ENGLISH

(Original instructions)

Intended use

Your BLACK+DECKER DVJ215J, DVJ315J, DVJ320J,

DVJ325J, DVJ325BF and DVJ325BFS Dustbuster®hand-held

vacuum cleaners have been designed for vacuum cleaning

purposes. These appliances are intended for household use

only.

Read all of this manual carefully

before operating the appliance.

Safety instructions

@Warning! Read all safety

warnings and all instructions.

Failure to follow the warnings

and instructions listed below may

result in electric shock, re and/or

serious injury.

uThe intended use is described in this

manual. The use of any accessory

or attachment or the performance

of any operation with this appliance

other than those recommended in this

instruction manual may present a risk

of personal injury.

uRetain this manual for future

reference.

Using your appliance

uDo not use the appliance to pick up

liquids or any materials that could

catch re.

uDo not use the appliance near water.

uDo not immerse the appliance in water.

uNever pull the charger lead to

disconnect the charger from the

socket. Keep the charger lead away

from heat, oil and sharp edges.

uThis appliance can be used by

children aged from 8 years and above

and persons with reduced physical,

sensory or mental capabilities or

lack of experience and knowledge

if they have been given supervision

or instruction concerning use of

the appliance in a safe way and

understand the hazards involved.

Children shall not play with the

appliance. Cleaning and user

maintenance shall not be made by

children without supervision.

Inspection and repairs

Before use, check the appliance for

damaged or defective parts. Check for

breakage of parts, damage to switches

and any other conditions that may affect

its operation.

uDo not use the appliance if any part is

damaged or defective.

uHave any damaged or defective parts

repaired or replaced by an authorized

repair agent.

uRegularly check the charger lead for

damage. Replace the charger if the

lead is damaged or defective.

uNever attempt to remove or replace

any parts other than those specied in

this manual.

Additional safety instructions

After use

uUnplug the charger before cleaning the

charger or charging base.

uWhen not in use, the appliance should

be stored in a dry place.

uChildren should not have access to

stored appliances.

Residual risks

Additional residual risks may arise when

using the tool which may not be included

in the enclosed safety warnings. These

risks can arise from misuse, prolonged

use etc.

ENGLISH (Original instructions)

Even with the application of the relevant

safety regulations and the implementa-

tion of safety devices, certain residual

risks can not be avoided. These include:

uInjuries caused by touching any

rotating/moving parts.

uInjuries caused when changing any

parts, blades or accessories.

uInjuries caused by prolonged use

of a tool. When using any tool for

prolonged periods ensure you take

regular breaks.

uImpairment of hearing.

uHealth hazards caused by breathing

dust developed when using your

tool (example:- working with wood,

especially oak, beech and MDF.)

Chargers

Your charger has been designed for a

specic voltage. Always check that the

mains voltage corresponds to the voltage

on the rating plate.

Warning! Never attempt to replace the

charger unit with a regular mains plug.

uUse your BLACK+DECKER charger

only to charge the battery in the

appliance with which it was supplied.

Other batteries could burst, causing

personal injury and damage.

uNever attempt to charge non-

rechargeable batteries.

uIf the supply cord is damaged, it must

be replaced by the manufacturer or an

authorised BLACK+DECKER Service

Centre in order to avoid a hazard.

uDo not expose the charger to water.

uDo not open the charger.

uDo not probe the charger.

uThe appliance/battery must be

placed in a well ventilated area when

charging.

Electrical safety

Symbols on the charger

Read all of this manual carefully before using the

appliance.

#This tool is double insulated; therefore no earth wire

is required. Always check that the power supply

corresponds to the voltage on the rating plate.

wShort circuit proof safety isolating transformer. The

mains supply is electrically separated from the

transformer output.

xThe charger automatically shuts off if the ambient

temperature becomes too high. As a consequence

the charger will be inoperable. The charging base

must be disconnected from the mains supply and

taken to an authorised service centre for repair.

$The charging base is intended for indoor use only.

Labels on appliance

The following symbols appear on this appliance along with the

date code

+Read all of this manual carefully before

using the appliance

S010Q 14 Only use with charger S010Q 14

Features

This tool includes some or all of the following features.

1. On/off power switch

2. Handle

3. Nozzle

4. Pull out crevice tool

5. LED charging indicator

6. Dust bowl

7. Charging base

8. Flip down brush

9. Charger

Use

Switching on and off (Fig. A)

uPress the button to turn, on the unit operates in slow

speed, low power mode, conserving the battery life.

uPress the button again, and the unit goes to a BOOST

mode.

uPressing the button again will turn the product off.

ENGLISH

(Original instructions)

Using the pull out crevice tool (Fig. B,C)

uExtend the crevice tool (4) as shown in gure C, until it

clicks in place.

uTo retract the crevice tool (4) press the crevice tool release

button (4a) allowing it to return to its normal position

(Fig. B).

