BLACK STAR HT-DISTX Manuel utilisateur

HT-DISTX

PURE VALV E FILT H

Owner’s Manual

HBK-1004 05/10

Blackstar Amplification Ltd, Beckett House, 14 Billing Road, Northampton, NN1 5AW, UK

For the latest information go to: www.blackstaramps.com

The specifications and information in this publication are subject to change without prior notice.

All electrical and electronic products should be

disposed of separately from the municipal waste

stream via designated collection facilities appointed

by the government or the local authorities.

English

Warning!

Important safety information!

Read the following information carefully. Save all

instructions for future reference.

Danger! High internal operating voltages.

Do not open the equipment case. There are no user serviceable parts

in this equipment. Refer all servicing to qualied service personnel.

Unauthorised modication of this equipment is expressly forbidden by

Blackstar Amplication Limited.

Never push objects of any kind into ventilation slots on the equipment

casing.

Do not expose this apparatus to rain, liquids or moisture of any type.

Only use the correct Blackstar approved DC adapter supplied.

Unplug the DC adapter from the mains supply when not in use.

Introduction

Thank you for purchasing this Blackstar valve effects pedal. Like all

our products this pedal is the result of countless hours of painstaking

Research and Development by our world-class design team.

Based in Northampton (UK), the Blackstar team are all experienced

musicians themselves and the sole aim of the development process

is to provide guitarists with products which are the ultimate tools for

self expression.

All Blackstar products are subjected to extensive laboratory and

road testing to ensure that they are truly uncompromising in terms of

reliability, quality and above all TONE.

If you like what you hear and want to nd out more about the Blackstar

range of products please visit our website at www.blackstaramps.

com.

Thanks!

The Blackstar Team

Features

The HT-DISTX allows more tonal adjustment than any other pedal

around. The patented ISF (Innite Shape Feature) circuit gives you

innite adjustment over the characteristics of the tone control network

and takes you from the USA to the UK and anywhere in between. So

now, for the rst time, you can effectively design your own tone and

nally nd ‘the sound in your head’.

This pedal is designed to deliver the most aggressive high gain valve

tones that modern guitarists need and the high voltage valve design

means all the tones available are extremely dynamic and natural. A no

compromise speaker emulated output allows you to get your great

guitar tone straight to tape or disk.

Controls

1. Gain

The Gain control adjusts the amount of overdrive or distortion that the

pedal will deliver. As the Gain control is increased clockwise (CW) the

sound becomes more overdriven moving through crunch tones until,

at its maximum position, a full distorted lead tone is arrived at.

2. Bass

The Bass control adjusts the amount of low end frequencies in your

tone. This pedal has an advanced tone shaping circuit which allows

the tone to be tight and cutting, counter clockwise (CCW), to warm

and thumping (CW).

3. Middle

The Middle control adjusts the amount of middle frequencies in your

tone. The middle frequencies are particularly important in getting

the amount of ‘body’ your tone has. With the Middle control set to

its minimum position (fully CCW) the sound will be aggressive and

scooped, this is a tone ideal for aggressive rhythm playing. As the

Middle control is increased (CW) the amount of ‘body’ is increased,

which is more suitable for sustained lead guitar tones.

4. Treble

The Treble control allows exact adjustment of the treble frequencies

within the sound. At low settings (CCW) the sound will be warm and

darker in character. As the Treble control is increased (CW) the sound

will become brighter. At the maximum settings the sound will be

aggressive and cutting.

5. ISF (Innite Shape Feature)

The ISF control works in conjunction with the Bass, Middle and Treble

controls. It allows you to choose the exact tone signature you prefer.

Fully CCW is a more American characteristic with a tight bottom end

and more aggressive middle, and fully CW is a

British characteristic which is more ‘woody’ and less aggressive. See

illustration below.

100

ISF

Frequency

Amplitude USA UK USA UK

We recommend that to start with the ISF is set to half way and the

Bass, Middle and Treble are set to taste. Then try gradually adjusting

the ISF CW and CCW until you nd the sound you prefer.

6. Level

The Level control sets the overall level or volume from the pedal. It

should be used in conjunction with the Gain control to achieve the

exact type of drive you require. Generally speaking at lower Gain

settings the Volume will be increased and at higher Gain settings the

Volume should be decreased.

7. Output

This output is for connection to the input of your amplier or into other

pedals or effects. For best noise performance we recommend you

place the overdrive pedal rst in the effects chain. Always use a good

quality screened guitar lead.

8. Speaker Emulated Output

This output emulates the tonal characteristics of a guitar speaker

cabinet and provides a natural valve overdrive tone for connection

to a recording device or mixing desk. Always use a good quality

screened guitar lead.

9. Input

Plug your guitar in here. Always use a good quality screened guitar

lead.

English

10. Valve Viewing Window

Through this grille you can see the ECC83 valve at the heart of your

pedal.

WARNING: Do not attempt to remove the xing screws or grille. No

user serviceable parts inside.

11. Effect On/Off LED

When the RED LED is on the pedal is on. When the LED is not on

the pedal is off.

12. Effect On/Off Switch

Press this switch to turn the effect on or off.

13. DC Inlet

For the input of the 22V DC / 1.1A adapter supplied. Always use a

Blackstar approved adapter.

Technical Specication

Power: 22V DC

Maximum Current Draw: 1.1A

Controls: Gain, Bass, Middle, Treble, ISF, Level

Valve: ECC83 / 12AX7

Switches: On/Off Switch

Indicators: Effect On/Off, Power On/Off (Valve Backlight LED)

Jacks: Input, Output, Emulated Output

Input Impedance: 1MΩ

Output Impedance: < 1KΩ

Dimensions (mm): 160 x 119 x 80

Weight: 1.2kg

DC Adaptor: ADA Series supplied

TREBLEBASS MIDDLE ISFGAIN LEVEL

100100100100100100

PURE VALVE FILTH

HT-DISTX

113

2 3 4 5 6

English

HT-DISTX

PURE VALV E FILT H

Owner’s Manual

HBK-1004 05/10

Blackstar Amplification Ltd, Beckett House, 14 Billing Road, Northampton, NN1 5AW, UK

For the latest information go to: www.blackstaramps.com

The specifications and information in this publication are subject to change without prior notice.

Suggested Settings

TREBLEBASS MIDDLE ISFGAIN LEVEL

100 100 100 100 100 100

PURE VALVE FILTH

HT-DISTX

Classic Crunch

TREBLEBASS MIDDLE ISFGAIN LEVEL

100 100 100 100 100 100

PURE VALVE FILTH

HT-DISTX

British High Gain

TREBLEBASS MIDDLE ISFGAIN LEVEL

100 100 100 100 100 100

PURE VALVE FILTH

HT-DISTX

American High Gain

TONE TIP:

1. Start with ISF set to half way.

2. Adjust Bass, Middle and Treble to taste.

3. Gradually adjust ISF until you nd your sound.

ISF at ‘0’ is an American response and ISF at ‘10’ is a British response.
