Black Series ST1 Manuel utilisateur

ST1 SOFT TRIFOLD TONNEAU COVER

blackseriesauto.com

Scan QR code

to watch video

installation guide

Prior to vehicle operation,all four clamps must be

secured in the closed position.

Alternatively, both safety buckles must be fastened

to the front frame clips. Ensure clamps are secured

in the open folded position.

DO NOT drive with the cover in a partially open

position.

Black Series is not responsible for damage arising

from failure to follow instructions relating to the

product’s use.

Periodically check the clamps to ensure they are

secured to prevent possible operational failures.

WARNING

2ST1 SOFT TRIFOLD TONNEAU COVER

1x Soft Trifold Tonneau Cover

1x Spare Clamp

1x Weatherstrip Seal

4x Clamp Brackets

1x Hex Key

For Toyota

What’s In The Box

ST1 SOFT TRIFOLD TONNEAU COVER

Apply weatherstrip seal if your truck’s

front bed rail (bulkhead) is lower than

the side bed rails.

Ensure the surface is clean prior to

applying seal.

Place the cover on the front end of

the bed and center it.

Secure the front clamps.

1. Unclip the clamp from its storage position.

2. Slide the handle lever to the edge of the

truck bed rail.

3.Adjust to proper tension/height by rotating

the clamp.

Rotate clamp counterclockwise to tighten.

Rotate clamp clockwise to loosen.

For all clamps:

To adjust clamp tension/height:

Tonneau Cover Installation

ST1 SOFT TRIFOLD TONNEAU COVER

4. Pivot the lever from vertical to

horizontal position.

5. Hook the latch under the bed rail

lip/flange.

6. Push handle down to lock and

secure clamp.

Do not overtighten or forcefully clamp the latch.

Otherwise, the clamp rod may bend.

For Toyota

1. Slide the clamp brackets into

the utility track system.

2. Position each clamp bracket

underneath a clamp.

3. Secure each clamp bracket

with a hex key.

4. Attach clamps onto the clamp

bracket. See Step 3A.

ST1 SOFT TRIFOLD TONNEAU COVER

To use the cover in the open,folded position:

1. Release the rear clamps.

2. Stow and clip / tuck the clamps in

storage position.

3.Fold the cover forward.

4. Fasten both safety buckles to the front

frame clips.

Unbuckle the safety clips and unfold

the cover towards the tailgate.

Secure rear clamps. Repeat Step 3A.

Shut the tailgate.

Reposition the cover and readjust the

clamps if necessary.

ST1 SOFT TRIFOLD TONNEAU COVER

Black Series One (1) Year Limited Warranty

For Black Series Branded Product Only

IMPORTANT: BY USING YOUR BLACK SERIES PRODUCTS YOU ARE AGREEING TO BE BOUND BY THE TERMS OF THE BLACK SERIES ONE (1)

YEAR LIMITED WARRANTY (“WARRANTY”) AS SET OUT BELOW.

DO NOT USE YOUR PRODUCT UNTIL YOU HAVE READ THE TERMS OF THE WARRANTY. IF YOU DO NOT AGREE TO THE TERMS OF THE

WARRANTY, DO NOT USE THE PRODUCT AND RETURN IT WITHIN THE RETURN PERIOD STATED IN BLACK SERIES’ OR RETAILER’S RETURN

POLICY WHERE YOU PURCHASED IT FOR A REFUND.

WHAT IS COVERED BY THIS WARRANTY?

Black Series warrants the Black Series branded hardware products and the Black Series branded accessories contained in the original packaging (‘Black

Series Product”) against defects in materials and workmanship when used normally in accordance with Black Series’ published guidelines for a period of

ONE (1) YEAR from the date of original retail purchase by the end-user purchaser (“Warranty Period”). Black Series’ published guidelines include but are

not limited to information contained in technical specifications,user manuals and service communications.Warranty is non-transferable.Proof of purchase

is required.

WHAT IS NOT COVERED BY THIS WARRANTY?

Black Series is not responsible for damage arising from failure to follow instructions relating to the Black Series’ Product use.

This Warranty does not apply:

(a) to consumable parts, such as rubber seals or protective coatings that are designed to diminish over time, unless failure has occurred due to a

defect in materials or workmanship;

(b) to cosmetic damage,including but not limited to scratches,dents and broken plastic unless failure has occurred due to a defect in materials or

workmanship;

(c) to damage caused by use with a third party products or accessories or components; (d) to damage caused by accident, abuse, misuse, fire,

liquid contact, earthquake or other external cause; (e) to damage caused by operating the Black Series Product outside Black Series’ published

guidelines;

(f) to damage caused by service performed by anyone who is not a representative of Black Series or a Black Series service provider;

(g) to a Black Series Product that has been modified to alter functionality or capability without the written permission of Black Series;

(h) to defects caused by normal wear and tear or otherwise due to the normal aging of the Black Series Product;

(i) if any serial number or SKU has been removed or defaced from the Black Series Product; or

(j) to damage caused by improper service or installation or removal of Black Series Product.

WHAT WILL BLACK SERIES DO IN THE EVENT THE WARRANTY IS BREACHED?

If during the Warranty Period you submit a claim to Black Series in accordance with this warranty, Black Series,will,at its option:

(i) repair the Black Series Product using new or previously used parts that are equivalent to new in performance and reliability,

(ii) replace the Black Series Product with the same model (or with your consent a product that has similar functionality) formed from new and/or previously

used parts that are equivalent to new in performance and reliability, or

(iii) exchange the Black Series Product for a refund of your purchase price.

Black Series may request that you replace certain user-installed parts or Black Series Products. A replacement part or Black Series Product, including a

user-installable part that has been installed in accordance with instructions provided by Black Series,assumes the remaining term of the Warranty or ninety

(90) days from the date of replacement or repair,whichever provides longer coverage for you.

HOW TO OBTAIN WARRANTY SERVICE?

Please contact a Black Series representative at blackseriesauto.com. A Black Series representative will help determine whether your Black Series Product

requires service and, if it does, will inform you how Black Series will provide it.

WARRANTY SERVICE OPTIONS

Black Series will provide warranty service through one or more of the following options:

(i) Carry-in service. You may return your Black Series Product to a Black Series retailer or Black Series service provider location offering carry-in service.

Service will be performed at the location.

(ii) Main-in service.If Black Series determines that your Black Series Product is eligible for mail-in service, Black Series will send you a prepaid label so that

you may ship your Black Series Product to a Black Series service provider. Instructions may be sent to you via email or in hard copy.

(iii) Do-it-yourself (DIY) part service.DIY parts service allows you to service your own Black Series Product. The following process may apply.

(a) Service where Black Series does not require return of the replaced Black Series Product or part. Black Series will ship you free of charge a replacement

Black Series Product or part accompanied by instructions on installation.