Note: The flip down brush (8) can only be utilised when the

crevice tool is in the retracted position.

Charging DVJ325BF, DVJ325BFS (Fig. D)

uPlace the appliance onto the charging base (7) and plug

into the electrical outlet.

uSwitch the electrical outlet on. The LED charging indicator

(B) will illuminate.

Charging DVJ215J, DVJ315J, DVJ320J,

DVJ325J (Fig. D1)

uPlace the charger (9) into the charging port at the rear of

the handle (2) and plug into the electrical outlet.

uSwitch the electrical outlet on. The LED charging indicator

(B) will illuminate.

Multi LED Display - DVJ325BF, DVJ325BFS

A. Filter sensor

Whenever a lter is Blocked and needs cleaning, the red

lter LED (A) in the handle will illuminate.

Clean ne dust from lter (See section on ‘cleaning lters’

in this manual).

B. LED Charging display

The charging display LED (B) will illuminate when the unit

is charging and will indicate (ash) when further charging

is required.

C. BOOST mode

LED (C) Illuminates when the appliance is in BOOST mode.

Dual LED Display - DVJ215J, DVJ 315J,

DVJ320J, DVJ325J

B. LED Charging display

Battery icon is illuminated when appliance is switched on

and will ash when the battery is almost depleted

charging. It will also ash during charging (See LED

pattern chart in this manual).

C. BOOST mode

Illuminates when the appliance is in BOOST mode.

ENGLISH (Original instructions)

LED Patterns

Charging

Battery Fault

Charger Fault

Battery Hot

Cleaning the lters (Fig. E, F, G, H, I, J)

uPress the dust bowl release button (12) (Fig. E)

uEject the dust bowl (6) (Fig.F)

uLift the lter assembly (10) using the metal handle provid-

ed from the dust bowl (6)

Note: On unit DVJ325BFS the pre filter is impregnated with a

fragrance allowing for a pleasing odour to be released when

the appliance is in use.

uEmpty the dust bowl (6) by lightly shaking over a dustbin

(Fig. H).

uThe lter (11) can now be removed from the lter assem-

bly (10)

DVJ215J, DVJ315J, DVJ320J, DVJ325J (Fig.I1).

DVJ325BF, DVJ325BFS (Fig. I).

uEmpty any remaining dust from the dust bowl.

uRinse out the dust-bowl with warm soapy water.

uWash the lters with warm soapy water (Fig. J).

uMake sure the lters are dry

uRet the lters into the appliance.

uClose the dust-bowl. Make sure the release latch (8) clicks

into place.

Warning! Before performing any maintenance or cleaning on

the appliance, unplug the appliance.

From time to time wipe the appliance with a damp cloth.

Do not use any abrasive or solvent-based cleaner. Do not

immerse the appliance in water

Maintenance

Your BLACK+DECKER cordless appliance has been designed

to operate over a long period of time with a minimum of main-

tenance. Continuous satisfactory operation depends upon

proper tool care and regular cleaning.

Warning! Before performing any maintenance on cordless

appliances:

uRun the battery down completely if it is integral and then

switch off.

uUnplug the charger before cleaning it. Your charger does

not require any maintenance apart from regular cleaning.

uRegularly clean the ventilation slots in your appliance/

charger using a soft brush or dry cloth.

uRegularly clean the motor housing using a damp cloth. Do

not use any abrasive or solvent-based cleaner.

Replacing the lters

The lters should be replaced every 6 to 9 months and when-

ever worn or damaged.

Replacement lters are available from your BLACK+DECKER

dealer (cat. noVBF10).

There are also pre-scented lters available to be purchased

(cat. no: VSPF10LC). These t all units. When these lters

reach the end of their lifespan they must be disposed of at a

local recycling centre.

Warning!

Cotton linen fragrance.

Wash face, hands and any exposed skin

thoroughly after handling. Wear protective

gloves/protective clothing/eye protection/

face protection. If in eyes: Rinse cautiously

with water for several minutes. Remove

contact lenses if present and easy to do.

Continue rinsing. If skin irritation occurs: Get

medical advice/attention. Avoid release into

the environment. Do not ingest.

uRemove the old lters as described above.

uFit the new lters as described above.

Protecting the environment

ZSeparate collection. Products and batteries

marked with this symbol must not be disposed of

with normal household waste.

Products and batteries contain materials that can be recov-

ered or recycled reducing the demand for raw materials.

