instruction manual & security advices for
decoration fire places of BFT (habee-Feuer) / 01.2007
Model: Centurio,Loft,TaSada
We congratulate for buying your „non-smoking-stove”
Introduction
Before using your stove for the first time, we would like to give you useful instructions and
security advice for the correct use of our product.
Your new “non-smoking stove” should only be placed on level, strong, and stable ground.
Please ensure that no flammable materials are near the stove. After removing the packaging,
as well as the lamination sheet, the stove is ready for use.
BFT decoration fire places guarantee a maximum standard of quality and security. However, it
is important to ensure that after reading the instruction manual, only responsible persons with
adequate ability handle the stove.
The BFT decoration fireplace is designed, as indicated, for decoration and the creation of a
comfortable atmosphere. The stove is not a heating stove and should not be used as a source
of heat in your home or the building in which the stove may be active.
It is not necessary to get a special permission for using the stove in normal accommodations.
Equally, while the stove must be placed away from flammable objects, it does not require a
stone hearth.
Please note: we advise you to limit usage of the stove to a maximum 8 hours per day. Heat
dissipation is a welcome effect, but not the main intention of the decoration fire place.
Starting your stove
Filling of the burning chamber
Open the drawer containing the burning chamber after moving the push-on- rosette to the
right side .(counter clockwise rotation )
Notice :. Because of the child-resistant technology the drawer can not be unintentionally
opened without moving the push-on-rosette. Open the anti dromic sliders of the burning
chamber completely by using the control unit you find on the front-panel of the drawer.
Fill in the BFT biological fuel (bio-alcohol) in the cane (enclosed in the equipment), minimum
1,5 liters, maximum 2,0 liters.
Fill the alcohol carefully in the chamber. If you spill some fuel, please clean the stove with an
absorbent towel. The towel should be removed from the stove to avoid an inflammation.
- 2 - Bio-Feuer-Technik
Inhaber Ausstellung Verwaltung Kontakt
Herbert Bee 54411 Hermeskeil 54296 Trier-Petrisberg fon 06503/953377
Ust-IdNr. DE 149 819 155 Bahnhofstraße 18 Max-Planck-Str. 8 fax 06503/981694
Bank Voba Hochwald BlZ 585 647 88 Konto 2000 24096 mobil 0171/ 770 82 98
Please note:
Never fill in more than 2 fingerbreadths under the upper edge of the burning chamber.
Shut the drawer carefully so that the bio alcohol can not be spilled !
The fuel should never be stored above room temperature. When you start your stove, it
is possible that you have a little deflagration of the fuel. Please do not be concerned about
it, this is not dangerous for you because of the construction of the chamber. The cooler
the temperature at which you store the fuel, the less deflagration there will be.
Lighting the biological fuel (bio-alcohol)
Move the push-on- rosette to the right side .(counter clockwise rotation )
Take a lighter and move it in the opening which appears after moving the push-on -rosette
Please use a lighter that has a minimum 10cm long lighting stick and simply light the
fuel/alcohol in the burning chamber.
Please note:
Be careful when lighting, it is important that the lighter has no physical contact with the
fuel, but that just the flame extends to the fuel. There should be distance of about 2-3cm
from the lighter to the fuel.
To avoid explosions due to the usage of improper lighters, we advice you to use only the
BFT lighter enclosed in your equipment.
Adjustment / consumption
With the control unit for opening and closing the chamber, you are also able to control and
adjust the size of the flame and consumption of fuel.
Please note:
When starting your stove, the burning chamber must be opened completely (control unit) to
allow maximum oxygen in the chamber. After 20 min. you can adjust the control to create the
flame size of your choice. Depending on the Model of your stove, the consumption of the
stove lies between 0,2 and 0,4 liters per hour.
When you adjust the burning chamber, please note that the fire should always burn with a
yellow flame. Please avoid blue flames as they are excessively hot.
Drowning the fire / re-filling
If you would like to put out the fire please close the burning chamber completely with the
control unit.
- 3 - Bio-Feuer-Technik
Inhaber Ausstellung Verwaltung Kontakt
Herbert Bee 54411 Hermeskeil 54296 Trier-Petrisberg fon 06503/953377
Ust-IdNr. DE 149 819 155 Bahnhofstraße 18 Max-Planck-Str. 8 fax 06503/981694
Bank Voba Hochwald BlZ 585 647 88 Konto 2000 24096 mobil 0171/ 770 82 98
Attention !
Please never restart the fire just after putting it out!
Before using the stove again, it must be completely cooled. Wait a minimum of at least 60
minutes before restarting your stove.
