BLACK DECKER FSMH1321 Manuel utilisateur
www.blackanddecker.com.au
www.blackanddecker.co.nz
2
1
12
11
3 4
5
7
9
10
6
8
12a
FSMH1321
BHSM166DSM
BHSM168D
BHSM168DSM
BHSM168U
BHSM169DSM
BHSM1610DSM
BHSM1615DSM
BHSM1615DSG
BHSM1615DAM
23
English (original instructions) 7
23
12a 12c
12b
5
10
11
11a
8
11
12
13
14
7
9
15
6
A B
C D
E F
45
5
16
25
17
19
20
21
22
22a
24
27
18
22b
22c
23
21a
18a
20a
16a
12d
28
29
26
G
45
18
17
20
19
22
22a
22c
22b
H
I
26 24
24
26
26a 24a
J
67
OFF
2
4
K L
MN
OP
67
uDo not leave the appliance connected
to an electrical outlet when not in use.
uNever pull the power lead to
disconnect the appliance from the
socket. Keep the appliance lead away
from heat, oil and sharp edges.
uDo not handle steam cleaner with wet
hands.
uDo not pull or carry by cord, use cord
as a handle, close door on cord, pull
cord around sharp corners or expose
cord to heated surfaces.
uDo not use appliance in an enclosed
spacelledwithvapourgivenoffby
oil-base paint thinner, some
mothproongsubstances,ammable
dust, or other explosive or toxic
vapours.
uCheckthetypeofoorwiththe
manufacturer.
uDo not use on leather, wax polished
furnitureoroors,syntheticfabrics,
velvet or other delicate, steam
sensitive materials.
@
Warning! Do not use on
unsealed wood or unsealed
laminateoors.Onsurfacesthat
have been treated with wax or
somenowaxoors,thesheen
may be removed by the heat
and steam action. It is always
recommended to test an isolated
area of the surface to be
cleaned before proceeding. We
also recommend that you check
the use and care instructions
fromtheoormanufacturer.
Intended use
Your BLACK+DECKERTM FSMH1321,BHSM166DSM,
BHSM168D, BHSM168DSM, BHSM168U, BHSM169DSM,
BHSM1610DSM, BHSM1615DSM, BHSM1615DSG,
BHSM1615DAM steam mop has been designed for sanitising
and cleaning sealed hardwood, sealed laminate, linoleum,
vinyl,ceramictile,stoneandmarbleoors.Thisapplianceis
intended for indoor household use only.
Safety Instructions
Warning! Read all safety
warnings and all instructions.
Failure to follow the warnings
and instructions listed below
mayresultinelectricshock,re
and/or serious injury.
@
Warning! When using
mains-powered appliances,
basic safety precautions,
including the following, should
always be followed to reduce
theriskofre,electricshock,
personal injury and material
damage.
uThe intended use is described in this
manual.
uThe use of any accessory or
attachment or the performance of any
operation with this appliance other
than those recommended in this
instruction manual may present a risk
of personal injury.
uRetain this manual for future
reference.
Using your appliance
uDo not direct steam at people,
animals, electrical appliances or
electrical outlets.
uDo not expose to rain.
uDo not immerse the appliance in water.
uDo not leave the applianceunattended.
8
ENGLISH (Original instructions)
9
ENGLISH
(Original instructions)
uNever put descaling, aromatic,
alcoholic or detergent products into the
steam cleaner, as this may damage it
or make it unsafe for use.
uIf the home circuit breaker activates
while using the steam function,
discontinue product use immediately
and contact the customer support
centre. (Beware of the risk of electrical
shock.)
uThe appliance emits very hot steam to
sanitize the area of use. This means
that the steam head, cleaning pads
and carpet attachment get very hot
during use.
Caution! Always wear suitable shoes
when using your steam mop and when
changing the accessories on your steam
mop. Do not wear slippers or open toed
footwear.
uThe lid may become hot during use.
uSteam may escape from the appliance
during use.
Care should be taken when using this
appliance.DONOTtouchanyparts
which may become hot during use.
uSwitch the appliance off and return the
handle to the upright position before
removing the water tank.
uIf steam is observed escaping from the
body of the hand held steam cleaner,
switch off and disconnect the unit
from the mains supply, allow to cool.
Contact your nearest authorised repair
agent. Do not continue to use the
appliance.
After use
uUnplug the appliance and allow to cool
before cleaning.
uWhen not in use, the appliance should
be stored in a dry place.
uChildren should not have access to
stored appliances.
Inspection and repairs
uUnplug the appliance and allow to cool
before performing any maintenance or
repairs.
uBefore use, check the appliance for
damaged or defective parts. Check for
breakage of parts, damage to switches
and any other conditions that may
affect its operation.
uRegularly check the power lead for
damage.
uDo not use the appliance if any part is
damaged or defective.
uHave any damaged or defective parts
repaired or replaced by an authorized
repair agent.
uNever attempt to remove or replace
anypartsotherthanthosespeciedin
this manual.
Safety of others
uThis appliance can be used by
persons with reduced physical,
sensory or mental capabilities or
lack of experience and knowledge
if they have been given supervision
or instruction concerning use of
the appliance in a safe way and
understand the hazards involved.
Children shall not play with the
appliance.