Please recycle electrical products and batteries according to

local provisions. Further information is available at

www.2helpU.com

Technical Data

DVJ215J

Voltage 7.2V

Current 1.5Ah

Watt Hours 10.8Wh

Weight 1.0Kg

DVJ315J

Voltage 10.8V

Current 1.5Ah

Watt Hours 16.2.Wh

Weight 1.1Kg

(Übersetzung der ursprünglichen

Anweisungen) DEUTSCH

ENGLISH (Original instructions)

DVJ320J

Voltage 10.8V

Current 2.0Ah

Watt Hours 21.6Wh

Weight 1.1Kg

DVJ325J,

Voltage 10.8V

Current 2.5Ah

Watt Hours 27Wh

Weight 1.1Kg

DVJ325BF

Voltage 10.8V

Current 2.5Ah

Watt Hours 27Wh

Weight 1.1Kg

DVJ325BFS

Voltage 10.8V

Current 2.5Ah

Watt Hours 27Wh

Weight 1.1Kg

Guarantee

Black & Decker is condent of the quality of its products and

offers consumers a 24 month guarantee from the date

of purchase. This guarantee is in addition to and in no way

prejudices your statutory rights. The guarantee is valid within

the territories of the Member States of the European Union

and the European Free Trade Area.

To claim on the guarantee, the claim must be in accordance

with Black&Decker Terms and Conditions and you will need to

submit proof of purchase to the seller or an authorised repair

agent. Terms and conditions of the Black&Decker 2 year guar-

antee and the location of your nearest authorised repair agent

can be obtained on the Internet at www.2helpU.com, or

by contacting your local Black & Decker ofce at the address

indicated in this manual.

Please visit our website www.blackanddecker.co.uk to register

your new Black & Decker product and receive updates on new

products and special offers.

Verwendungszweck

Der Handstaubsauger BLACK+DECKER DVJ215J, DVJ315J,

DVJ320J, DVJ325J, DVJ325BF and DVJ325BFS Dustbuster®

wurde zum Aufsaugen von Schmutz entwickelt. Diese Geräte

sind nicht für den gewerblichen Einsatz vorgesehen.

Lesen Sie diese Anleitung voll-

ständig und aufmerksam durch,

bevor Sie das Gerät verwenden.

Sicherheitshinweise

@Warnung! Lesen Sie alle

Sicherheitswarnhinweise

und alle Anweisungen. Die

Nichteinhaltung der folgenden

Warnungen und Anweisungen

kann einen elektrischen Schlag,

Brand und/oder schwere

Verletzungen verursachen.

uDer vorgesehene Verwendungszweck

ist in dieser Anleitung beschrieben.

Bei Verwendung von Zubehör oder

Anbauteilen, die nicht in dieser

Anleitung empfohlen werden, sowie

bei der Verwendung des Geräts

in Abweichung von den in dieser

Anleitung beschriebenen Verfahren

besteht Verletzungsgefahr.

uBewahren Sie diese Anleitung auf.

Verwendung des Geräts

uBenutzen Sie das Gerät nicht zum

Aufsaugen entzündlicher Flüssigkeiten

oder Materialien.

uBetreiben Sie das Gerät nicht in der

Nähe von Wasser.

uTauchen Sie das Gerät nicht in

Wasser.

uZiehen Sie das Ladegerät nicht am

Kabel aus der Netzsteckdose.

(Übersetzung der ursprünglichen Anweisungen)

DEUTSCH

Achten Sie darauf, dass das Kabel des

Ladegeräts nicht in Kontakt mit starker

Hitze, Öl oder scharfen Gegenständen

kommt.

uDieses Gerät darf von Kindern

ab 8 Jahren und Personen mit

eingeschränkten körperlichen,

sensorischen oder geistigen

Fähigkeiten sowie mangelnder

Erfahrung und Wissen in Bezug auf

dessen Gebrauch bedient werden,

wenn sie bei der Verwendung des

Geräts beaufsichtigt oder angeleitet

werden und die möglichen Gefahren

verstehen. Kinder dürfen nicht mit

dem Gerät spielen. Reinigung und

Wartungsarbeiten dürfen von Kindern

nur unter Aufsicht durchgeführt

werden.

Inspektion und Reparaturen

Prüfen Sie das Gerät vor der Verwen-

dung auf beschädigte oder defekte Teile.

Prüfen Sie, ob Teile gebrochen sind,

Schalter beschädigt sind oder andere

Bedingungen vorliegen, die die Funktion

beeinträchtigen könnten.

uBetreiben Sie das Gerät nicht, wenn

ein Teil beschädigt oder defekt ist.

uLassen Sie beschädigte oder defekte

Teile in einer Vertragswerkstatt

reparieren oder austauschen.

uÜberprüfen Sie das Ladegerätkabel

in regelmäßigen Abständen auf

Beschädigungen. Tauschen Sie das

Ladegerät aus, wenn das Kabel

beschädigt oder defekt ist.

uErsetzen oder entfernen Sie keine

Teile, für die in dieser Anleitung

keine entsprechende Beschreibung

enthalten ist.

