Beurer GL48 Manuel utilisateur

This monitor is an in vitro diagnostic medical device (IVD) CE 0483.

It is important to read the warnings and instructions carefully. Ministerial authorisation dated 27/12/2022

GL48 mg/dL BLOOD GLUCOSE MONITOR (REF 463.66)

•LIGHT AND EASY TO USE

•LARGE DISPLAY SCREEN

•ILLUMINATED TEST STRIP INSERTION SLOT

•2 X CR2032 BUTTON CELL BATTERIES (INCLUDED)

•LANCING DEVICE

•DATA TRANSMISSION CABLE

•CODE FREE (NO CALIBRATION)

•AMOUNT OF BLOOD REQUIRED: 0.5 μL

•BLOOD GLUCOSE MEASUREMENT DURATION:

APPROX. 5 SECONDS

•STORES UP TO 900 VALUES (WITH DATE & TIME)

•CALCULATES AVERAGE VALUES FOR: 7, 14, 30

and 90 DAYS

•RESULTS LABELLING

•MEASUREMENT RANGE 20 –630 mg/dL

•AUTOMATIC SWITCH-OFF

50 TEST STRIPS SUITABLE FOR GL48/GL49 (REF 463.76)

•PACK OF TEST STRIPS (2 x 25 strips)

•LARGE SIZED TEST STRIP WITH ARROW FOR EASY

INSERTION

•EXPIRATION PERIOD OF 24 MONTHS (FROM

OPENING)

•TEST STRIPS MAY BE HANDLED ANYWHERE

(WITH CLEAN HANDS) WITHOUT DAMAGING THE

TEST STRIP EJECTION BUTTON

•TEST STRIP EJECTION BUTTON

This monitor is an in vitro diagnostic medical device (IVD) CE 0483.

It is important to read the warnings and instructions carefully. Ministerial authorisation dated 27/12/2022

BEURER GL48 BLOOD GLUCOSE MONITOR AND TEST STRIPS

USAGE

INITIAL USE

The batteries are already installed in the

device.

Pull off the protective cover to remove it.

BASIC SETTINGS

Switch the device on with the on/off button (6)

and press the SET button (8). When the year

display starts to flash use the green '+' and '-'

side buttons (9) to set the year and confirm

with the SET button (8).

Proceed as described above for the

day –month –hour –and minute.

Next, set the lower limit of the normal

glycaemic range (recommended value 80), the

upper limit of the normal glycaemic range

(recommended value 180) and set the

activation / deactivation of the acoustic signal

(BEEP).

PREPARING THE DEVICE FOR USE

Insert the test strip into the device so that the

contacts are pointing inside the slot as

indicated

by the arrow. The device will switch on

automatically.

After approximately 3 seconds, a flashing

blood drop symbol will appear on the screen:

This means the device is now ready to take

the reading.

TAKING A BLOOD SAMPLE

Once the sterile lancet needle is in place,

firmly position the lancing device slightly to

the side of the centre of the fingertip and

press the trigger.

A drop of blood of at least 1.2 mm in size

should form ( • correct blood drop size).

This monitor is an in vitro diagnostic medical device (IVD) CE 0483.

It is important to read the warnings and instructions carefully. Ministerial authorisation dated 27/12/2022

Make sure that the blood remains as a

droplet and does not spread over the finger.

Place the test strip across the blood drop as

shown in the image (do not remove the test

strip from the device at this stage).

The test strip will automatically siphon the

blood required for the reading and the

device will emit a BEEP.

Caution! Blood may only be drawn from the

blood input gap (at the tip of the test strip).

Should blood be deposited on or under the

strip, there is a risk that the reading may not

give an accurate measurement.

READING THE RESULT

A 5 second countdown starts automatically.

The measurement will appear in the display

with the date, time and a bar pointing at the

colour-coded target scale (at either the red,

green or yellow segment).

Use the bar to interpret the results as

follows:

The bar is in the red area = low blood

glucose levels

The bar is in the green area = normal blood

glucose levels

The bar is in the yellow area = high blood

glucose levels

Result labelling (optional)

The results can be labelled by using the

'apple button': press once for 'before meal';

twice for 'after meal'; 3 times for general

This monitor is an in vitro diagnostic medical device (IVD) CE 0483.

It is important to read the warnings and instructions carefully. Ministerial authorisation dated 27/12/2022

labelling; 4 times to cancel labelling.

Labelling is optional.

EJECTING TEST STRIPS

Use the side eject button to release the test

strip without coming into contact with it.

The device switches off automatically.

MEASUREMENT MEMORY

Measurements are automatically stored

with the date and time (holds up to 900

measurements). To display the recorded

values: turn the device on using the on/off

button and press the green ‘+’or ‘-‘side

buttons. The diary symbol is displayed

between the date and time.

AVERAGE VALUES

You can view the average glycaemic values

from the past 7, 14, 30 and 90 days. Turn

the device on with the on/off button and

press the '+' button twice. Press the green

'+' and '-' buttons to display averages with

or without labelling.

DATA TRANSFER TO PC OR THE APP

Connect the device to the PC with the cable

provided. Data may be transferred via the

Glucomemory or the HealthManager

software as well as via the

HealthManagerPro Uploader to the app on

your smartphone. With the GL48 it's

possible to transfer data to Smart Digital

Clinic and Glooko.

This monitor is an in vitro diagnostic medical device (IVD) CE 0483.

It is important to read the warnings and instructions carefully. Ministerial authorisation dated 27/12/2022

This document is available in

Click here for the video tutorial- link WWW.beurer-medical.it

BEURER MEDICAL ITALIA CUSTOMER SERVICE

TECHNICAL SUPPORT

Customer Service Hotline

•Open 7 days a week, every day of the year

•8.00 a.m. to 1.00 p.m. and 2.00 p.m. to 6.00 p.m.

www.beurer-medical.it

service-it@beurer-medical.de

INSTRUCTIONS FOR THE CORRECT DISPOSAL OF DISCARDED MATERIALS

After use, dispose of test strips and lancet needles in a puncture-proof container.

It is essential to comply with the generally applicable safety precautions for handling

blood when disposing of test strips and lancets. Dispose of all blood samples and

materials with which you or your caregivers come into contact correctly in order to

prevent injury and infection of other persons. All components of the monitor and its

accessories may come into contact with human blood and are therefore a possible

source of infection.

Empty, completely flat batteries must be disposed of through specially designated collection

boxes, recycling points or electronics retailers. It is a legal requirement to dispose of the

batteries.

This monitor is an in vitro diagnostic medical device (IVD) CE 0483.

It is important to read the warnings and instructions carefully. Ministerial authorisation dated 27/12/2022

The codes below are printed on batteries containing harmful substances:

Pb = Battery contains lead,

Cd = Battery contains cadmium,

Hg = Battery contains mercury.

For environmental reasons, do not dispose of the device or the the connection cable

in the household waste at the end of their service life. They must be disposed at at a

suitable local collection or recycling point. Dispose of the device in accordance with EC

Directive –WEEE (Waste Electrical and Electronic Equipment). If you have any

questions, please contact the local authorities responsible for waste disposal.

The fabric case may be discarded with the general waste or as instructed by your local authority
