USER'S GUIDE

94E9 SERIES

Earn BISSELL Rewards!

product today!

See details on

page 2

2Thank You

Safety Instructions

Product View

Assembly

Operations

Maintenance and Care

Consumer Services

Troubleshooting

7-8

Replacement Parts

Additional Accessories

Warranty

Product Registration

www.bissell.com 800.237.7691

Thanks for buying a BISSELL Steam Mop™Select

We’re glad you purchased a BISSELL Steam Mop Select. Everything

we know about floor care went into the design and construction of

this complete, high-tech home cleaning system.

Your BISSELL Steam Mop Select is well made, and we back it with a

limited one year warranty. We also stand behind it with a knowl-

edgeable, dedicated Consumer Services department, so, should you

ever have a problem, you’ll receive fast, considerate assistance.

My great-grandfather invented the floor sweeper in 1876. Today,

BISSELL is a global leader in the design, manufacture, and

service of high quality homecare products like your

BISSELL Steam Mop Select .

Thanks again, from all of us at BISSELL.

Mark J. Bissell

Chairman & CEO

www.bissell.com 800.237.7691

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical

appliance, basic

precautions should be observed,

including the following:

Read all instructions before using your

Steam Mop™Select.

WARNING: To

reduce the risk of fire, electric shock, or injury:

■Do not direct steam at people, animals, or

at electrical outlets.

■Do not expose to rain.

■Store indoors.

■Unplug from outlet when not in use and

before conducting maintenance

or troubleshooting.

■Do not leave steam cleaner unattended.

■Do not expose hair, loose clothing, ﬁngers

or body parts to openings or moving parts.

■Do not service steam cleaner when it is

plugged in.

■Do not handle steam cleaner with wet hands.

■Do not use steam cleaner if it has been

dropped, damaged, left outdoors or

dropped into water, return it to a service

center.

■Do not pull or carry by cord, use cord as

a handle, close door on cord, pull cord

around sharp corners or edges, or expose

cord to heated surfaces.

■Do not unplug by pulling on cord.

■Do not use appliance in an enclosed space

filled with vapor given off by oil-base paint,

paint thinner, some moth proofing sub-

stances, flammable dust, or other explosive

or toxic vapors.

■Do not allow to be used as a toy.

■Do not use on leather, wax polished furniture

or floors, synthetic fabrics, velvet or other

delicate, steam-sensitive materials.

■Do not immerse.

■Do not use for any purpose other than

described in this User’s Guide.

■Use only manufacturer’s recommended

attachments - use of attachments not pro-

vided or sold by BISSELL may cause fire,

electric shock or injury.

■Never put descaling, aromatic, alcoholic or

detergent products into the steam cleaner, as

this may damage it or make it unsafe for use.

■Unplug by grasping the plug, not the cord.

■Close attention is necessary when used by

or near children.

SAVE THESE

INSTRUCTIONS

Commercial use of this unit void the

manufacturer's warranty.

THIS APPLIANCE

HAS A

POLARIZED

PLUG.

To reduce the risk of electric shock, this

appliance has a polarized plug (one

blade is wider then the other) This plug

will fit in a polarized outlet only one way.

If the plug does not fit fully into the outlet,

reverse the plug. If it still does not fit,

contact a qualified electrician to install a

proper outlet. Do not change the plug in

any way.

This model is for household use only.

www.bissell.com 800.237.7691

Product view

Washable Mop

Pads-2 Pack

Strain Reliever

Handle™

Steam on

Demand Trigger

Lower Cord

Wrap

Mop Pad

Quick Release™

Cord Wrap

Power Cord

Steam Mop Scented Water-

Eucalyptus Mint

Optional Accessories:

Removable

Water Tank

Indicator Light

www.bissell.com 800.237.7691

Assembly

Your Steam Mop Select assembles

quickly and easily. Your Steam Mop

Select is packaged with the following

items:

Handle Assembly

Lower Body

Maneuverable Mop Head

Removable Water Tank

2 Steam Mop Select Mop Pads

1. Attach lower body to mop head by

snapping it into place.

2. Slide handle assembly down into

lower body until it snaps into place.

3. Slide water tank onto lower body and

gently push tank into place.

Steam Mop Select assembly is now complete.

