OWNER’S MANUAL

STARTER DISABLE/KEYLESS ENTRY

Congratulations on your purchase of your

vehicle security system.Your system is man-

ufactured in the U.S.A. and designed by lead-

ing security experts using the latest state of

the art technology.Your security system is

designed to give you trouble free operation

for years to come.The system includes an

LED, and override/valet switch, two remote

controls and the main control module.

Button 1 LED Button 2

2- Button

Transmitter

Arming Operation: To manually arm

the system. Press button one on the 2-

button remote.The LED will start slowly

flashing.The starter is now disabled.

Disarming Operation: Press button

one on the 2-button remote.The LED will

stop flashing.The starter is now engaged.

Illuminated Entry (Optional): Your

system can also turn on your interior

lights when you disarm your system for

30 seconds or until the ignition key is

turned on.

Car Locator Feature (Optional):

When you disarm your system, if your

parking lights are connected to the sys-

tem, the parking lights will flash twice and

then illuminate for 30 seconds or until the

ignition key is turned on.

Passive Arming: If your system is pro-

grammed to passive arm, the system will

automatically disable the starter 30 sec-

onds after the ignition has been turned

off. Once the ignition switch has been

turned off, the LED will start rapidly flash-

ing to let you know that in 30 seconds the

system will be engaged.

Valet Mode: Valet mode will keep your

alarm system from passive arming (if pro-

grammed to be passive arming), if you

need to have your vehicle serviced, or run

it through a car wash, etc.To put your

vehicle in Valet Mode, turn the ignition key

on and press and hold your valet/override

switch in for approximately 5 seconds.The

LED will turn on solid.Your vehicle’s sys-

tem is now in Valet Mode. If you have key-

less entry features or remote auxiliary

features, they will still operate. Deactivate

Valet Mode: It will stay in Valet until you

repeat the procedure and the LED will

turn off. Siren will chirp twice.

Valet Mode via the Remote: To put

the system in valet with your remote con-

trol, press button #2, then button #1 for 3

seconds and the system will enter the

valet mode.The LED will stay on solid. (If

optional siren or horn is connected, the

siren/horn will chirp 5 times).To exit the

valet mode, via remote, repeat the proce-

dure.The LED will go out and optional

siren/horn will chirp twice.

Remote Chirp Delete: If your system is

hooked up to the vehicle horn or the

siren, you can arm and disarm the system

without the arm/disarm chirps: Press but-

ton #2 momentarily then button #1 and

the system will arm or disarm silently.

Remote Panic: Pressing button #1 for 3

seconds will trigger the system into Panic

mode.The siren will sound and parking

lights will flash (optional).The Panic mode

will run 30 seconds, or you can shut it off

by pressing button #1 again.

Automatic Reset: If your system has

been triggered by shock sensor, door trig-

ger, or any other optional sensor or input,

the siren will sound and the lights will

flash (optional) for 45 seconds and then

reset.

Auxiliary #2: If your system is connect-

ed to auxiliary #2 feature (trunk or hatch

pop) use the feature by pressing and hold-

ing button #2 for 3 seconds and auxiliary

#2 feature will operate.

Horn or Siren Output (optional):

Your remote starter disabler system can

also be connected to your vehicle horn or

a siren.The horn/siren will give you confir-

mation chirps when you arm or disarm

the system.

Multi-Car Operation: Your remote will

control up to 3 systems. By teaching but-

ton #2 to a second system, it will allow

you to operate both vehicles with one

remote.To access a 3rd vehicle with the

2-button remote, you can program button

1 and 2 to the third vehicle.Auxiliary

channels 2 and 3 will not operate with

this remote; only arm and disarm func-

tions.

Overriding the System: If you have lost

your remote or it does not disarm the

system, you can manually override the sys-

tem by turning the ignition key to the ON

position and pressing and holding the

override/valet switch for 2 seconds.The

system will disarm and go into valet mode

automatically.

Code Learning Mode: Your system will

keep in memory codes for up to 3 differ-

ent remotes.To enter the code learning

mode: turn your key ON, OFF, ON, OFF

and ON (leave in the ON position).You

will hear a single chirp.Within 5 seconds

press in the valet/override switch and

hold.You will hear 3 chirps.Within 5 sec-

onds, press up to 3 different remote con-

trol buttons, that you desire to operate

the system. Note:When the system is in

the code learning mode, it will drop all

remotes that were previously pro-

grammed in the system.

LED Status Modes:

Valet = Solid

Armed Slow flash

Disarmed = Off

Pre Arm Passive = Rapid flash

Siren Chirp Modes:

Armed = Single chirp

Disarmed = Two chirps

Operating Override/Valet Switch:

Valet = Ignition switch on: Press override/

valet switch and hold for 5 seconds.

Disengage Valet = Repeat above process

Manual Override System = Ignition On

and press switch.

Code Learning = Turn ignition key Off & On

3 times (leave on the 3rd time), press and

hold override/valet switch for 5 seconds.

Keyless Entry (optional): Your system

may be connected to your central locking

system, so that when you arm your sys-

tem it will lock the doors remotely.The

system will also unlock your doors when

you disarm the system.
