Black Box LES302A Manuel utilisateur

LES302A quick start guide

BL A C K B OX®

Quick Start Guide

Access two serial RS-232 or RS-422/485 devices over a 10- or 100-Mbps

network.

2-Port 10/100 Device Server RS-232/422/485 DB9 M

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)

FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746

Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018

Web site: www.blackbox.com • E-mail: info@blackbox.com

Customer

Support

Information

LES302A

LES302A-KIT

LES302AE-KIT

724-746-5500 | blackbox.com

Page 2 LES302A quick start guide

This quick-start guide provides brief descriptions of the LES302A to help you get started. For detailed information, refer to the

user’s manual on the product CD.

QS.1. What’s Included

Your package should contain the following items. If anything is missing or damaged, contact Black Box Tech Support

at 724-746-5500 or info@blackbox.com.

LES302A-KIT or LES302AE-KIT:

• (1) Ethernet Serial Server

• (1) CD-ROM containing configuration utility and a user manual in PDF format

• (2) wallmounting screws

• Power adapter with 12-VDC, 1.75-A jack (PS012B [U.S.] or PS012BE [Europe])

• This printed quick-start guide

LES302A:

• (1) Ethernet Serial Server

• (1) CD-ROM containing configuration utility and a user manual in PDF format

• This printed quick-start guide

QS.2 Optional Accessories

• DIN Rail Kit (LES30X-DR)

• DB9 to TB5 Adapter (for RS-422 or RS-485) (LES30X-TB5)

QS.3 Hardware Setup

Interfaces

NOTES: The RS-232/422/485 interfaces do not support isolation.

Press the LES302A’s reset button to reset the settings to the default values.

Figure QS-1 shows the interface.

2-Port 10/100 Device Server RS-232/422/485 DB9 M Quick Start Guide

724-746-5500 | blackbox.com

Page 3

LES302A quick start guide

2-Port 10/100 Device Server RS-232/422/485 DB9 M Quick Start Guide

DIN rail

screw hole

Wallmount

screw hole

DC 9-30-V

Reset

button

RJ-45 10-/100-Mbps

Ethernet port

DB9 male serial ports

Figure QS-1. LES302A interface.

Indicators

Table QS-1 describes the indicators on the LES302A.

Table QS-1. LED indicators.

LAN LED Message Description

Off Ethernet disconnected

Blinking green Data is transmitted on Ethernet at 100 Mbps

Blinking orange Data is transmitted on Ethernet at 10 Mbps

COM Port LED Message Description

Off No data is transmitted on COM port

Blinking Data is transmitted on COM port

RUN LED Message Description

On Jumper JP1 Pin 1 and Pin 2 are shorted to disable AP firmware running

Blinking (rate: 0.5 sec.) AP firmware is running normally

724-746-5500 | blackbox.com

Page 4 LES302A quick start guide

2-Port 10/100 Device Server RS-232/422/485 DB9 M Quick Start Guide

Installation Steps (LES302A-KIT or LES302AE-KIT):

1. Connect an LES302A to the supplied power adapter (PS012B [U.S.] or PS102BE [Europe]).

2. Connect an LES302A to your Ethernet network. Use a standard straight-through Ethernet cable to connect it to a hub/switch.

Use a crossover cable to connect it to a PC’s Ethernet port.

NOTE: If you connect the PC to the LES302A, make sure that the PC is in the same subnetwork as the LES302A.

3. Connect the LES302A‘s serial ports to two serial devices.

NOTE: You may need an LES30X-TB5 adapter for RS-422 or RS-485 applications.

4. You can mount the LES302A to a wallplate (mounting screws are included) or a DIN rail using the DIN rail kit (LES30X-DR).

QS.4 Software Setup

Table QS-2. Software default settings.

Default Network Setting Default User Name/Password

IP: 10.0.50.100 User name: admin

Gateway: 10.0.0.254 Password: null (leave it blank)

Subnet: 255.255.0.0 —

Auto IP (Dynamic IP):

A DHCP server can automatically assign the IP address and network settings. The LES302A supports the DHCP function. By

default, the DHCP function on the LES302A is disabled. You can use SerialManager.exe to enable this function (see Figure QS-2).

Figure QS-2. SerialManager.exe utility Dialog window.

Assign a Static IP address by: Using Telnet, SerialManager.exe utility, or Web browser.

Using Telnet

1. Telnet to the LES302A using the DOS command “Telnet IP_address.” Example: telnet 10.0.50.100

2. The LES302A’s network, link mode, and COM ports settings can be configured in the Telnet window.

724-746-5500 | blackbox.com

Page 5

LES302A quick start guide

2-Port 10/100 Device Server RS-232/422/485 DB9 M Quick Start Guide

Using SerialManager.exe Utility

Use SerialManager.exe (included on the product CD) to automatically search for all LES302A units connected to your local area

network. Then select the desired LES302A to configure the network setting individually.

Using Web Browser

1. Make sure your PC is located on the same network subnet as LES302A.

2. Open a Web browser, then type in the IP address of the LES302A to be configured. The default user name is “admin” and the

default password is null (leave it blank).

3. The LES302A’s network, link mode, and COM port settings can be configured in different Web pages.

4. Click on “Save Configuration” to save settings.

5. Click on the ”Restart” button to make the change effective if necessary.

QS.5 Pin Assignments

The pin assignments of the DB9 connectors on LES302A are shown in the following table:

Table QS-3. DB9 connector pin assignments.

Number RS-232 Full-Duplex

2-Wire RS-485

Half-Duplex

RS-422/4-Wire RS-485

Full Duplex

1DCD N/A N/A

2RXD N/A (reserved) TXD+

3TXD DATA+ RXD+

4DTR N/A N/A

5SG (Signal Ground) SG (Signal Ground) SG (Signal Ground)

6DSR N/A N/A

7 RTS DATA- RXD-

8CTS N/A (reserved) TXD-

9N/A N/A N/A

NOTE: Use an LES30X-TB5 adapter for RS-422 and RS-485 applications.

724-746-5500 | blackbox.com

Page 6 LES302A quick start guide

2-Port 10/100 Device Server RS-232/422/485 DB9 M Quick Start Guide

The LES30X-TB5 terminal block pin assignments are shown in Table QS-4.

Table QS-4. Terminal block pin assignments.

Number

RS-422/4-Wire

RS-485

Full Duplex

2-Wire RS-485

Half-Duplex

1T+ Not connected

2T- Not connected

3R+ Data+

4R- Data-

5SG (Signal Ground) SG (Signal Ground)

724-746-5500 | blackbox.com

Page 7

LES302A quick start guide

NOTES

724-746-5500 | blackbox.com

BLACK BOX®

Black Box Tech Support: FREE! Live. 24/7.

Tech support the

way it should be.

Great tech support is just 30 seconds away at 724-746-5500 or blackbox.com.

LES302A Quick Start Guide, version 1
