Programming
Select Total's Display Multiplier
This parameter displays the accumulated flow total in multiples of 10� For example, if the
optimum totalization unit is 1000 gallons, the unit total display increments by one digit
for every 1000 gallons monitored� In RUN mode, at 1000 gallons the total monitor reads 1,
at 3000 gallons, the total display reads 3� This feature eliminates having to look at a total,
count the digits, and mentally insert commas for each 1000 multiple�
At the TOTL MUL prompt, press ENTER� The monitor shows the current total multiplier� If the
current selection is correct, press ENTER to advance to the next parameter� To change to an
alternate multiplier, press UP or RIGHT to scroll to the correct multiplier unit� Press ENTER
to save and advance to the KFAC UNT parameter�
OTE:NIf pounds or kilograms were chosen as the RATE UNT or TOTL UNT, the monitor
advances to the SP GRAV parameter�
Specific Gravity
At the SP GRAV parameter, press ENTER� The first digit of the current specific gravity flashes�
If the current setting is correct, press ENTER to advance to the next parameter� To change
the current setting, press RIGHT to move to the correct digit� Press UP to increment the
digit� Repeat for all digits� Press ENTER to save and advance to the KFAC UNT parameter�
Enter Meter's K-Factor Unit
OTE:NThe K-factor supplied with the meter, or calculated from calibration data, is
needed to complete this step�
At the KFAC UNT prompt, press ENTER� The display shows the current K-factor unit� If the
current selection is correct, press ENTER to advance to the next parameter� To change
the K-factor, press UP or RIGHT to scroll to the correct K-factor� Press ENTER to save and
advance to the SCALE F parameter�
OTE:NFor meters calibrated in gallons, use PUL/GAL; for meters calibrated in cubic
meters, use PUL/M3 or any other unit option�
Scale Factor
The scale factor is used to force a global change to all variables� For example, under
operating conditions the display is reading a consistent three percent below the expected
values at all flow rates� Rather than changing all parameters individually, the scale factor is
used to compensate for the three percent offset� Set the scale factor to 1�03 to correct the
readings� The range of scale factors is 0�5…1�5� The default scale factor is 1�0�
At the SCALE F prompt, press ENTER� The first digit of the current scale factor flashes� If the
current selection is correct, press ENTER to advance to the next parameter� To change to an
alternate scale factor, press UP to increment the display digit until it matches the first digit
of the new scale factor� Press RIGHT to advance to the next digit� Repeat for all digits� Press
ENTER to save and advance to the METERTYP parameter�
