Black Box 10VS Manuel utilisateur
10” Video Screen
Manual v1.2
Jan 2016
10” Video Screen Manual v1.2 Jan 2016
3
Contents
1. What is the 10VS............................................................................4
2. Features .........................................................................................4
3. In the Box.......................................................................................6
4. Setup Instructions..........................................................................7
4.1 Connect Speakers ....................................................................8
4.2 Connect Buttons ......................................................................8
4.3 Insert SD Card ..........................................................................8
5. Formats..........................................................................................9
5.1 Optimal Playback ...................................................................10
6. Remote Control ...........................................................................10
6.1 Remote Control Buttons........................................................11
6.2 Screen Settings ......................................................................11
7. Programming Content .................................................................12
8. Folder Volume Control ................................................................13
9. Automatic Power on/off..............................................................14
10. Slideshow Options .....................................................................15
11. Reformatting Instructions..........................................................16
Update Notes...................................................................................20
10” Video Screen Manual v1.2 Jan 2016
4
Thank you for purchasing the 10” Video Screen
The 10” Video Screen is one of a range of products we offer specific
to the heritage marketplace. We are confident that we have other
products you will find useful and look forward to dealing with you
again soon.
T: +44 (0)1639 767007 | W: www.blackboxav.co.uk
1. What is the 10VS
10VS is an all in one digital media player and screen. It’s used to
display and distribute media communication, videos and images in
a small compact manner. Thanks to the open frame design and
inbuilt mounting wings it can be built into signage or other such
installations. The 10VS supports a wide range of digital media files
which are stored on an SD card. A remote is also supplied for easy
player control; it can be looping or use up to 4 buttons to activate
content not including 2 volume buttons.
2. Features
Media Format Compatibility
Image:
Jpeg, BMP
Au
dio: MP3, WMA, AAC, OGG
Video:
MPEG-1, MPEG-2, AVI
Media Storage and Playback Source
High Speed Compact Flash (CF) Card
High Speed Secure Digital (SD) Card
USB 2.0 Drive (Thumb Drive/Flash Drive)
10” Video Screen Manual v1.2 Jan 2016
5
Playback Modes
Video
Audio
Picture with background
music
On-Screen Display Languages
English
Chinese
Japanese
Image Slideshow Playback
Picture Rotation
Portrait
-Vertical or Landscape-Horizontal
Slideshow Transitions
14 Different transition effects
Slide intervals: 1 to 60 seconds
If you need to reformat any files we recommend ‘Format Factory’.
This can be downloaded for free here:
http://www.pcfreetime.com/
See more in the ‘Reformating Instructions’ section.
10” Video Screen Manual v1.2 Jan 2016
6
3. In the Box
1. 10” Screen and Player
2. Speakers
3. Power Supply
4. Button Cables
5. Remote Control
6. SD Card
10” Video Screen Manual v1.2 Jan 2016
7
4. Setup Instructions
Left Side
Right Side
10” Video Screen Manual v1.2 Jan 2016
8
4.1 Connect Speakers
The 10VS is supplied with 2 mountable speakers attached via the
rear. There is also an audio out cable which can be connected on
the right side of the unit.
4.2 Connect Buttons
If you wish to use button activated content or allow user volume
control attach the required amount of buttons using the button
wires supplied to the appropriate button input as displayed below;
Note: illuminated buttons stay illuminated at all times
4.3 Insert SD Card
See Programming Instructions for information on how to program
your SD Card. Once programmed place it face down in the slot
located on the left of the 10VS as displayed below;
10” Video Screen Manual v1.2 Jan 2016
9
5. Formats
An SDHC Card is used as the storage medium for the 10VS. The card
must be formatted to FAT32.
Media Requirements
Before putting the content onto the SD Card it needs to be in the
right format as listed below, for reformatting instructions see
‘Reformatting’ section.
Video
Category
Format
Max Res
Max Bitrate
MP4
MP4/AVI
1920x1080
30fps
20Mbit/s
MPG/MPEG
MPG,MPE
1920x1080 30fps
20Mbit/s
MKV H.264
MPEG1,2,4
1920x1080 30fps
20Mbit/s
Sub Type
Codec
Max Res
Size
JPG
Baseline
YUV400
YUV420
YUV422
YUV440
YUV444
8000x8000 No Limit
Audio
Category
Codec
Sample Rate
Bitrate
MP2
MP3
PCM(wav)
AC3
WMA
MP2
MP3
PCM(wav)
AC3
WMA
8-320Khz
32Kbps
-
448kbps
10” Video Screen Manual v1.2 Jan 2016
10
5.1 Optimal Playback
Image Playback
For optimal image playback we recommend images be 1920x1080
pixels at 300DPI and saved as a jpeg.
Video Playback
For optimal video playback it is recommended that your video is
1920x1080 pixels and runs at a frame rate of 30 frames per second
in MP4 format.
Audio Playback
For optimal audio playback it is recommended that your audio file is
of MP3 format and has a bitrate of 44.1Khz.
6. Remote Control
A remote control is supplied with the 10VS, this enables you to set a
range of functions which are explained over the next pages.
To access the menu press the ‘Menu’ button
on the remote. Please note the IR sensor is
located on the rear base of the unit next to
the ‘power in’ cable.
To exit press the ‘Exit’ button.
10” Video Screen Manual v1.2 Jan 2016
11
6.1 Remote Control Buttons
POWER
MUTE
MENU
VOL+
VOL
-
Power on/off
Mute
/unmute audio
Next
item when playing
Previous
item when playing
Play
/Pause
Navigation
up/Pop up control menu when laying
Navigation
right
Navigation
left
Navigation
down
Enter
settings menu
Volume
up
Volume
down
Fast
-forward
Rewind
6.2 Screen Settings
If you would like to adjust the screen settings such as brightness,
contrast, colour or backlight you can adjust these here:
Menu > Screen Set >
