing a repair,

disconnect the appliance from the

mains supply:

- disconnect the appliance by

pulling out the mains plug

- shut off the power.

• Do not pull on the cable – pull on

the plug. Turn off the water supply

tap.

What should not be washed in

your dishwasher

• Rust sensitive steel parts

• Cutlery with wooden or horn

handles

• Cutlery with mother of pearl or

porcelain handles

• Non heat resistant plastic parts

• No glued dish or cutlery parts

• No items made out of copper, tin

or aluminium

• Sensitive decorative glasses and

porcelain parts

• Lead crystal glasses

• Art and crafted articles

• Aluminium and silver tend to

discolour

• Glass and crystal articles may lose

their shine over time

• Sponges and dishcloths

Note

Do not wash items soiled with cigarette

ash, candle wax, varnish, paints or

chemicals.

Recommendation:

When buying new dishes, note whether

they are suitable for the dishwasher.

(marked as dishwasher proof)

6GB

3Directions for Assembly

Safety notes for installation

Prior to installing and using your

appliance, please check it for possible

transit damage.

If the appliance is damaged, please

contact your supplier.

Never install or use a damaged

appliance.

The following directions must be

followed to connect the dishwasher

properly.

• Before operating your dishwasher,

please ensure that the information

on the type plate corresponds to

the current and voltage of your

power supply.

• The appliance may only be

connected using a properly

grounded socket. Ensure that the

appliance is grounded according

to regulations.

• The grounded socket must be

easily accessible and close to the

appliance.

• Do not use extension cables or

multiple adapters, as this can lead

to overheating, which can be a re

hazard.

• Hardwiring may only be carried out

by a qualied electrician.

• Check the power cable, the

water inlet hose and the drainage

hose. Damaged parts may only

be replaced by customer service

personnel or by a qualied

electrical service expert.

Installing Your Dishwasher

• Choose a suitable location for your

dishwasher. Take care to ensure

that the appliance is stable on a

level surface.

• Unevenness in the oor can be

equalised by adjusting the screw

feet. When the appliance is

standing correctly, the door can be

closed without difculty.

• Water inlet and drainage hoses

must be positioned so that they

can move freely without bending

or squeezing.

• The appliance may not be installed

in a room where the temperature

is below 0° Celsius.

7GB

tap with a ¾ inch external thread. If

required, use a lter insert to lter

deposits from the pipes.

Check that the connection does not

leak.

Important

For safety reasons, turn off the tap

after every rinse process.

Water connection

• There are two different types of

water inlet hoses:

- Cold water inlet hose (up to

25°C)

- Hot water inlet hose (up to

60°C)please check which one is

applicable to your model.

If you are willing to connect

your machine to natural

energy resources or to the central

hot water supply, rst check out

whether your water inlet hose

type is suitable by checking the

temperature values written on the

hose. If your hose is not suitable,

apply to your authorized service to

change the hose.

• The dishwasher may not be

connected to open warm water

devices or ow-through water

heaters.

Permitted water pressure:

Lowest permitted water pressure: 0.3

bars = 3 N/cm² = 30 kPa

When the water pressure is below 1

bar, please contact your technician.

Highest permitted water pressure: 10

bar = 100N/cm² = 1Mpa

When the water pressure is above 10

bars, a pressure reduction valve must

be installed (available in trade supply

stores).

Connect water inlet hose

Ensure that the water inlet hose is not

bent or squeezed. Do not install a used

hose set.

Use a screw-on hose connector to

connect the water inlet hose to a water

1009

aquAvoid™ plus (some models)

The aquAvoid™ plus System protects

against water damage hich may be

caused at the water inlet hose.

Do not immerse the system’s valve

box into water; it contains electrical

components.

In case of damage, pull out the power

supply plug.

Do not shorten or lengthen the hose

insert as it contains electrical cables

and components.

2550







8GB

Water drainage

Connecting the drainage hose.

Take care to ensure that the drainage

hose is not bent or squeezed.

Check that the drainage hose is rmly

seated.

1011

Extension hoses

If a hose extension is required, a

drainage hose of equal quality must be

used.

The maximum length must not exceed

4m. Using a longer hose will produce

poorer cleaning results.

Siphon connection

The drainage height must be between

50 and 100cm above the oor.

Use hose clamps to fasten the

drainage hose to the siphon.

Electrical connection

Please refer to the type plate for

information on current type, mains

voltage, and fuse protection.

The type plate is located on the inside

of the door.

The mains plug must be freely

accessible after installation.

Power cables and insulated cables

must not be accessible (exposed) after

installation.