Handle Assembly

Maneuverable Mop Head

Removable

Water Tank

2 Microfiber Mop Pads

Lower Body

www.bissell.com 800.237.7691

Special features

Removable water tank

The water tank is located on the top of

the Steam Mop Select. It can be refilled

with water any time during use. Distilled

or demineralized water is recommended

in place of tap water.

Do not use chemicals with your

Steam Mop Select.

Indicator light

The indicator light will glow when the

Steam Mop Select is plugged in.

Steam on demand trigger

Press to release steam.

Microfiber Mop Pads

Reusable microfiber mop pad is machine

washable and safe for all

hard floor surfaces. Your Steam Mop

Select may have come with two different

pads. The all-white "soft" pad is best for

everyday use on delicate flooring like

sealed hardwoods and laminate. The

gray and white striped pad can be used

for scrubbing heavily soiled floors and

tougher messes.

Tip:

Do not attempt to use

your Steam Mop Select

without water in the tank.

www.bissell.com 800.237.7691

Operations

1A 1B

Getting ready

The mop pad may have already

come attached to the mop head, if

not follow steps 1A and 1B below.

1. Attach mop pad

A. Set mop head in mop pad, making

sure toggle is located on the back.

B. Tighten mop pad by pulling on elastic

cord while pressing on toggle.

2. Fill the water tank

A. Remove tank by lifting straight up

and away from unit.

B. Unscrew cap at bottom of water tank.

C. Fill water tank with water. For best

results, water should be at

room temperature.

D. Replace the cap, tighten until snug.

E. Replace water tank by gently sliding

tank into place.

3. Twist the quick release cord wrap clock-

wise to unwrap the power cord com-

pletely and plug into a 120-Volt outlet

as described on the Important Safety

Instructions, page 3.

4. The indicator light will illuminate when the

Steam Mop Select is plugged in.

NOTE: Upon first use of the Steam

Mop Select or first use after refilling

the water tank, the pump may make

a "knocking" sound. This is normal

and should only last a few seconds.

While in use, the pump will continue

to make a soft "knocking" sound.

This is also normal.

Tip:

Use of distilled water is recommend-

ed to prolong the life of your Steam

Mop Select

www.bissell.com 800.237.7691

Operations

Before you clean

Thoroughly sweep or vacuum floor

prior to cleaning with the Steam Mop

Select.

Cleaning hard floors

Your Steam Mop Select is designed to

clean hard flooring such as ceramic

tile, vinyl, laminate, marble, stone and

sealed hard wood floors. Use of your

Steam Mop Select on waxed or some

unwaxed floors may result in a dimin-

ished glossiness. The Steam Mop Select

is not for use on unsealed wood floors.

For best results test in an inconspicu-

ous area and check the care instructions

from your flooring manufacturer.

1. Plug the unit in and wait 30 seconds for it to

heat up. Begin cleaning by slowly passing

over surface while pressing the steam on

demand trigger to emit steam as needed.

2. To sanitize an area of your floor, (attack

invisible germs and bacteria) place the

Steam Mop Select over the spot for a

minimum 15 seconds using continuous

steam, but no longer than 20 seconds

using continuous steam. For larger areas,

overlap swivel head placement.

3. When the Steam Mop Select stops emitting

steam, unplug the unit. Simply remove the

water tank, refill, and continue cleaning.

WARNING:

Never put descaling, alcoholic,

or detergent products into the steam

cleaner, as this may damage it or

make it unsafe for use. Only use

BISSELL authorized aromatic

products

www.bissell.com 800.237.7691

Maintenance and care

CAUTION:

Upright storage of the

Steam Mop Select with a

wet mop pad may result

in the formation of white

marks on your floor. To

remove the white marks,

clean area with vinegar.

When you're done

1. Unplug power cord from outlet.

2. Carefully remove mop pad from flip

head, as mop pad and lower assembly

may be hot.

3. Any water remaining in the water tank

should be emptied prior to machine

storage.

4. Mop pad can be machine washed in

warm water. Use only liquid detergents.

Do not use fabric softeners. For best

results, air dry.

5. Wrap power cord around quick release

cord wrap on side of Steam Mop Select.

