Blitzz BWP712 Manuel utilisateur

Blitzz Super G Wireless – 108 Mbps 802.11g Notebook Adapter

any means without written permission from Blitzz Technology Inc.

Changes are periodically made to the information in this document. They will be

incorporated in subsequent editions. The supplier may make improvements and/or

changes in the product described in this document at any time.

Blitzz Super G Wireless – 108 Mbps 802.11g Notebook Adapter

Technical Support

Up-to-date information

Your newly purchased Blitzz product was created with the latest technology and designs.

However, we constantly modify and update the product features to keep you up to date

with the latest technologies through firmware or software upgrades. You can visit our

web site on www.blitzzusa.com to check if there is new software for your product.

Problem solving

If you have difficulty resolving problems in installation or have further technical

questions, you can go www.blitzzusa.com to look for the latest FAQ or contact us with

the following ways:

Web site: www.blitzzusa.com

Tech support: [email protected]

Toll Free: 1-888-4Blitzz (1-888-425-4899)

Sales: [email protected]

Blitzz Super G Wireless – 108 Mbps 802.11g Notebook Adapter

iii

Federal Communication Commission

Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one of the following

measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment.

This transmitter must not be co-located or operating in conjunction with any other

antenna or transmitter.

Blitzz Super G Wireless – 108 Mbps 802.11g Notebook Adapter

About this Manual

This User’s Manual describes how to install and operate your Blitzz Super G Wireless

LAN Card. Please read this manual before you install the product.

This manual includes the following topics:

 Product description and features.

 Hardware installation procedure.

 Software installation procedure.

 FAQ

Blitzz Super G Wireless – 108 Mbps 802.11g Notebook Adapter

Table of Contents

COPYRIGHT.................................................................................................................................................. I

TECHNICAL SUPPORT ............................................................................................................................... II

FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT....................................... III

ABOUT THIS MANUAL...............................................................................................................................IV

TABLE OF CONTENTS ...............................................................................................................................V

CHAPTER 1 INTRODUCTION................................................................................................................ 1

1.1 FEATURES ..................................................................................................................................... 1

1.2 WHAT IS WIRELESS LAN?.............................................................................................................. 2

1.3 WIRELESS LAN MODES ................................................................................................................. 2

1.4 NOTES ON WIRELESS LAN CONFIGURATION ................................................................................... 3

CHAPTER 2 HARDWARE INSTALLATION .......................................................................................... 4

2.1 PACKAGE CONTENTS ..................................................................................................................... 4

2.2 SYSTEM REQUIREMENTS FOR THE ADAPTER ................................................................................... 4

2.3 HARDWARE DESCRIPTION ............................................................................................................... 4

2.4 INSERTING THE WIRELESS LAN CARD ............................................................................................ 4

2.5 LED INDICATORS ........................................................................................................................... 5

2.6 EJECTING THE WIRELESS LAN CARD .............................................................................................. 5

CHAPTER 3 DRIVER INSTALLATION FOR WINDOWS ...................................................................... 7

3.1 DRIVER INSTALLATION FOR WINDOWS 98 SE ..................................................................................7

3.2 DRIVER INSTALLATION FOR WINDOWS 2000 .................................................................................. 10

3.3 DRIVER INSTALLATION FOR WINDOWS ME ..................................................................................... 13

3.4 DRIVER INSTALLATION FOR WINDOWS XP ..................................................................................... 15

CHAPTER 4 INSTALLING AND USING THE WIRELESS UTILITY ................................................... 17

4.1 INSTALLATION IN WINDOWS .......................................................................................................... 17

4.2 USING THE WINDOWS WIRELESS NETWORK UTILITY IN WINDOWS XP ............................................ 19

4.3 USING THE BLITZZ WIRELESS LAN UTILITY IN XP .......................................................................... 23

4.4 USING THE BLITZZ WIRELESS LAN UTILITY IN WINDOWS 98, 2000 AND ME ................................... 27

4.5 CONFIGURING THE BLITZZ 802.11G WIRELESS LAN CARD ............................................................ 29

4.5.1 Link Status: Connection Details.................................................................................... 29

