USER GUIDE

Table of Contents

Welcome to BirdDog........................................................................................3

Using This Manual..............................................................................................3

First Step ...............................................................................................................3

Firmware Upgrade ........................................................................................................3

PTZ Keyboard Overview.................................................................................4

Key Features....................................................................................................................4

What’s in the box? .............................................................................................6

Optional Accessories .......................................................................................6

Getting Started With Your PTZ Keyboard...............................................7

Connections.....................................................................................................................8

Keyboard Main Panel ......................................................................................10

Keyboard Rear Panel.......................................................................................12

Keyboard Screen ..............................................................................................13

Junction Box ........................................................................................................14

Powering PTZ Keyboard ................................................................................15

Connecting PTZ Keyboard to Your network..........................................16

NDI® Connection.......................................................................................................... 16

Other Control Protocols............................................................................................. 16

Navigating the Menus..................................................................................... 17

Keyboard Conguration ................................................................................17

Keyboard Setting Menu............................................................................................. 17

Button Light....................................................................................................................18

Function Key Assignment .........................................................................................19

Factory Default .............................................................................................................19

Tally - GPI I/O ............................................................................................................... 20

Password Setting ......................................................................................................... 20

Joystick Zoom Setting .................................................................................................21

Model Info........................................................................................................................21

Adding an NDI® Camera to the Keyboard............................................. 22

Adding Cameras Manually ...................................................................................... 22

Adding non-NDI® Cameras to the Keyboard....................................... 23

Adding a VISCA over IP Camera to PTZ Keyboard.........................................23

Interacting with Cameras.............................................................................. 26

Controlling Cameras................................................................................................... 26

NDI® Keyboard Router...............................................................................................27

Setting and calling presets........................................................................... 28

Creating Presets........................................................................................................... 28

Calling Presets .............................................................................................................. 28

Resetting / Deleting Presets.................................................................................... 28

Dual RS422 Button A/B............................................................................................. 29

Adjusting Image Parameters................................................................................... 29

Web User Interface Conguration Panel ............................................... 30

Dashboard...................................................................................................................... 30

Network ........................................................................................................................... 31

System ............................................................................................................................ 32

Using Other Control Protocols ....................................................................37

Cross-Protocol Mix Control..................................................................................... 38

Cross Protocol Mix Control...................................................................................... 40

Serial Port Connection................................................................................................41

Tally Light GPI I/O Connection....................................................................51

GPI Connection with VISCA OVER IP Control Connection..........................51

Appendix ............................................................................................................ 52

PTZ Keyboard Physical Dimensions ......................................................................53

Glossary............................................................................................................... 54

reproduced, translated, or distributed in any form or by any means without prior consent in writing

from our company.

Trademark Acknowledgement

and other BirdDog trademarks and logos are the property of BirdDog Australia. Other

trademarks, company names and product names contained in this manual are the property of their

respective owners.

•Trademarks and Registered Trademark Acknowledgement

•Microsoft, Windows, ActiveX, and Internet Explorer are registered trademarks of Microsoft

Corporation in the U.S. and/or other countries.

•HDMI, the HDMI logo and High-Denition Multimedia Interface are the trademarks or

registered trademarks of HDMI Licensing, LLC in the United States and other countries.

•Other trademarks, company names and product names contained in this manual are the

property of their respective owners.

IMPORTANT INFORMATION

Legal Notice

To ensure account security, please change the password after your rst login. You are recommended

to set a strong password (no less than eight characters).

The contents of this document are subject to change without prior notice. Updates will be added

to the new version of this manual. We will readily improve or update the products or procedures

described in the manual.

Best eort has been made to verify the integrity and correctness of the contents in this document, but

no statement, information, or recommendation in this manual shall constitute formal guarantee of any

kind, expressed or implied. We shall not be held responsible for any technical or typographical errors in

this manual.

The product appearance shown in this manual is for reference only and may be dierent from the

actual appearance of your device.

Due to uncertainties such as physical environment, discrepancy may exist between the actual values

and reference values provided in this manual. Use of this document and the subsequent results shall

be entirely on the user’s own responsibility.

WARNINGS

Installation and removal of the unit and its accessories must be carried out by qualied personnel. You

must read all of the Safety Instructions supplied with your equipment before installation and operation.

•If the product does not work properly, please contact your dealer. Never attempt to

disassemble the device yourself. (We will not assume any responsibility for problems caused

by unauthorized repair or maintenance).

•This installation should be made by a qualied service person and should conform to all the

local codes.

•When shipping, the device should be packed in its original packaging.

•Make sure the power supply voltage is correct before using the camera.

•Do not drop the device or subject it to physical shock.

Regulatory Compliance

FCC Part 15

This equipment has been tested and found to comply with the limits for digital device, pursuant to

part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used

in accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at his own expense.

This product complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions:

•This device may not cause harmful interference.

•This device must accept any interference received, including interference that may cause

undesired operation.

LVD/EMC Directive

This product complies with the European Low Voltage Directive 2006/95/EC and EMC Directive

2004/108/EC.

NDI® is a registered trademark of NewTek, Inc.

Welcome to BirdDog

Thank you for purchasing your PTZ Keyboard. If you have any questions regarding the camera, please

contact your authorized dealer or view our PTZ Keyboard Knowledge Base.

Our website also has a User Stories page to help inspire you to get the most out of your camera.

Using This Manual

Your PTZ Keyboard is a powerful and sophisticated device, so please read this manual before use and

retain for future reference.

If you are new to the world of NDI® or BirdDog PTZ Keyboard, begin with Getting Started With Your

PTZ Keyboard. This will give you a good introduction to the setup of your device.

Tip

You can use controls in your browser or PDF reader to increase the page size when viewing the

diagrams to reveal much more detail.

