Black Line BLK-PTZ36XIR Manuel utilisateur

BLK-PTZ36XIR High Resolution IR

36x Zoom Outdoor PTZ Camera

User Manual

Products: BLK-PTZ36XIR

Please read this manual before using your camera, and always follow the instructions for

safety and proper use. Save this manual for future reference.

BLK-PTZ36XIR_CM

1/21/15

REGULATORY NOTICE

FCC Information

FCC compliance: This equipment has been tested and found to comply with the limits for a digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may

cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be required to correct the interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

This product and - if applicable - the supplied accessories too are marked with “CE” and

comply therefore with the applicable harmonized European standards listed under the Low

Voltage Directive 2006/95/EC, the EMC Directive 2004/108/EC.

LEGAL NOTICE

Observint Technologies (Observint) products are designed to meet safety and performance standards with the use of

specic Observint authorized accessories. Observint disclaims liability associated with the use of non-Observint

authorized accessories.

The recording, transmission, or broadcast of any person’s voice without their consent or a court order is strictly

prohibited by law.

Observint makes no representations concerning the legality of certain product applications such as the making,

transmission, or recording of video and/or audio signals of others without their knowledge and/or consent. We

encourage you to check and comply with all applicable local, state, and federal laws and regulations before

engaging in any form of surveillance or any transmission of radio frequencies.

The BLACK Line is a trademark of Observint Technologies.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks

and names or their products. Observint disclaims any proprietary interest in trademarks and trade names other than

its own.

No part of this document may be reproduced or distributed in any form or by any means without the express written

permission of Observint

11000 N. Mopac Expressway, Building 300, Austin, TX 78759

For Sales and Support, please contact your distributor.

iii

36x PTZ IR Outdoor Camera User Manual

SAFETY WARNINGS AND CAUTIONS

Safety Warnings and Cautions

WARNING

!Hazardous Voltage may be present: Special measures and precautions must be taken when using this device.

Some potentials (voltages) on the device may present a hazard to the user. This device should only be used by those with

knowledge and training in working with these types of devices that contain live circuits.

WARNING

!Power Supply Hazardous Voltage: AC voltages are present within the power supply assembly. This device must be

connected to a UL approved, completely enclosed power supply, of the proper rated voltage and current. No user serviceable

parts inside the power supply.

WARNING

!Connect only to a properly earth grounded outlet. To avoid shock, ensure that all AC wiring is not exposed and that

the earth grounding is maintained. Ensure that any equipment to which this device will be attached is also connected to

properly wired grounded receptacles and are approved medical devices.

WARNING

Power Connect and Disconnect: The AC power supply cord is the main disconnect device to AC power. The socket outlet

must be installed near the equipment and must be readily accessible.

Installation and Maintenance: Do not connect/disconnect any cables to or perform installation/maintenance on this

device during an electrical storm.

WARNING

Power Cord Requirements: The connector that plugs into the wall outlet must be a grounding-type male plug designed

for use in your region. It must have certication marks showing certication by an agency in your region. The connector that

plugs into the AC receptacle on the power supply must be an IEC 320, sheet C13, female connector. See the following website

for more information http://kropla.com/electric2.htm.

WARNING

Lithium Battery: This device contains a Lithium Battery. There is a risk of explosion if the battery is replaced by an

incorrect type. Dispose of used batteries according to the vendor’s instructions and in accordance with local environmental

regulations.

Perchlorate Material: Special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate. This notice is

required by California Code of Regulations, Title 22, Division 4.5, Chapter 33: Best Management Practices for Perchlorate

Materials. This device includes a battery which contains perchlorate material.

SAFETY WARNINGS AND CAUTIONS

CAUTION



Management Practices for Perchlorate Materials. This device includes a battery which contains perchlorate material.

Electromagnetic Interference: This equipment has not been tested for compliance with emissions limits of FCC and

similar international regulations. This device is not, and may not be, oered for sale or lease, or sold, or leased until

authorization from the United States FCC or its equivalent in other countries has been obtained. Use of this equipment in a

residential location is prohibited. This equipment generates, uses and can radiate radio frequency energy which may result

in harmful interference to radio communications. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment on and o, the user is required to take measures to eliminate

the interference or discontinue the use of this equipment.

Warnings

• Use of the product only when in compliance with local electrical safety regulations.

• Use only the required power adapter. The standard power adapter is 24 Vac / 2 A.

• Do not connect additional devices to the power adapter. Doing so may over-heat the device and cause a re hazard.

• Always make sure that the power adapter plug is fully inserted into the power socket.

• When the product is installed on a wall or ceiling, it must be securely attached.

• If the camera emits smoke, odors or noise power it o immediately and unplug the power cable. Contact the service center.

• If the camera does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble

the camera yourself. (Your provider is not responsibility for problems caused by unauthorized repair or maintenance.)