4.5.2 Profiles.......................................................................................................................... 29

5.4.3 Site Monitor: Finding and connecting to wireless networks.......................................... 31

5.4.4 Wireless Security: WEP and WPA (WiFi-Protected Access) ....................................... 32

4.5.5 Information.................................................................................................................... 35

4.6 USING SUPER G MODE ................................................................................................................ 36

CHAPTER 5 INSTALLING NETWORK PROTOCOLS ........................................................................ 37

5.1 INSTALLING THE NETWORK PROTOCOLS FOR WINDOWS 98 AND MILLENNIUM ................................. 37

APPENDIX A GLOSSARY................................................................................................................. 40

APPENDIX B FAQ ............................................................................................................................. 44

APPENDIX C SPECIFICATIONS....................................................................................................... 45

Blitzz Super G Wireless – 108 Mbps 802.11g Notebook Adapter

Chapter 1 Introduction

Thank you for purchasing the Blitzz Super G CardBus Wireless LAN Card

(BWP712). This high-speed CardBus Wireless LAN Card provides you with an innovative

wireless networking solution. The Adapter is easy to set up and use. With this

innovative wireless technology, you can share files and printers on the network—

without inconvenient wires!

The Adapter is a network adapter with a rate of 1, 2, 5.5, 11, 12, 18, 24, 36, 48

and 54 Mbps operating in the ISM band using Direct Sequence Spread Spectrum (DSSS)

transmission implementing the IEEE 802.11g standard. This Adapter provides Device

Drivers for Windows Operating Systems. It also provides tools for the configuration of

the Adapter. The tool, as well as the installation steps of the plug-and-play procedure

for the Windows operating systems, is described in this document.

The Adapter uses Super G Technology that allows speeds up to 108 Mbps when

used with our BWA711 Super G Wireless Router in Super G mode.

Blitzz Super G Wireless is driven by Atheros Communications, Inc.

1.1 Features

The CardBus Wireless LAN Card offers compliance with the IEEE 802.11 b and g

specifications. This feature allows them to communicate with other wireless devices that

support the standard. Features of the Adapter are:

 Uses 2.4GHz frequency band, which complies with worldwide

requirements.

 Wireless interface following the IEEE 802.11b standard.

 Using CardBus interface.

 Enciphering/deciphering of wireless data by the implementation of the

WEP algorithm. Also has support for WPA PSK and RADIUS with AES and TKIP

encryption.

 Wire-free access to networked resources from anywhere beyond the

Notebook.

 Allows users move between Access Points without resetting their

connection configuration.

 Delivers data rate up to 54 Mbps and 108 when used in Super G mode

 Supports 108, 54, 48, 36, 24, 18, 12, 11, 5.5, 2, and 1 Mbps rates

 Provide CardBus Wireless LAN Card Configuration utility

 The Adapter uses external Antenna with LEDs indicating Power and Link

 Supports most popular operating systems

Blitzz Super G Wireless – 108 Mbps 802.11g Notebook Adapter

1.2 What is Wireless LAN?

Wireless Local Area Network (WLAN) systems offer a great number of

advantages over traditional wired systems. WLAN is flexible and easy to setup and

manage. They are also more economical than wired LAN systems.

Using radio frequency (RF) technology, WLAN transmit and receive data through

the air. WLAN combine data connectivity with user mobility. For example, users can

roam from a conference room to their office without being disconnected from the LAN.

Using WLAN, users can conveniently access-shared information, and network

administrators can configure and augment networks without installing or moving

network cables.

WLAN technology provides users with many convenient and cost saving features:

• Mobility: WLAN provide LAN users with access to real-time information

anywhere in their organization, providing service opportunities that are

impossible with wired networks.

• Ease of Installation: Installing is easy for novice and expert users alike,

eliminating the need to install network cables in walls and ceilings.

• Scalability: WLAN can be configured in a variety of topologies to adapt to

specific applications and installations. Configurations are easily changed and

range from peer-to-peer networks suitable for a small number of users to full

infrastructure networks of thousands of users roaming over a broad area.

