INSTRUCTIONS FOR USE
Models: 210, 310, 410 & 600
2 | BIOBASIC INSTRUCTIONS FOR USE
Before you proceed
This instructions for use is intended for the following product series:
BIOBASIC
We recommend that you read this instructions for use through thoroughly
before using the cabinet for the rst time. Gram Commercial does not
guarantee safe operation if the cabinet is used for anything other than its
intended use. Contents of the instructions for use can be subject to change
without notice. No part of this instructions for use may be reproduced in
any form without expressed written consent of Gram Commercial. Gram
Commercial guarantees the cabinet under certain warranty conditions. Gram
Commercial is not responsible for any loss or damage of content.
This instructions for use should be considered an integral part of the cabinet
and should be stored close to the cabinet and be easy to access. If the
instructions for use is lost, please refer to your local distributor or Gram
Commercial for a replacement. For current versions of the instructions for use,
please go to www.gram-bioline.com.
Gram BioLine equipment is designed to be used in a system with monitored
additional independent alarms to ensure timely reaction to alarms and thereby
maximum item safety
BIOBASIC INSTRUCTIONS FOR USE | 3
In the event of need for product support, donot hesitate to contact us at:
In the event of technical diculties always contact Gram BioLine technical
support or a Gram BioLine authorized service partner.
Copyright © 2006-2022 Gram BioLine, a division of Gram Commercial, Denmark. All rights
reserved. The content of this publication is owned by Gram BioLine, unless otherwise
noted, and is protected by Danish and international copyright laws and provisions.
Information and images may not be used, copied or transferred without the express
written permission by Gram BioLine.
4 | BIOBASIC INSTRUCTIONS FOR USE
Table of Content
Before you proceed ............................................. 2
Table of Content ................................................ 4
Intended use .................................................... 6
Temperature setpoint range and ambient requirements ......... 6
Symbols used ................................................... 7
Installation ..................................................... 8
Initial setup steps ............................................... 8
Adjusting the base .............................................. 9
Anti tilt bracket ................................................10
Wall mounting .................................................11
Surroundings ..................................................12
Product inspection ............................................13
Voltage free contact ...........................................14
Connecting to power ..........................................16
Equipotential bonding .........................................20
Start up ........................................................22
The digital display controls .....................................22
General introduction to the controller interface ................23
Alarm settings ................................................. 24
Buttons and useful short cuts ..................................25
Operation parameters .........................................26
Error codes ....................................................27
Latching alarms: A2, A3 ........................................27
Sensor oset ..................................................28
Ordinary use ...................................................30
Door gaskets ..................................................32
General info ...................................................33
Responsibility .................................................33
General info ...................................................34
Service ........................................................34
BIOBASIC INSTRUCTIONS FOR USE | 5
Type number plate ............................................35
Access port ....................................................36
Regular maintenance .........................................38
Cleaning .......................................................38
IMPORTANT ....................................................40
Disposal .......................................................41
Datasheet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
General data: BIOBASIC 210, 310, 410 ..........................42
BIOBASIC RR210 – with solid door ..............................44
BIOBASIC RR210 – with glass door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
BIOBASIC RR310 – with solid door ..............................46
BIOBASIC RR310 – with glass door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
BIOBASIC RR410 – with solid door ..............................48
BIOBASIC RR410 – with glass door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
BIOBASIC RF210 ...............................................50
BIOBASIC RF310 ...............................................51
BIOBASIC RF410 ...............................................52
General data: BIOBASIC 600 ...................................54
BIOBASIC RR600 ............................................... 56
BIOBASIC RF600 ...............................................57
Declaration of Conformity .....................................58
Wiring diagrams ............................................... 59
BIOBASIC RR/RF210, RR/RF310, RR/RF410 ......................59
BIOBASIC RR600 ............................................... 60
BIOBASIC RF600 ...............................................61
Piping diagram ................................................62
Notes ..........................................................64
6 | BIOBASIC INSTRUCTIONS FOR USE
Intended use
BIOBASIC refrigerators (RR) and freezers (RF), are designed and manufactured
to provide general purpose storage of non-critical laboratory items.
The BIOBASIC range complies with EN/IEC 60079-15, covering electrical
apparatus in Category 3, Zone 2 locations where explosive atmospheres may be
present.
Enabling placement of BIOBASIC refrigerators and freezers, in Zone 2 areas
categorised according to EN/IEC 60079-14.
Temperature setpoint range and
ambient requirements
Model + temperature
setpoint range
Minimum ambient
operating temperature
Maximum ambient
operating temperature
BIOBASIC 210, 310, 410
RR with solid door: +2/+15ºC +10ºC +35ºC
RR with glass door: +2/+15ºC +10ºC +32ºC
RF: -25/-5ºC +10ºC +35ºC
BIOBASIC 600
RR: +2/+15ºC +10ºC +43ºC
RF: -25/-5ºC +10ºC +43ºC
The user must ensure that the cabinet is used in accordance with its
intended use. Abnormal use or use conicting with the intended use or
guidelines stipulated in the product documentation can lead to; danger
to patient safety, damage to stored items, damage to cabinet, danger to
user. Gram BIOBASIC equipment is designed to be used in a system with
monitored additional independent alarms to ensure timely reaction to
alarms and thereby maximum item safety.
BIOBASIC INSTRUCTIONS FOR USE | 7
Symbols used
Risk of burning / freezing
Risk of personal injury
Risk of material damage
Risk of electric shock
Hazard
Info
Riskofre/ammable materials
Risk of explosion/explosive materials
ATEX information
8 | BIOBASIC INSTRUCTIONS FOR USE
Installation
Initial setup steps
The cabinet is shipped with a protective
lm that shall be removed prior to use.
WARNING – POTENTIAL
ELECTROSTATIC CHARGING
HAZARD
Removing protective packaging
and lm may cause electrostatic
discharge. protective packaging and
lm shall not be removed in ATEX
zones.
The cabinet is only allowed to lay down for very short durations (for instance
handling through a doorway). If the cabinet has been laying down, the
cabinet must stand up-right for at least 24 hours prior to use. This enables
oil in the compressors to run back into place.
Avoid placement of the cabinet in a chloric/acidic environment due to risk
of corrosion.
Due to safety and operating considerations, the cabinet must not be used
outdoors. The cabinet should be installed in a dry and suciently ventilated
area. To ensure ecient operation, the cabinet should not be installed in
direct sunlight or close to heat sources.
The cabinet interior must not be exposed to corrosive atmospheres.
Clean the cabinet with a mild soap solution prior to use.
BIOBASIC INSTRUCTIONS FOR USE | 9
Cabinets equipped with legs
should be levelled as shown in the
illustrations to the left.
For cabinets equipped with
castors, the oor must be level
to ensure stable positioning and
safe use. When the cabinet is
positioned, the 2 front castors
should be locked.
Adjusting the base
Cabinets with drawers and/or glass door must be secured to a stable vertical
surface, ensuring that the cabinet cannot tip over when the drawers are drawn
to the outermost position, or the door is open. Brackets for securing the cabinet
are included from the factory.
Find the instructions for the tilt bracket below.
The anti-tilt brackets must be tted when installing the cabinet, ensuring that
the users, surroundings and stored items are not damaged.
10 | BIOBASIC INSTRUCTIONS FOR USE
Anti tilt bracket
