Bitspower Hercules Pump V3 Manuel utilisateur
[ 1 ]
Dimension
Troubleshooting
If the pump doesn't operate, please replug the pump in
several times until it works normally.
If it still doesn't work, it is probably blocked by particles.
Drain the system and remove the pump housing. Open the
pump by removing the four housing screws at the bottom.
Remove the housing and pull out the rotor. Clean the
rotor with a clean cloth and purge all dirt from the pump
housing.
Bitspower Hercules Pump
instruction manual
V3
SPECIFICATION
Rated voltage：12V DC
Power consumption：13W
Maximum ow：11±10% L/min
Noise：≤ 30dBA
PWM：Yes
MTBF：≥ 15000 hours
Warranty：2 years
Dimension: 62 x 62 x 46.1mm
Maximum lift of the water pump: 6 meters
50.5MM
50.5MM 62MM
62MM
46.1MM
Assembly steps
Not permitted Upside downHorizontalVertical
[ 2 ]
[ 3 ]
Pump Replacement Demonstration
Titan Series
Titan Mini Series
O Ring
O Ring
Hercules Pump
Hercules Pump
M4x25 Screw
M4x25 Screw
step 1
step 1
step 2
step 2
記得上角要放對應的 LOGO!
[ 4 ]
Protection
Idle protection
When there is no liquid in the pump, the water pump will enter an idle speed protection mode
and run at full speed within 5 seconds.
After 5 seconds of idling, the water pump will temporarily stop running.
The pump will restart automatically after 5 seconds.
After repeating this cycle 10 times, the pump will completely stop running and will not start
again.
At this time, the power needs to be turned o before restarting.
If normal water ows through the pump before the pump stops running completely, the pump
will keep running normally.
Over / Under Voltage Protection
Over Voltage Protection 20±1V
When the input voltage is higher than the protection value, the pump will stop running within 2
seconds.
When the input voltage is lower than the protection value, the water pump will resume running
within 2 seconds.
Under Voltage Protection 6±1V
When the input voltage is lower than the protection value, the pump will stop running within 2
seconds.
When the input voltage is higher than the protection value, the water pump will resume running
within 2 seconds.
Rotor lock protection
When the rotor of the pump is blocked, the pump will automatically stop running, and resume
running after 5 seconds.
If the pump rotor continues to clog, the restart time will be extended to 15 seconds after 5
restarts.
Reverse voltage protection
When the positive and negative poles of the water pump are accidentally reversed
with 20V of power, the water pump will not run thereby preventing irreparable damage.
Notice
Before filling in the water, please make sure all the components are
installed correctly. To prevent any leakage which may damage the PC
components, please perform a 24-hour leaking test with only the pump
connected to the power supply.
Bitspower reserves the right to change the product design and
interpretations. These are subject to change without notice. Product
colors and accessories are based on the actual product.
When using leak tester on water cooling loop, in order to avoid product
damage due to excessive pressure, the input pressure should not exceed
0.5kg/cm2 (Bar). If the product is damaged due to
excessive pressure, it will be borne by the customer. Forbidden to use the
leak teser when there is water in the loop or the pump is runing.
Bitspower requires to use of distilled or pure water or Bitspower Pellucid
Coolant as the water-cooling liquid. Also, the consumer can add Bitspower
Dye to Pellucid Coolant for the color requirement. But please do not add
any biocide by yourself. If the consumer chooses different water-cooling
liquids, the resulting impurities may cause peeling o the coating on some
of the hardware, water channels blockage by built-up residue, improper
operation of the water pump, water tank tube breakage, and O-rings
deformation or loss sealing leading to leakage. Any issues related to the
use of inappropriate water-cooling liquid will be the responsibility of the
consumer.
[ 5 ]
記得上角要放對應的 LOGO!
[ 6 ]
外觀尺寸
故障排除
假如水泵未運作，請重新插拔電源數次直至正常運行。
仍持續未運作，有可能被顆粒阻塞。
將水排除並拆下四顆螺絲，移除水泵上蓋。
將轉子取出用乾淨的布做清潔並清除上蓋汙垢。
規格
額定電壓：12V DC
功率消耗：13W
最大流量：11±10% L/min
噪音：≤ 30dBA
PWM：Yes
MTBF：≥ 15000 hours
保固：2 years
產品尺寸 : 62 x 62 x 46.1mm
水泵最大揚程：6 米
50.5MM
50.5MM 62MM
62MM
46.1MM
組裝步驟
禁止顛倒置放水平直立
使用說明書
Bitspower Hercules Pump V3
[ 7 ]
[ 8 ]
馬達更換示範
Titan 系列
Titan Mini 系列
O 型圈
O 型圈
馬達
馬達
M4x25 螺絲
M4x25 螺絲
步驟 1
步驟 1
步驟 2
步驟 2
[ 9 ]
保護事項
空轉保護
當泵內無液體時，水泵會在 5 秒內進入空轉保護模式，並全速運作。
一直維持空轉狀態，水泵會在 5 秒後暫時停止運作。
再過 5 秒，水泵會自動重啟。
依此循環 10 次後，水泵會完全停止運作不再啟動，此時需斷電才能重新啟動。
如果水泵在完全停止運作前即有正常水流通過，水泵則會維持正常運作。
過電壓 / 低電壓保護
過電壓保護值為 20±1V。
當輸入電壓大於此保護值時，水泵會在 2 秒內停止運作。
當輸入電壓小於此保護值時，水泵會在 2 秒內恢復運作。
低電壓保護值為 6±1V。
當輸入電壓小於此保護值時，水泵會在 2 秒內停止運作。
當輸入電壓大於此保護值時，水泵會在 2 秒內恢復運作。
轉體鎖定保護
當水泵轉子有阻塞情況時，水泵會自動暫停運作，5 秒後會恢復運作。
若水泵轉子持續有阻塞情況，重新啟動 5 次後，重啟時間將延長至 15 秒。
逆向電壓保護
當水泵正負極反向輸入 20V 電壓時，水泵不會運作、也不會發生無法恢復的故障。
注意
跑水前，請先確認所有零件已安裝在正確的位置上，在不開主機，單開水泵的
情况下，進行 24 小時的跑水測試， 確保無漏水情况後再開主機，避免發生漏
水而導致電腦零件的損壞。
本公司保留對產品的設計更改以及解釋的權力，如有更動恕不另行通知，產品
顏色與配件以實物為準。
當使用測氣產品測試水路時 , 為避免由于壓力過大導致產品損壞 , 輸入的壓力
請不要超過 0.5kg/cm2 (Bar), 如因壓力過大造成產品損壞 , 將由客戶自行承
擔 . 嚴禁客戶在水路有水及水泵開啟的情況下進行氣體飽壓測試。
Bitspower 要求消費者使用 蒸餾水或純水或 Bitspower 透明冷卻液作爲水冷液
使用。此外，也可以添加 Bitspower 染料到透明冷卻液中以滿足顏色要求。如
果消費者選擇不同的水冷液，可能會引起水路配件中的塗層剝落、積垢堵塞水
道、水泵磨損、水箱管破裂、O 型圈變形或失去密封性導致漏水等。任何因使
用不當水冷液導致相關的問題將由消費者自行負責。
[ 10 ]
記得上角要放對應的 LOGO!
