Dperation
1,Read the instruction Ⅱ
nanual completely before operating this unit,
2,open the lock ofthe plastiG case carefully,
3.Place thc rechargeable battcry,and thcn connectthe coⅡ nector(for the
battery charging only)and the battery.The red power cab1e and black
ground cab1e shou1d conⅡcctto red ter1nina1and black terⅡlina1ofthe
battery respeGtive1y,
4.open the sunshade ofthe1nonitor;connectthc cables between the battery
and the1nonitor as above.
5.Connectthe camera cables(as point3),
6.Make sure allthe cabIes be connected correctly,then pressthc POWER
button ofthe rnonitor,you will getthc picture.
7.According to,your need,you can use the camera in diffcrcnt placc。
8.Forthe convience ofthe rccharging,a leading lino is equipped besides the
back cover,and then itis no need to getthe battery out、 vhen rccharging is
nccded,and youjust need connectthe adaptor and the1eading line togethcr.
9,Bya句 usting the brightness,contrast,color,chroma on the Ⅱlonitor button
orthe remote control,you will getthe perfcct picture.
10.Please rcGharge the battery regularly;even you haven’ t use for a1ong ti1ne。
To assurc the battery can bc used a Iongerti1ne,pleasc kecp the battery
having powerin any tiⅡ ne.
-15¨ -16-
Important InfOrmation
Connecting Your Undeiwat‘ 玎Gamera
1,The camera must not be located to look direct1y into the sun or any
other bright light sourcc as this Will not on1y resu1t in a poor image,
but、vi11eventually damage the electronics of the camera.
2.Areas with a high degrcc of contrast in the1ight levels rcquire careful
positioning of the camera to obtain the best image.
3.The best vie、 ving angle is achievcd by placing the camera in a position
where“ is looking dowⅡ on the su凵 ect.
4.Additional lighting may be requircd if watcr quaIity is poor,or in low
light conditions,
5.Always wash the camera in warn1water and soap after use,to remove
salt and other corrosivc agents.
6.Always use appropriate water safety precautions when operating the
Underwater Camcra,and ensure appropriatc levc1of supcrvision of
childrcn when near water.
PIease Read The FoⅡ owiⅡ g VIanuaI DetaⅡ s Before Using
米
Pay attention to dampphoof forthc high resolution.
扌
DOn’t break thc LCD scrccn surface,and c1ean the surface by soft c1oth ifthe
screen dirty,
艹
DOn1t dismantle the unit by unprofessiona1.
艹
Push the unit L/R switch ifⅡ nd the lettor reverse。
涞
Installthe bottom side ofthe outer shell orinner side chamfer by customer’ s
selfˉ sc1cction in accordance with bedframc。