Cautions

• Do not drop the dome or subject it to physical shock. Do not expose it to high levels of electromagnetic radiation.

• Do not install the camera on surfaces that are subject to vibrations or shock.

• Do not place the camera in extremely hot, cold (operating temperature range: -22 °F ~ 149 °F (-30 °C ~ +65°C)),

dusty or damp locations. Fire or electrical shock can occur.

• Exposing the equipment to direct sunlight, low ventilation or heat sources such as heater or radiator should be avoided.

• Do not aim the camera at the sun or extra bright places. A blooming or smear may occur (which is not a malfunction however),

and aect the longevity of CCD.

• Use the glove provided when opening the dome cover. Do not touch the dome cover; the acidic moisture on skin can erode the

surface coating.

• Please use a soft and dry cloth when cleaning the inside and outside surfaces of the dome cover. Do not use alkaline

detergents.

36x PTZ IR Outdoor Camera User Manual

PREPARATION FOR INSTALLATION

Preparation for Installation

• Basic requirements:

—All the electronic operations must be compliant with local electrical safety regulations, re prevention regulations and

other related regulations.

—Verify that all accessories are included with your shipment.

—Make sure that the camera is suitable for the location and security requirements where it will be installed. If not, please

contact the supplier.

—Always use this product in accordance with the manufactures specications and recommendations.

• Check installation space. Make sure the place have enough space to install the camera and its accessories.

• Check the intensity of conformation at the installation location. Please make sure that the ceilings or walls are strong enough to

withstand four times the weight of camera and its accessories.

• Preparation of cables:

—Choose video cable in accordance with the transmission distance. The video should meet the least demands as: 75 Ω

resistance; 100% copper core conducting wire; 95% weaving copper shield.

—For RS-485 communication cable, please refer to Appendix B.

—For 24 Vac power cabling, please refer to Appendix C.

• Keep packaging for possible future use. If a failure occurs, return the product to the factory with the original packaging.

Shipment without the original packaging may damage the product and incur additional costs.

TABLE OF CONTENTS

Table of Contents

SECTION 1 Introduction .......................................................................1

1.1 Features ............................................................................1

1.2 Accessories..........................................................................4

SECTION 2 Installation ........................................................................8

2.1 Setup the camera address and baud rate DIP switches .....................................8

2.2 Camera wall mount installation .......................................................10

2.3 Connecting the cables ...............................................................12

SECTION 3 Getting Started ....................................................................14

3.1 Power-up initial display..............................................................14

3.1.1 Basic operations................................................................15

3.2 System-dened Presets .............................................................15

3.2.1 Manchester code control protocols ................................................16

3.3 On Screen Displays ..................................................................16

SECTION 4 Using the OSD Menus ...............................................................17