Disposal

Packaging

The packaging and some parts of your

appliance are made from recyclable

materials. These materials are marked

with the recycling symbol and the

relevant material type (PE, PS, POM).

Before operating your appliance,

remove the packaging material and

dispose of it in accordance with

regulations.

          















9GB

salt do not dissolve in water easily and

will damage the softening device.”

Remove the lower basket from the

appliance.

Open the screw-in cap of the salt

container by turning it counter

clockwise (g. A,B).

4Using Your Dishwasher

Important

The electricity and water connections

of the dishwater must be in compliance

with the instructions in this booklet.

Filling the dishwasher salt

Important

Only use special dishwasher salt in

your appliance.The manufacturer is

not liable for damage resulting from the

use of the wrong type of salt.

Use Diswasher salt only. Moderate or

coarse grained and easily soluble salts

are recommended. Don’t use table

salt, or any other type, these types of

Warning

Packaging materials may be

dangerous to children.Reusable

substances may be dropped off at your

local disposal facilities. You may obtain

further information from your local

authorities and disposal facilities.

Used appliances –

Environmental notice

This product must not

be disposed of with your

regular household waste.

Instead, you need to dispose of the

waste equipment by handing it over

to a designated collection point for

the recycling of waste electrical

and electronic equipment. This is

indicated by a symbol to be found on

the product, it’s packaging or in the

manual.

Materials used are recyclable

according to their labelling. Reuse,

recycling of materials and further

reutilization of used products are

important contributions to protect our

environment.

Please ask your local town council for

the nearest collection point.

To avoid possible dangers, disable

your waste appliance prior to

discarding it. Pull the mains plug and

cut the power cord. Disable any door

locks.

Table des matières

Autres manuels Blomberg Lave-vaisselle

Blomberg

Blomberg LDVN2284 Manuel utilisateur

Blomberg

Blomberg DW 15110 NBLOO Manuel utilisateur

Blomberg

Blomberg DWT 52800 WIH Manuel utilisateur

Blomberg

Blomberg DWT 81800 SS Manuel utilisateur

Blomberg

Blomberg DWT 25502 B Manuel utilisateur

Blomberg

Blomberg DWT 57550 SS Manuel utilisateur

Blomberg

Blomberg DW14110 Manuel utilisateur

Blomberg

Blomberg DWT 59500 SS Manuel utilisateur

Blomberg

Blomberg DWT 59500 FBI Manuel utilisateur

Blomberg

Blomberg DIN26410 Manuel utilisateur

Blomberg

Blomberg GSN9123 Manuel utilisateur

Blomberg

Blomberg Dishwasher Manuel utilisateur

Blomberg

Blomberg Dishwasher Manuel utilisateur

Blomberg

Blomberg DW 14110 NBL00 Manuel utilisateur

Blomberg

Blomberg GSN 1580L Manuel utilisateur

Blomberg

Blomberg DWT 81900 FBI Manuel utilisateur

Blomberg

Blomberg GVN 9483 E Manuel utilisateur

Blomberg

Blomberg DWT34200 Manuel utilisateur

Blomberg

Blomberg DW 55502 FBI Manuel utilisateur

Blomberg

Blomberg DIT39432 Manuel utilisateur

Blomberg

Blomberg DWT 24100 SSP Manuel utilisateur

Blomberg

Blomberg LDFN2240W Manuel utilisateur

Blomberg

Blomberg GSN 1580 Manuel utilisateur

Blomberg

Blomberg GSN 1580 Manuel utilisateur

Manuels Lave-vaisselle populaires d'autres marques

Electrolux

Electrolux ESI5211LOX Manuel utilisateur

KitchenAid

KitchenAid KUDB230B Manuel utilisateur

Brandt

Brandt BDJ424DB Manuel utilisateur

Asko

Asko DSD767UXXL.AU Manuel utilisateur

Beko

Beko DFN26210W Manuel utilisateur

NEFF

NEFF S153ITX00E Fiche technique

Midea

Midea SV 4.45 wi Manuel utilisateur

LG LDF7932 Manuel utilisateur

Gorenje

Gorenje GV63214 Manuel utilisateur

Hotpoint

Hotpoint HDA1100ZWH Manuel de service

AEG

AEG FFB83836PM Manuel utilisateur

Cylinda

Cylinda DM3220RFD Manuel utilisateur

Atag

Atag DW8214MB Manuel utilisateur

GE GLD8000 Series Manuel utilisateur

Siemens

Siemens SN23HI02KE Fiche technique

Omega

Omega ODW717X Manuel utilisateur

BORETTI

BORETTI BVW-683 Manuel utilisateur

Siemens

Siemens SN 56N591 Manuel utilisateur