1.3 Wireless LAN Modes

Wireless LANs can be configured in one of two ways:

Ad-hoc Networking

Also known as a peer-to-peer network, an ad-hoc network is one that allows all

workstations and computers in the network to act as servers to all other users on

the network. Users on the network can share files, print to a shared printer, and

access the Internet with a shared modem. However, with ad-hoc networking,

users can only communicate with other wireless LAN computers that are in the

wireless LAN workgroup, and are within range.

Infrastructure Networking

Infrastructure networking differs from ad-hoc networking in that it includes an

access point. Unlike the ad-hoc structure where users on the LAN contend the

shared bandwidth, on an infrastructure network the access point can manage the

bandwidth to maximize bandwidth utilization. Additionally, the access point

enables users on a wireless LAN to access an existing wired network, allowing

wireless users to take advantage of the wired networks resources, such as

Internet, email, file transfer, and printer sharing. Infrastructure networking has

the following advantages over ad-hoc networking:

• Extended range: each wireless LAN computer within the range of the

access point can communicate with other wireless LAN computers within

range of the access point.

Blitzz Super G Wireless – 108 Mbps 802.11g Notebook Adapter

• Roaming: the access point enables a wireless LAN computer to move

through a building and still be connected to the LAN.

• Wired to wireless LAN connectivity: the access point bridges the gap

between wireless LANs and their wired counterparts.

1.4 Notes on Wireless LAN Configuration

When configuring a wireless LAN (WLAN), be sure to note the following points:

• Optimize the performance of the WLAN by ensuring that the distance between

access points is not too far. In most buildings, WLAN Adapters operate within a

range of 100 ~ 300 feet, depending on the thickness and structure of the walls.

• Radio waves can pass through walls and glass but not metal. If there is

interference in transmitting through a wall, it may be that the wall has

reinforcing metal in its structure. Install another access point to circumvent this

problem.

• Floors usually have metal girders and metal reinforcing struts that interfere

with WLAN transmission.

This concludes the first chapter. The next chapter deals with the hardware installation

of the Adapter.

Blitzz Super G Wireless – 108 Mbps 802.11g Notebook Adapter

Chapter 2 Hardware Installation

This chapter covers connecting your CardBus Wireless LAN Card to CardBus slot

of notebook.

2.1 Package Contents

Please make sure that items below are included on package.

 One Wireless LAN Notebook Card

 One CD containing drivers and documentation

 One Quick Installation Guide

2.2 System Requirements for the Adapter

 Operating System: Microsoft Windows 98/ME/2000/XP

 Notebook with CD-ROM drive

 One free CardBus slot

 Pentium-Class 90MHz or higher

2.3 Hardware description

The Wireless LAN Card is encased in a stainless compact frame and has a 68-pin

connector for attaching to the CardBus port of notebook.

2.4 Inserting the Wireless LAN Card

Note!

These instructions apply to most notebook computers. For detailed information on

inserting PC cards into your notebook, consult the notebook manual.

Table des matières

Autres manuels Blitzz Adaptateur

Blitzz

Blitzz BWU613B Manuel utilisateur

Manuels Adaptateur populaires d'autres marques

PCB Piezotronics

PCB Piezotronics 090B274 Manuel utilisateur

Auvidea

Auvidea J20 Manuel du produit

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manuel utilisateur

Akribis

Akribis ITF-21-BISS-MIT Manuel utilisateur

Tenda

Tenda W54U Manuel utilisateur

ROHO

ROHO AGILITY Manuel utilisateur

PROLiNK

PROLiNK WN2001 Manuel utilisateur

Hawking

Hawking HUF2 Manuel utilisateur

Airlink101

Airlink101 AWLC4030 Manuel utilisateur

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manuel utilisateur

Philips

Philips SWA4554S/10 Manuel utilisateur

JVC

JVC TS-C9D2B Manuel d'instructions

NETGEAR

NETGEAR A6100 Manuel utilisateur

D-Link

D-Link DWA-121 Manuel utilisateur

Philips

Philips SWA2037 Manuel utilisateur

Basalte

Basalte 0610-20 Manuel utilisateur

Yealink

Yealink EHS40 Manuel utilisateur

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manuel utilisateur