4.1 Accessing and operating the menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

4.2 Conguring System Information ......................................................19

4.2.1 Checking System Information ....................................................19

4.2.2 Conguring system parameters...................................................19

4.2.3 System time conguration .......................................................22

4.2.4 Display the PTZ movements, system time, fan/heat, etc...............................22

4.2.5 IR parameter conguration ......................................................23

4.3 Conguring Image Parameters........................................................25

4.3.1 TASK 1. Congure the focus settings ...............................................25

4.3.2 TASK 2. Congure the zoom settings...............................................26

4.3.3 TASK 3: Congure the Day/Night mode ............................................26

4.3.4 TASK 4: Congure the sharpness level..............................................27

4.3.5 Task 5: Congure the BLC and WDR ...............................................27

4.3.6 TASK 6. Congure iris, gain and shutter speed.......................................27

4.3.7 TASK 8: Congure white balance ..................................................28

4.3.8 TASK 9: Congure the image ip ..................................................29

4.3.9 TASK 10: Congure the INIT LENS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

4.3.10 TASK 11: Congure noise reduction................................................29

4.3.11 TASK 12: Congure the image quality..............................................29

vii

36x PTZ IR Outdoor Camera User Manual

TABLE OF CONTENTS

4.3.12 Conguring Privacy Mask ........................................................29

4.4 Conguring PTZ control parameters....................................................31

4.4.1 Conguring PTZ parameters......................................................31

4.5 Conguring Presets .................................................................33

4.5.1 TASK 1: Set a preset .............................................................33

4.5.2 TASK 3: Call the presets..........................................................34

4.5.3 TASK 2: Clear the preset settings ..................................................34

4.6 Conguring Patrols..................................................................34

4.6.1 TASK 1: Set a patrol .............................................................34

4.6.2 TASK 2: Preview the patrol .......................................................36

4.6.3 TASK 3: Delete a patrol ..........................................................36

4.6.4 TASK 4: Call the dened patrol ...................................................36

4.6.5 Set the dwell time when running a fast patrol ......................................37

4.7 Conguring Patterns ................................................................37

4.7.1 TASK 1: Set a pattern ............................................................37

4.7.2 TASK 2: Preview a pattern........................................................38

4.7.3 TASK 3: Call the dened pattern. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

4.7.4 TASK 4: Delete patterns..........................................................38

4.8 Conguring Time Tasks...............................................................39

4.8.1 TASK 1: Set time tasks ...........................................................39

4.8.2 TASK 2: Delete the task. .........................................................40

4.9 Conguring Zones...................................................................40

4.9.1 TASK 1: Set a zone...............................................................41

4.9.2 Clearing PTZ Control Settings.....................................................42

4.9.3 Using the DIAGNOSTICS display ...................................................42

4.10 Others.............................................................................43

4.10.1 Conguring dome authentication .................................................43

4.10.2 Restoring default dome settings ..................................................44

4.10.3 Restoring camera default settings.................................................45

4.10.4 Rebooting the camera...........................................................45

SECTION 5 Specications .....................................................................46

APPENDIX A Lightning and Surge Protection ......................................................48

APPENDIX B RS-485 Bus Connection .............................................................49

APPENDIX C 24 Vac Wire Gauge and Transmission Distance ..........................................52

viii

36x PTZ IR Outdoor Camera User Manual

SECTION 1: INTRODUCTION

SECTION 1

Introduction

The BLACK Line™ 700 TVL 36x zoom outdoor PTZ camera enables you to pan, tilt and zoom in on activity both near and far, and

features high-powered 320’ IR LEDs to capture high-resolution video day and night. The PTZ camera has an extreme operating

temperature range of -22° F ~ 149° F that is ideal for capturing video in cold climates and an IP66 weather rated enclosure

to withstand a variety of elements and weather conditions. The camera also features privacy zone masking and back light

compensation (BLC) 256x sense up.

1.1 Features

Special features of the camera include:

• Delivers 700 TV lines of resolution (color) 750 TV lines (B/W)

• 1/4” Sony 960H CCD image sensor

• 36x optical zoom, 16x digital zoom

• Long range 320’ IR

• Enhanced imaging with D-WDR and 3D-DNR

• True day/night (ICR) to capture sharp, detailed images day and night

• 360° endless pan range, -55° ~ -90° tilt range, 0.1°/s ~ 240°/s pan speed and 0.1°/s ~ 120°/s tilt speed

• Extreme operating temperature: -22 °F ~ 149 °F

• IP66 weather rated

• TVS 4,000V lightning/surge protection

OSD (on-screen display)

The on-screen display is a text image superimposed on video. The text displays status information and conguration menus.

Self-adaptive Protocol

The camera is compatible with PELCO-D, PELCO-P, PRIVATE-Code, VICON and KALATEL-312 protocols, etc., and is capable of being

self-adaptive to these protocols without selecting protocol by DIP switch settings.

Keyboard Control

The pan/tilt movement and zoom actions of camera can be controlled by the control keyboard, DVR, matrix, etc.

Limit Stops

The dome can be programmed to move within the limit stops (left/right, up/down) which are congurable by the control keyboard,

DVR or client application software.

SECTION 1: INTRODUCTION

Scan Modes

The dome provides 5 scanning modes: pan scanning, tilt scanning, frame scanning, random scanning and panorama scanning.

Preset Freezing

This feature freezes the scene on the monitor when moving to a preset. This allows for smooth transition from one preset scene to

another and also guarantees that masked areas will not be revealed when moving to a preset.

Presets

Each of the user-denable presets can be programmed to use pan, tilt, camera settings and other settings. When a preset is called,

the dome will automatically move to the dened position. The user can add, modify, delete and call each preset.

Label Display

The on-screen label of the preset title, PT display, zoom, and time can be displayed on the monitor.

Auto Flip

In manual tracking mode, when a target object moves directly beneath the dome, the dome will automatically rotate 180 degrees

in the horizontal direction to maintain continuity of tracking.

Privacy Mask

The privacy mask allows the user to dene areas of the eld of view that cannot be seen by the operator of the camera. A masked

area will move with pan and tilt functions and automatically adjust in size when the lens zoom changes.

3D Positioning

The camera can be controlled with a mouse and the PRIVATE-Code protocol. Clicking a spot can direct the camera position the spot

in the center of the image. When a rectangular area is selected with the left mouse button, the camera will move to its center and

enlarge it. Right click the mouse to zoom in. The scroll wheel can control lens zoom. Mouse cursor movement can also control zoom

eects.

Proportional Pan/Tilt

Proportional pan/tilt automatically reduces or increases the pan and tilt speeds in proportion to the amount of zoom. At telephoto

zoom settings, the pan and tilt speeds are slower than at wide zoom settings. This keeps the image from moving too fast on the

monitor when there is a large amount of zoom.

Auto Focus

Auto focus enables the camera to focus automatically to maintain clear video images.

Day/Night Auto-switch

The camera provides color images during the day. As light diminishes at night, it switches to night mode and delivers black and

white images with high quality.
