Blaupunkt BSB201S Manuel utilisateur
Instruction Manual
2.1ch Soundbar with Built-in Subwoofer - BSB201S
General Safety Instructions 4
Remote Control 7
Product Overview 9
Controls and Connections 10
First Time Setup 11
General Operations 12
Pairing your soundbar 13
Troubleshooting 14
Specifications 15
Specifications Last Page
CONTENTS
4
Read this manual thoroughly before you start using the Soundbar.
Store this manual, the completed warranty card, your receipt and the product packaging.
The safety precautions instructions reduces the risk of fire, electric shock and injury when
correctly complied to.
Please follow all instructions and take notice of all warnings.
• Only using furniture that can safely support the Products.
• Ensure the Product is not overhanging the edge of the supporting furniture.
• Do not place the product on a high furniture without securing both the furniture
and the product to a stable support.
• Do not place the product on cloth or other conductive materials.
• Warn children of the dangers of climbing on furniture to reach the soundbar
or its controls and to call for an adult to assist.
• Do not expose this product to rain or moisture as it may result in fire or an
electric shock hazard
• Do not temper or change or modify the product in any way.
• Only use Accessories outlined and recommended by the manufacturer.
• Please do not expose the product to splashing or water contact
• Please do not place any object on top of the product
IMPORTANT INFORMATION
GENERAL SAFETY INSTRUCTIONS
5
Please follow instruction when installing this product in accordance with the
instruction manual. This product must be positioned in a suciently stable
location, it can be potentially hazardous due to falling when mounted and can
cause injury, particularly to children if it positioned incorrectly.
• Before installing this Soundbar, make sure your outlet voltage corresponds to the
voltage stated on the power supply rating label
• The apparatus shall not be exposed to dripping or splashing and no objects filled
with liquids, such as vases, shall be placed on the product. Dry location use only.
• No naked flame source, such as candles, should be placed on the product.
• Ventilation should not be impeded by covering the ventilation openings.
• Do not plug several devices into the same outlet. Doing so may cause the outlet
to overheat and start a fire. Make sure the outlet is readily accessible during
operation of the equipment.
• No naked flame source, such as candles, should be placed on the product.
• Unplug the Soundbar during lightning storms or when unused for long periods of
time. Not doing so may result in fire or electric shock.
• Do not cover the ventilation openings of the product with items such as
newspapers, tablecloths, curtains etc. Do not insert objects into the slots
available on the products. As this could result in the product being damaged and
could cause a fire.
GENERAL SAFETY INSTRUCTIONS (Cont.)
6
GENERAL SAFETY INSTRUCTIONS (Cont.)
• If you notice any unusual odors or smoke around the unit, immediately disconnect the
unit from the outlet and contact the service center. Failure to do so may result in fire
or electric shock.
• When not using the unit for long periods of time or when you are moving the unit
please ensure to disconnect the power supply from the wall socket.
• Please beware that dust could accumulate over time on the unit and cause it to generate
heat and or deteriorate insulation, which in turn may result in an electrical fire.
• The product is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or young children of any age, They must be supervised
product by a person responsible for their safety.
• Batteries from the remote control must be only removed by an adult, the adult must
ensure to keep them out of reach of infants and children. Seek medical attention
immediately if a child has swallowed a battery.
• To maintain the product do not use any chemical or cleaning agent or wet cloth, please
only ensure to utilize a dry cloth to wipe it down from marks or dust and only after
unplugging the product from the power socket.
• Please ensure to contact our call center for any repair or service required for the products.
• Wall mounted installation must be carried out by a qualified personnel only.
Incorrect installation may result in severe personal injury, electric shock and/or fire hazard.
Please make sure upon positioning this product, the place is:
• Not wet or damp and Well ventilated
• Away from direct sunlight or heaters.
• Away from splashes or food.
• Protected from excessive dust or grease.
• Do not place this equipment in a confined space such as a bookcase or similar unit. Allow
20cm above and 5cm spacing on both sides for proper ventilation.