First Step

Firmware Upgrade

Before you use your new PTZ Keyboard, it’s a good idea to upgrade to the lastest rmware. We are

always adding new features and improving the performance of our products, so installing the latest

rmware will provide you with the best user experience.

To upgrade the rmware, please follow the Firmware Upgrade Instructions located in your rmware

download folder and perform upgrade process.

The latest rmware les are available for download here:

Firmware Updates

We’re Invested in Your Success

At BirdDog we pride ourselves on being approachable and easily contactable. We’d love to hear from

you.

Dan Miall

Co-Founder and CEO

dan@bird-dog.tv

Eamon Drew

Co-Founder and CMO

eamon@bird-dog.tv

PTZ Keyboard Overview

BirdDog PTZ Keyboard is a full featured and versatile PTZ keyboard that supports NDI®, NDI®|HX,

Visca over IP, RS422, and RS232. By harnessing BirdDog’s next generation NDI® and IP technology, it’s

never been easier to discover, connect, and control your PTZ cameras.

Key Features

•Wide protocol support: NDI®, VISCA, PELCO D/P, VISCA over IP.

•Cross protocol mix-control with RS232/RS422 and IP.

•Quick access of key camera functions.

•High quality 6-way joystick control.

•Independent wide-range dual power input: 12VDC, PoE.

Features

•Easy, ergonomic PTZ control of multiple remote cameras for live event production and

content creation. Typical applications include: Education, Broadcast, Video Conferencing,

House of Worship etc.

•This compact remote controller features a high-quality joystick that allows eortless one-

handed pan, tilt and zoom adjustments. Zoom can also be controlled via the joystick or a

supplementary seesaw lever; dedicated knobs and control buttons simplify direct access to

frequently-needed camera functions without needing to use the camera menus.

•Quick Access features include the control of Exposure, Shutter Speed, Iris, Compensation,

White Balance, Focus, PT Speed, Zoom Speed.

•The controller supports serial RS232/RS422 and IP mix-control. It allows you to use RS232/

RS422/IP control on one controller to control cameras in a single system.

•With IP control, automatically search available IP cameras in the network and assign IP

addresses easily. IP control supports CGI and VISCA Over IP.

•Up to 256 camera presets with memory of image parameters and 8 patterns to recall

camera moves (requires camera support).

•Tally Indicator: Includes Normal Tally/On-Air Tally/Contact Modes.

•Supports 2 groups (7 cameras per group) via VISCA RS422 daisy chain control. Unlimited

number of controllers can operate on a single network to control up to 255 IP cameras.

Controls up to total 255 cameras (Combine using PELCO/VISCA/VISCA-Over-IP Protocol).

•Up to 6 selectable ASSIGN function keys, allowing quick control of key camera functions.

•Multi-color Key/Button illumination indicator.

•Full compatibility is provided with all BirdDog PTZ cameras and Sony BRC, SRG series PTZ

cameras and most PTZ cameras in the market that support IP/RS232/RS422/RS485 control.

•Regular MCU rmware upgrades via USB add new features to PTZ Keyboard.

Welcome to the Future

What is NDI®?

Your new PTZ Keyboard has been designed from the ground up to support the cutting edge NDI®

video transmission standard.

NDI® (Network Device Interface) is a high-quality, low-latency, frame-accurate standard that enables

compatible devices to communicate, deliver, and receive high denition video over your existing

Gigabit Ethernet network.

Operating bi-directionally, NDI® devices can be auto-detected, powered and controlled over the same

Ethernet cable used to send the video and audio to anywhere on a network. Even ll and key alpha

channel information, as well as Tally, can be sent over this same cable. If you have a Gigabit network,

you have a now have the potential for a streamlined, interconnected, video production environment.

Transitioning to NDI® can also occur gradually. Existing SDI or HDMI signals can easily be converted to

an NDI® stream and piped where required on your network and converted back only at the neccessary

endpoints.

BirdDog has been on the NDI® journey since the very beginning and your PTZ Keyboard is just one of

our products designed to take advantage of the features and potential of NDI®.

For more information on NDI®, please refer to this page on our website.

1x BirdDog PTZ Keyboard

1x Power Adaptor & Power Cord

1x Junction box

1x RJ45 Control Cable

1x Tally light Terminal Contact

Optional Accessories

What’s in the box?

1x RJ45 to Phoenix Breakout

1x RJ45 Coupler

1x RS232 8 Pin Mini Din to Phoenix

Terminal Block

Depending on your requirements, you may need to purchase these optional accessories:

•When RS422, RS485 and RS232 cameras are being controlled simultaneously.

•When more than one group of RS422/RS485 cameras is being controlled simultaneously.

•When a 8 Pin Mini Din RS232 connector camera needs to be connected to and controlled.

Please browse to this page on our website for all your accessory needs.

Getting Started With Your PTZ Keyboard

If you are new to the world of NDI® or BirdDog cameras, please follow this quick start guide to become

familar with the basic setup of your new camera.

Your PTZ Keyboard at a Glance

If you are new to PTZ Keyboard, it may be helpful to visualize the layout as follows.

1. LCD Screen and Navigation

•For navigating and adjusting PTZ Keyboard settings. Interacting with IP cameras.

2. Camera Control

•PTZ Joystick

• For panning / tilting the camera in any direction and to zoom in / out.

•Alphanumeric Keypad

• For camera call, preset call, entering menu data.

•Separate zoom seesaw control.

3. Assign Keys

•To assign quick access to device commands.

4. Camera Image Adjustment

•Exposure, white balance and focus.

Autres manuels pour Studio NDI

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels birddog Contrôleurs

birddog

birddog PTZ KEYBOARD Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur

birddog Studio NDI Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques
