Bitbrain EEG 16 Manuel utilisateur
Versatile
Kids EEG
16
User guide
Model: E16.A1
2Versatile Kids EEG 16
English
English
This is the user guide for the
Versatile Kids EEG 16 device from Bitbrain.
This document will provide information for
the proper setup and usage of the system.
3
User guide English
Contents
05 What is included?
08 Safety information
10 Conditions for use
11 Disclaimer
12 Versatile Kids EEG 16
13 Technical specications
14 Preparing the equipment
19 Preparing to record data
21 Placement of the equipment
4Versatile Kids EEG 16
English
25 Obtaining a signal
27 Placement of the kids cap
28 Removing the cap
30 Maintenance
Contents
5
User guide English
Item Name / description Amount
16-channel amplier
•Powered by an internal battery.
1
16-channel EEG cap + chinstrap
•Holds the electrodes in place.
•Based on the 10/10 international system.
3
Kids Cap
•Exterior kids cap that protects the sensors
during use.
1
1 Set of EEG electrodes + connectors
•With a total of 16 channels + GND + REF
1
Sensor holder
•Organizes the sensors and cables when
not in use, preventing damage.
1
Sensor sockets
•Enable placement of the sensors in
specic positions on the cap.
3 x 18
What is included?
This pack includes all the elements necessary for the operation of the
16-channel EEG system:
6Versatile Kids EEG 16
English
What is included?
Item Name / description Amount
Wet sensors (sponges)
•When damp, enable contact between
the sensor and the scalp.
1 bag
Cable fastening band
•Groups and organizes the cables during
operation.
1
Measuring band
•Measures the perimeter of the user’s
head.
1
8GB Class-10 MicroSD Card with SD
Adaptor
1
Charger + adapters
•Charges the internal amplier battery.
1
Photodiode EEG (optional)
• Connected to the auxiliary input, it measures changes in
light intensity to synchronize data recording with on-
screen stimuli.
1 Button Box - 1-bit input trigger (optional)
• Connected to the auxiliary input, allows the user to
record events.
7
User guide English
What is included?
Item Name / description
Pedal - 1-bit input trigger (optional)
• Connected to the auxiliary input, allows the user to
record events.
TTL Trigger BBT (optional)
• Connected to the auxiliary input, allows
synchronization with Versatile BIO.
TTL Trigger EXT (optional)
• Connected to the auxiliary input, allows
synchronization with external devices.
Pulse generator (optional)
• Synchronizes two Versatile Kids EEG systems.
Duplexer (optional)
• Connected to the auxiliary input, enables the
conexion of one photodiode and one digital trigger
(TTL, button, pedal or pulse generator) at the same
time.
HTC Vive PRO attachment kit (optional)
• Integration with the HTC Vive Pro VR.
8Versatile Kids EEG 16
English
Safety information
Please read the safety information, conditions of use and instructions
carefully before using the device. Failure to follow the instructions set
out in these documents will lead to the nullication of the product
warranty.
Careful usage and handling of the
equipment
•Do not handle the device with
damp hands, as this could cause a
short-circuit.
•Do not use the device for other
applications than its intended
purpose.
•Do not hit, throw, bite, open or burn
the device.
•Avoid falls or collision with other
objects.
•Keep the device in a dry place,
and do not expose to extreme
temperatures.
Warnings about the equipment
•DO NOT use the device while it is
charging.
•DO NOT open the device. If your
device does not work properly,
contact suppor[email protected]m..
•DO NOT place this device close
to life support electronic and
electrical equipment.
•If you notice that the device emits
strange smells or noises, or that its
temperature is excessive, leave it in
a safe place and contact
support@bitbrain.com.
Warnings about the battery
• Disconnect the charging cable
once the battery is fully charged.
Otherwise, the battery’s life cycle
could be reduced.
•If you are going to store the device
for a long period (several weeks or
months), it is recommended that
the battery should not be 100%
charged. This can degrade the
battery and result in permanent
capacity loss.
•Keep the device in a dry place,
between the temperatures of 5ºC
and 40ºC. Prolonged exposure to
high temperatures can affect the
stability of the battery.
•To charge the battery of the device,
ONLY use the battery charger
provided.(Limit of 1A).
•Using a higher amperage charger
may seriously damage the
equipment.
9
User guide English
Safety informationSafety information
Device disposal
Do not throw electrical and
electronic devices in the trash! In
accordance with European Directive
2012/19/UE on Waste Electrical
and Electronic Equipment,
they should be disposed of at
suitable collection points for
environmentally responsible
recycling.
Before disposing of appliances
at collection points, batteries
should be removed and disposed
of separately from the electronics to
be treated appropriately.
In order to separate the battery from
the electronics in preparation for
disposal, open the amplier using
a Torx 6 screwdriver and carefully
detach it.
Conformance and CE marking
This device complies with the EU
safety requirements (UNE- EN
60950-1: 2007, EN55032 and
EN55024). The CE mark indicates
compliance with the corresponding
directives of the EU Council, which
includes EMC Directive 2004/108/
EC.
Important
Versatile Kids EEG 16 is a device
designed by Bitbrain to measure
biometric data for research
purposes.
10 Versatile Kids EEG 16
English
Conditions for use
•Read the device safety information carefully and keep this manual for
future reference.
•Read the “General Terms and Conditions of Sale and Use for Bitbrain
Products” carefully. You can nd the document at
www.bitbrain.com/en/tc.