6. Wipe all surfaces of Steam Mop Select

with a soft cloth. Store upright in a

protected, dry area.

www.bissell.com 800.237.7691

Troubleshooting

Item Part No. Part Name

1 203-7738 Handle Assembly

2 203-7734 Water Tank with Cap and Insert

3 203-7735 Cap and Insert Assembly

21 3

23 4

Additional Accessories

Item Part No. Part Name

1 76B2-A Replacement Mop Pads - 2 pack

2 3252-1 Eucalyptus Mint Natural Aroma

3 59V4 Steam Mop Scented Water Eucalyptus Mint 32 FL oz

4 203-2168 Storage Hook with Screws

Replacement parts- BISSELL Steam Mop™Select

Reduced steam or no steam.

Possible Causes Remedies

1. Water tank empty 1. Fill tank

Other maintenance or service not included in the manual should

be performed by an authorized service representative.

Thank you for selecting a BISSELL product.

Please do not return this product to the store.

For any questions or concerns, BISSELL is happy to be

of service. Contact us directly at 1-800-237-7691.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Bissell Nettoyeur à vapeur

Bissell

Bissell 57F4-J SERIES Manuel utilisateur

Bissell

Bissell SURFACESENSE PET 2817 Series Manuel utilisateur

Bissell

Bissell POWEREASE 76R9 Series Manuel utilisateur

Bissell

Bissell Lift-Off® Steam Mop Hard Surface Cleaner... Manuel utilisateur

Bissell

Bissell SUPREME SWEEP TURBO 4105 Manuel utilisateur

Bissell

Bissell 1544 series Manuel utilisateur

Bissell

Bissell PROHEAT 2X REVOLUTION PET 2457F Manuel utilisateur

Bissell

Bissell 1558N Manuel utilisateur

Bissell

Bissell 2680 Fiche d'information produit

Bissell

Bissell Lift-Off 66E1 SERIES Manuel utilisateur

Bissell

Bissell Symphony Manuel utilisateur

Bissell

Bissell Swiffer™ BISSELL® STEAMBOOST™ Steam Mop... Manuel de la liste des pièces

Bissell

Bissell Perfect Sweep TURBO 2800 SERIES Manuel utilisateur

Bissell

Bissell Steam Shot 16Q1E SERIES Manuel utilisateur

Bissell

Bissell Steam Mop BS-1867F Mode d'emploi

Bissell

Bissell POWERSTEAMER DUO 2078K Manuel utilisateur

Bissell

Bissell Steam&Sweep Pet Manuel utilisateur

Bissell

Bissell POWERSTEAMER 2685 Series Manuel utilisateur

Bissell

Bissell 23B6-F SERIES Manuel utilisateur

Bissell

Bissell Select 23V8-EFGY Series Manuel utilisateur

Bissell

Bissell Steam Mop 1005-E SERIES Manuel utilisateur

Bissell

Bissell Healthyhome 48F3 SERIES Manuel utilisateur

Bissell

Bissell 39N7 SERIES Manuel utilisateur

Bissell

Bissell SteamShot 2635 SERIES Manuel utilisateur

Manuels Nettoyeur à vapeur populaires d'autres marques

Oreck

Oreck STEAM-IT STEAM100LRH Manuel utilisateur

Beautural

Beautural YPZ-146 Manuel utilisateur

MPM

MPM MZP-02 Manuel utilisateur

Electrolux

Electrolux Refine 500 Manuel utilisateur

Kärcher

Kärcher SC 3 Premium Manuel utilisateur

Shark

Shark PRO Steam & Spray Instructions d'utilisation et d'entretien

Jula

Jula 802-337 Manuel utilisateur

Haan

Haan Floor Sanitizer MS-30 Manuel utilisateur

Black & Decker

Black & Decker HSM13E1 Manuel utilisateur

HOFFEN

HOFFEN GS-1231 Manuel utilisateur

POLTI

POLTI VAPORETTO SYSTEME PRO Manuel utilisateur

eta

eta AQUASIM PRO Manuel utilisateur

Maxwell

Maxwell MW-3715 G Manuel utilisateur

VAPamore

VAPamore Primo MR-100 Manuel

Bestron

Bestron AZQ016 Manuel utilisateur

Nilfisk-ALTO

Nilfisk-ALTO Steamtec 312 Manuel utilisateur

Tempo di saldi

Tempo di saldi SPINSCRUBBER Manuel utilisateur

DOMENA

DOMENA HYGIAFLOR Manuel utilisateur
