INSTALLER TECHNICAL INFORMATION
Installation measurements
The product dimensions of this freestanding cooker are as follows:
895 W/L x 870- 940 H x 600 D mm
Please note that the stainless steel legs are adjustable from a height of 150 mm to 185 mm.
If the kick plate is placed on the freestanding cooker the product will require being at a height of 895
mm. This is the only way the kick plate will fit.
Please read this entire section to ensure that the cooker is installed safely and correctly and please
measure the actual product before cutting out for installation.
WARNING: TO BE INSTALLED BY AN AUTHORISED PERSON
WARNING: THIS APPLIANCE HAS BEEN DESIGNED FOR DOMESTIC USE ONLY
LOCAL AUTHORITY REQUIREMENTS
Check gas type and specifications plate placed on the bottom face of the unit. All gas fitting work,
service and repairs can only be performed by an authorized person and to local gas regulations.
Failure to comply with this condition will render the warranty invalid. Always unplug the appliance
before carrying out any maintenance operations or repairs. The walls of the units must not be higher
than work top and must be capable of resisting temperatures of 75’C above room temperature. Do
not install the appliance near flammable materials (e.g. curtains). The final act of any installation or
gas type conversion must be the full testing of this appliance, which includes leak testing, ignition of
each burner and the functionality of the burners separately and together.
WARNING: Keep all the dangerous packing parts (polystyrene foam, bags, cardboard, staples,
etc.) away from children.
WARNING: Young children should be supervised to ensure that they do not play with the
appliance.
INSTALLING THE APPLIANCE
The appliance can be installed as a freestanding unit, next to a wall at a distance of no less than
20mm (Fig.2, Class 1 Installation) or inserted between two walls (Fig.1, Class 2 Subclass 1
Installation). A single sidewall that exceeds the height of the work surface is possible. This must be
at a minimum distance of 70 mm from the edge of the cooker (Fig.2, Class 1 Installation).
WARNING: Where this appliance is installed in a Marine craft or in Caravans, it shall NOT be
used as a space heater.
WARNING: In order to prevent accidental tipping of the appliance, for example by a child
climbing on to the oven door, the stabilizing means must be installed according to these
instructions.
WARNING: DO NOT MODIFY THIS APPLIANCE.
WARNING: The appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a responsible
person for their safety.