• Do not place the Soundbar near heat sources such as radiators, stoves or other audio
visual equipment that produce heat.
• Do not place containers with liquids, if liquid falls inside the products it may result in
short-circuit, fire or electric shock.
• Do not place small metallic objects on top of the unit.
• Do not use or store flammable or combustible materials near the unit. Doing so may
result in fire or explosion. Do not place any naked flame sources, such as lit candles,
cigarettes or incense sticks on top of the soundbar.
7
REMOTE CONTROL
• The remote control has a reception range of approximately 5m. Be sure to point
the remote control directly at the sensor at the front of the soundbar.
• Make sure there are no obstacles in the way. This will intefere with the sensor strength.
• Handle the remote control carefully, please do not drop, apply shock or step on it.
• Do not spill water on it.
• Using the remote control while operating other remote controls which use infra-red
rays near the unit as this will cause it to operate incorrectly.
• If you do not intend to use the remote control for a period of a month, remove the remote
control to prevent battery leakage or corrosion.
INCREASE
TREBLE
NEXT
VOLUME DOWN
INCREASE
BASS
DECREASE
TREBLE
VOLUME UP
PLAY / PAUSE
PREVIOUS
SONG
POWER ON
EQ MODES
DECREASE
BASS
MODE/MUTE
LONG PRESS to mute.
SHORT PRESS to change
input mode.
8
CAUTION!
Battery Precautions
• Do not use other batteries other than the one specified in this manual.
• Danger of explosion if incorrectly replaced by a battery other than the one specified.
• Do not store battery with other metallic objects, doing so can cause the battery to
short-circuit, leak or explode.
• Ensure the battery is not exposed to excessive heat, direct sunlight or fire.
• Do not try to short-circuit, disassemble or throw the battery into a fire.
• Dispose of batteries promptly and correctly, observing any local hazardous
waste regulations.
To insert new 2 x AAA batteries or replace current batteries, at the back of the remote
control remove the cover of the battery compartment and insert the 2 x AAA batteries
ensuring that the + sign on the battery is facing toward the + sign marked within the
battery compartment.
+
+
-
-
REMOTE CONTROL (Cont.)
9
PRODUCT OVERVIEW
1: SOURCE: SHORT PRESS TO POWER ON WHEN OFF, AFTER POWER
ON SHORT PRESS FOR FUNCTION CHANGE,
LONG PRESS TO TURN OFF.
2: VOL-: SHORT OR LONG PRESS FOR VOLUME DOWN;
3: VOL+: SHORT OR LONG PRESS FOR VOLUME UP;
4: PAIR: SHORT OR LONG PRESS BLUETOOTH PAIR;
5: DC IN
6: USB PORT
7: AUX IN (3.5MM)
8: OPTICAL IN
9: HDMI ARC
1 2 3 4
5 6 7 8 9
10
CONTROLS AND CONNECTIONS
HDMI
Connect a HDMI cable (not supplied) from your TV HDMI/ARC port to the HDMI socket on
the soundbar. Then change the mode on your soundbar to HDMI Mode.
Note: To enable the Audio Return Channel (ARC) feature, the HDMI must be connected to
an ARC enabled HDMI on your TV. (go to next page for details on ARC).
OPTICAL
Remove protective cap from the Optical socket on the soundbar and plug in the optical
cable (not supplied) from your Soundbar to the TV optical port.
Once connected, change the Mode to OPTICAL from the unit or remote control.
Note: If there is no sound and Optical light is flashing quickly, make sure that the audio
settings on your TV is set to appropriate mode.
This unit may not be able to decode all digital audio formats from the input source. In this
case, the unit will mute. This is NOT a defect. Ensure that the audio setting of the input
source (e.g. TV, game console, DVD player, etc.) is set to PCM or Dolby (Refer to the user
manual of the input source device for its audio setting details) with optical.
IMPORTANT INFORMATION
