bioscrypt BIOSCRYPT V-PASS FX Manuel utilisateur
Finger-only security in 1:N mode or
dual-factor authentication in 1:1
mode with an external Wiegand
reader
Ideal for retrofitting existing
legacy systems to dual biometric/
authentication solutions in 1:1 mode
FEATURES
• Industry’s most accurate finger-scan algorithm (#1 at FVC 2002 &
FVC 2004)
• RoHS compliant
• User configurable 1:N mode or 1:1 mode
• New blue LED power signal
• Self-contained reader stores approximately 4,000 finger-scan
templates in 1:1 mode, 500 finger-scan templates in 1:500 mode,
and 200 finger-scan templates in 1:200 mode
• USB communication via Aux port
• VeriAdmin software (included free of charge) offers a simple
approach to initial setup, template management, and networking
configuration
• User-friendly installation with pigtail connections and flat surface,
single-gang, or mullion mounting
• Simple one-touch enrollment
• Intuitive user interface provides feedback via multi-colored LED
and tone signals
• Flexible communication options support Wiegand formats up to
64 bits
• Duress finger option.
Bioscrypt®V-Pass FX™
Flexible Security Options
DIMENSIONS
Length: 130 mm (5.12 in)
Width: 50 mm (1.97 in)
Depth: 63.5 mm (2.5 in)
COMMUNICATIONS:
Pigtail wire connections for RS-232 and RS-485
Wiegand IN/OUT
USB Aux port
VERIFICATION (1:1):
Enrollment time: < 3 seconds
Verification time: < 1 second
False Acceptance Rate (FAR): Adjustable
False Rejection Rate (FRR): Adjustable
Equal Error Rate (EER) (FAR=FRR): 0.1%
Number of templates: ~ 4000 per unit
Template size: ~ 350 bytes
IDENTIFICATION (1:N):
Enrollment time: < 3 seconds
Verification time: < 2 seconds
FAR: 0.2%
FRR: 1.0%
Number of templates: 500 per reader in 1:500 mode; 200 per
reader in 1:200 mode
Template size: ~ 2500 bytes
VOLTAGE:
9-24 VDC
CURRENT DRAW:
Idle: 0.20 amps @ 12 VDC
Max: 0.40 amps @ 12 VDC
MOUNTING:
Flat surface, single-gang, or mullion mountable
Wall mount plate accepts #6 screws or bolts
Clearance hole diameter is 3.94 mm (0.155 in)
Trim plate included to cover single-gang box.
OPERATING TEMPERATURE:
0° - 60°C
CERTIFICATIONS:
FCC, CE, UL294, cUL, RoHS
By default, the Bioscrypt V-Pass FX is set to 1:500 mode. The reader must
be configured manually to run in 1:200 or 1:1 modes.
V-PASS-FX-A,R:
Finger-scan reader (using customer-supplied external Wiegand device)
DESKTOP-VS-FX-A,R:
V-PASS-FX-A,R reader mounted on a plastic stand,with power supply
DEMO-VS-FX-A,R:
V-PASS-FX-A,R reader mounted on stand,with power supply and case
BIO-SDK:
Development software CD (supports all Bioscrypt products)
OUTDOOR ENCLOSURE:
The Bioscrypt V-Pass FX is compatible with the Bioscrypt V-Cerco or
V-Cerco-HT protective enclosures. Contact Bioscrypt for more
information.
TECHNICAL INFORMATION ORDERING INFORMATION
Bioscrypt®V-Pass FX™
BIOSCRYPT INC.
505 Cochrane Drive
Markham, ON, Canada
L3R 8E3
P: 905.940.7490
F: 905.940.7492