Zusätzliche Sicherheitshinweise

Nach dem Gebrauch

uZiehen Sie das Ladegerät aus

der Netzsteckdose, bevor Sie das

Ladegerät oder die Ladestation

reinigen.

uBewahren Sie das Gerät bei

Nichtgebrauch an einem trockenen Ort

auf.

uKinder sollten keinen Zugang zu

aufbewahrten Geräten haben.

Restrisiken

Beim Gebrauch dieses Geräts verbleiben

zusätzliche Restrisiken, die möglicher-

weise nicht in den Sicherheitswarnungen

genannt werden. Diese Risiken bestehen

beispielsweise bei Missbrauch oder län-

gerem Gebrauch.

Auch bei der Einhaltung der entspre-

chenden Sicherheitsvorschriften und der

Verwendung aller Sicherheitsgeräte be-

stehen weiterhin bestimmte Restrisiken.

Diese sind:

uVerletzungen, die durch das Berühren

von sich drehenden/bewegenden

Teilen verursacht werden.

uVerletzungen, die durch das

Austauschen von Teilen, Sägeblättern

oder Zubehör verursacht werden.

uVerletzungen, die durch längeren

Gebrauch eines Geräts verursacht

werden. Legen Sie bei längerem

Gebrauch regelmäßige Pausen ein.

uBeeinträchtigung des Gehörs.

uGesundheitsrisiken durch das

Einatmen von Staub beim Gebrauch

des Geräts (beispielsweise bei

Holzarbeiten, insbesondere Eiche,

Buche und Pressspan).

Autres manuels pour DVJ215J

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Black & Decker Ventilateur

Black & Decker

Black & Decker 625233-00 Manuel utilisateur

Black & Decker

Black & Decker BV2200 Manuel utilisateur

Black & Decker

Black & Decker BV3600-CA Manuel utilisateur

Black & Decker

Black & Decker BEBLV290 Manuel utilisateur

Black & Decker

Black & Decker Leaf Hog 617365-00 Manuel utilisateur

Black & Decker

Black & Decker BDB530 Manuel utilisateur

Black & Decker

Black & Decker GW200 Manuel utilisateur

Black & Decker

Black & Decker GWC1820PC-QW Manuel utilisateur

Black & Decker

Black & Decker NS118 Manuel utilisateur

Black & Decker

Black & Decker GWC1820PC Manuel utilisateur

Black & Decker

Black & Decker BL950 Manuel utilisateur

Black & Decker

Black & Decker Dustbuster PSA115B Manuel utilisateur

Black & Decker

Black & Decker LSW36 Manuel utilisateur

Black & Decker

Black & Decker LB700 Manuel utilisateur

Black & Decker

Black & Decker BV2500 Manuel utilisateur

Black & Decker

Black & Decker BEBLV260 Manuel utilisateur

Black & Decker

Black & Decker DVA320J Manuel utilisateur

Black & Decker

Black & Decker NS118-XE Manuel utilisateur

Black & Decker

Black & Decker GWC1800L-XE Manuel utilisateur

Black & Decker

Black & Decker BPPT600 Manuel utilisateur

Black & Decker

Black & Decker LSW321 Manuel utilisateur

Black & Decker

Black & Decker GWC3610L-XE Manuel utilisateur

Black & Decker

Black & Decker GW180 Manuel utilisateur

Black & Decker

Black & Decker Leaf Hog 492172-00 Manuel utilisateur

Manuels Ventilateur populaires d'autres marques

Weed Eater

Weed Eater VS2000BV Manuel utilisateur

KRAUSMANN

KRAUSMANN U37020-00 Manuel utilisateur

Bosch

Bosch ALB 36 LI Manuel utilisateur

Cub Cadet

Cub Cadet HB425 Manuel utilisateur

GreenWorks Pro

GreenWorks Pro BLB482 Manuel utilisateur

ARIETE

ARIETE 2768 Manuel utilisateur

NuTone

NuTone 331H Manuel utilisateur

GÜDE

GÜDE GLB 200 18 Li-Ion Manuel utilisateur

I.VA.CO.

I.VA.CO. SC Series Mode d'emploi

DeWalt

DeWalt DCE100 Manuel utilisateur

Becker

Becker SV 7.330 Manuel utilisateur

Metabo

Metabo AG 18 Pro Manuel utilisateur

Desa

Desa GA3650TB Manuel utilisateur

Echo

Echo Power Blower PB-230LN Manuel utilisateur

Echo

Echo PB-413H Manuel utilisateur

Ryobi

Ryobi RY08570 Manuel utilisateur

Haaga

Haaga 355 Manuel utilisateur

Stiga

Stiga SBL 327 V Manuel utilisateur