8
ENGLISH (Original instructions)
9
ENGLISH
(Original instructions)
uChildren should be supervised to
ensure that they do not play with the
appliance.
uThe plug must be removed from
the socket-outlet before cleaning or
maintaining the appliance.
uThe liquid or steam must not be
directed towards equipment containing
electrical components, such as the
interior of ovens.
uThe appliance shall not be left
unattended while it is connected to the
supply mains.
uThe appliance is not to be used if it
has been dropped, if there are visible
signs of damage or it is leaking.
uKeep the appliance out of reach of
children when it is energized or cooling
down.
uNever point or direct the mitt at
yourself or any other person.
uCare should be taken when using
the appliance due to the emission of
steam
uUnplugtheapplianceduringllingand
cleaning.
uThe fabric steamer must not be left
unattended while it is connected to the
supply mains.
uThe fabric steamer is not to be used if
it has been dropped, if there are visible
signs of damage or if it is leaking.
ukeep the fabric steamer and its cord
out of reach of children less than 8
years of age when it is energized or
cooling down.
Residual risks
Additional residual risks may arise when
using the tool which may not be included
in the enclosed safety warnings. These
risks can arise from misuse, prolonged
use etc.
Even with the application of the
relevant safety regulations and the
implementation of safety devices, certain
residual risks can not be avoided. These
include:
uInjuries caused by touching any
moving parts.
uInjuries caused by touching any hot
parts.
uInjuries caused when changing any
parts or accessories.
uInjuries caused by prolonged use
of the appliance. When using any
appliance for prolonged periods
ensure you take regular breaks.
Electrical safety
@Warning! Warning! This product
must be earthed. Always check
that the power supply
corresponds to the voltage on
the rating plate.
Power plugs must match the outlet.
Never modify the plug in any way.
Unmodiedplugsandmatchingoutlets
will reduce risk of electric shock
uIf the supply cord is damaged, it must
be replaced by the manufacturer or an
authorised BLACK+DECKER Service
Centre in order to avoid a hazard.
10
ENGLISH (Original instructions)
11
ENGLISH
(Original instructions)
Extension cables & Class 1
product
uA 3-core cable must be used as your
appliance is earthed and of Class 1
construction.
uAlways use an approved extension
cable suitable for the power input of
this appliance (see technical data).
Up to 30m of 1.50mm2extension
cable can be used without loss of
product performance. Before use,
inspect the extension cable for signs
of damage, wear and ageing. Replace
the extension cable if damaged or
defective. When using a cable reel,
always unwind the cable completely.
Labels on appliance
The following pictograms along with the
date code may be shown on the
appliance.
CAUTION! Hot Steam
Water dripping when used
upside down
Steam escapes from all
sides
Do not leave unsuper-
vised with young children
Hand wash only
CAUTION! Hot surface
Features
This appliance includes some or all of the following features.
1. On/offswitch
2. AutoselectTM dial
3. Hand held steam unit handle
4. Filler cap
5. Hand held steam unit
6. Hand grip
7. Top cable tidy hook
8. Main handle
9. Bottom cable tidy hook
10. Hand held steam unit release button
11. Main body
12. Floor cleaning head
12a. Floor cleaning head with lift-out delta section
12b. Delta head
12c. Steam head removal tab
12d. Carpet glider (for use on carpets)
13. Floor cleaning pad
14. Floor cleaning pad release tab
15. Hanging Bracket
16. Steam hose
17. Steam nozzle
18. Angle brush accessory
(for use on hard to remove stains)
18a. Angle brush (wire brush)
19. Brush accessory
(for use on tiles / grout)
20. Squeegee accessory
(for use on shower screens / glass / mirrors / clothing /
upholstery)
20a. Squeegee sock
21. Large squeegee accessory
(for use on shower screens / glass / mirrors / clothing /
upholstery)
21a. Large squeegee sock
22. Steam burst brush unit
22a. Steam burst wire brush
( for use on BBQ / ovens)
22b. Steam burst brush
( for use on BBQ / ovens / oven hobs / taps / grout)
22c. Steam burst wide brush
(for use on larger work surfaces)
23. Delta head cleaning pad.
24. SteaMittTM
25. SteaMittTM hose
26. SteaMittTM cleaning pad
27. SteaMittTM cleaning pad 2
28. Ultra-absorbentoorcleaningpad
29. Large brush with built-in scraper
Autres manuels pour FSMH1321
4
Ce manuel convient aux modèles suivants
9
Table des matières
Autres manuels BLACK DECKER Nettoyeur à vapeur
BLACK DECKER
BLACK DECKER HGS100T Manuel utilisateur
BLACK DECKER
BLACK DECKER FSM13E1 Manuel utilisateur
BLACK DECKER
BLACK DECKER HGS100T Manuel utilisateur
BLACK DECKER
BLACK DECKER FSMH13E5 Manuel utilisateur
BLACK DECKER
BLACK DECKER HSMC1321 Manuel utilisateur
BLACK DECKER
BLACK DECKER FSMH1300FX Manuel utilisateur
BLACK DECKER
BLACK DECKER FSMH1300FX Manuel utilisateur
BLACK DECKER
BLACK DECKER HSM13E1 Manuel utilisateur
BLACK DECKER
BLACK DECKER FSMH1321 Manuel utilisateur
BLACK DECKER
BLACK DECKER BDSteam16 Manuel utilisateur
BLACK DECKER
BLACK DECKER FSM1640 Manuel utilisateur
BLACK DECKER
BLACK DECKER FSH10SM Manuel utilisateur
BLACK DECKER
BLACK DECKER HGS400-LA Manuel utilisateur
BLACK DECKER
BLACK DECKER FSMH13E5 Manuel utilisateur
BLACK DECKER
BLACK DECKER HGS011 Series Manuel utilisateur
BLACK DECKER
BLACK DECKER HGS250 Series Manuel utilisateur
BLACK DECKER
BLACK DECKER FSM1616 Manuel utilisateur
BLACK DECKER
BLACK DECKER FSH10SM Manuel utilisateur
BLACK DECKER
BLACK DECKER FSMH13151SM Manuel utilisateur
BLACK DECKER
BLACK DECKER FSM13E1 Manuel utilisateur