The entire amount of fuel initially placed in the chamber should be burned and the flame
allowed to go out on its own. It is advised to allow this process and only to manually put out
the fire in exceptional cases. As a general rule, the fuel in the stove should be burned
completely.
Fuel/biologicalalcohol
Absolutely no other type of fuel may be used in this stove. Only use BFT biological alcohol
for your BFT decoration fire place. Please note the security warnings on the fuel canister!
Ventilation and space requirements
If you would like to use the BFT decoration fire place in closed rooms, please make sure that
the room has an adequate ventilation.
To avoid a certain amount of carbon dioxide (CO2) and carbon monoxide (CO) over the
admissible limit it is important to guarantee a constant ventilation.
The room must have a minimum size of 25 m² and a volume of 80m³.
The volume of rooms that are not separated (with doors), should be 200 m³.
The rooms should be aired every 1-2 hours.
Security advice / regulations
Please avoid flammable materials near the stove and make sure that there is enough distance
between the stove and any furniture or other items in the area, at least .5 meters in all
directions.
The ventilation opening should never be covered or closed by materials like a tea kettle, etc.
Please note: The glass front and the metal surface are heated up to 90 degrees during use and
can cause burns!
Maintenance
The combustion chamber is to be examined regularly for tightness. To do this, lift the
combustion chamber from the oven body and turn it upside down over a suitable
receptacle and examine whether bio alcohol is in the safety tub and if this drips from
the safety tub into the receptacle. If this should be the case, wipe away the alcohol
with a soft, absorbent cloth. Replace the chamber into the stove. Control again after
the next combustion. Again if bio alcohol should be present and dripping, it is likely
that it does not come from a previous pouring but a defective combustion.
- 4 - Bio-Feuer-Technik
Inhaber Ausstellung Verwaltung Kontakt
Herbert Bee 54411 Hermeskeil 54296 Trier-Petrisberg fon 06503/953377
Ust-IdNr. DE 149 819 155 Bahnhofstraße 18 Max-Planck-Str. 8 fax 06503/981694
Bank Voba Hochwald BlZ 585 647 88 Konto 2000 24096 mobil 0171/ 770 82 98
If this is the case, the stove should not be lit again! Please send the defective combustion
chamber to the following address:
Of course you will get replacement free of charge.
Other details:
If you see mess in the burning chamber, please clean it with an adequate towel. Often you will
find some white residua which do not derogate the functions of the stove. If you spill some
fuel, please clean the stove as well as all other surfaces like paint, leather, flooring etc. not to
pollute other materials.
decoration ceramic wood
using of decoration ceramic wood is not allowed !
Storage of biological fuel (bio-alcohol)
We deliver the bio-alcohol in canisters of 20 litres. Every canister is officinal labeled.
Please note that there are special instructions for transporting and storing biological fuel
(dangerous goods). The instructions depend on the country.
Usually applies:
- storage in houses (basement) max. 20 litres
- storage in apartments max. 5 litres
If you want to store larger quantities you need adequate rooms.
Please make sure, that no unauthorized persons (especially children) have access to the fuel.
If you have further questions, you can always contact your fire department.
These using instruction an security advices are an elemental part of the contract of sale and
included in the scope of the delivery of BFT decoration fire places.
The underwriting of the bill of delivery confirms the receipt of the stove as well as the notice
of the using instruction and security advices.
We wish you cosy hours with your “non-smoking stove”!
Fa. BFT, Herbert Bee, Bahnhofstr. 18, D- 54411 Hermeskeil (Germany)
www.dernichtraucher.de mailto:[email protected]
- 5 - Bio-Feuer-Technik
Inhaber Ausstellung Verwaltung Kontakt
Herbert Bee 54411 Hermeskeil 54296 Trier-Petrisberg fon 06503/953377
Ust-IdNr. DE 149 819 155 Bahnhofstraße 18 Max-Planck-Str. 8 fax 06503/981694
Bank Voba Hochwald BlZ 585 647 88 Konto 2000 24096 mobil 0171/ 770 82 98
Confirmation of the first user
The customer confirm with his signature that he/her received and noticed the using
instructions and security advices (page 1-5) of the BFT decoration fire place.
The customer confirms that he/she has an adequate knowledge about the functions and
how to use the BFT decoration fire place.
He/She ensures that in case that other persons also use the stove, these persons will also
note the using instructions and security advices before using the stove and that he/she
will brief these persons how to handle the stove.
-------------------------------------- --------------------------------------------------------------
Place, date original signature
Commodity received completely, correct and free of defects
-------------------------------------- ------------------------------------------------------------
Place, date original signature
