178 125 76-1 2018-04-04
Installation- and maintenance instruction
BG 450
J/K
3Bentone
General
Table of contents
1. Technical data _____________________________________________________________10
1.1 Burners are intended for use at:_______________________________10
1.2 Dimensions ___________________________________________________________10
1.2.1 Dimension of flange _____________________________________11
1.2.2 Capacity range____________________________________________ 12
1.2.3 Appliance categories ___________________________________13
1.2.4 Electric Specification____________________________________15
1.2.5 Working field_______________________________________________16
1.3 Description BG 550/650 _________________________________________ 18
1.3.1 Components BG 550/650____________________________ 19
1.4 Description BG 700/800/950___________________________________20
1.4.1 Components BG 700/800/950 _____________________21
2. General instruktions ____________________________________________________ 22
2.1 General instructions________________________________________________22
2.2 Operating instructions_____________________________________________ 22
2.3 Instructions____________________________________________________________22
2.4 Inspection and maintenance____________________________________22
2.5 Start up_________________________________________________________________ 22
2.6 Commissioning of installation___________________________________22
3. Installation __________________________________________________________________23
3.1 Delivery check _______________________________________________________23
3.2 Preparations for installation _____________________________________23
3.3 Gas supply ____________________________________________________________ 23
3.4 Electric connection_________________________________________________23
3.5 Skeleton diagrams _________________________________________________24
3.6 Fitting the burner to the boiler__________________________________25
3.7 Handling and lifting instruktion _________________________________ 26
3.7.1 BG 550, BG 650 _________________________________________26
3.7.2 BG 700, BG 800, BG 950 ____________________________26
3.8 Inspection of gas nozzle before commissioning _________27
4. Setting the burner _______________________________________________________ 28
4.1 Setting the combustion assembly ____________________________28
4.1.1 Setting the combustion assembly,
BG 550 & 650 __________________________________________________28
4.1.2 Setting the combustion assembly, BG 700, 800
& 950 ______________________________________________________________ 28
4.2 Setting the air damper ____________________________________________ 28
4.2.1 Calculate prepurge time: ______________________________29
4.3 Setting the gas damper __________________________________________29
4.4 Recommended excess air when using default setting 30
4.5 Determining the gas quantity for the system______________30
4.5.1 Example of how to calculate the gas quantity
(natural gas G20): _____________________________________________ 31
4.6 Calculating the quantity of gas supplied____________________32
5. Service________________________________________________________________________33
5.1 Servicing the combustion assembly _________________________33
5.2 Servicing air dampers _____________________________________________34
5.3 Replacement of damper motor, air ___________________________35
5.4 Replacement of damper motor, gas _________________________37
5.5 Flame monitoring and ionisation current check__________38
5.6 Gas nozzle BG 550/650__________________________________________40
5.7 Gas nozzle BG 550LN ____________________________________________40
5.8 Gas nozzle BG 700/800__________________________________________41
5.9 Gas nozzle BG 950 ________________________________________________42
5.10 UV detector ___________________________________________________________43
5.11 Setting the air pressure switch_________________________________44
5.12 Setting the min. gas pressure switch ________________________45
5.13 Setting the overload protection gas pressure switch___46
5.14 Setting the max. gas pressure switch _______________________47
5.15 Vibration________________________________________________________________ 48
6. Handing over of the installation ___________________________________ 49
7. Fault location, functional troubles________________________________49
8. Regulators __________________________________________________________________ 50
9. Damper motors ___________________________________________________________ 51
9.1 SQN damper motor________________________________________________ 51
9.1.1 Technical specification _________________________________51
9.1.2 Mounting position________________________________________52
9.1.3 Choice of damper motor variant____________________ 52
9.1.4 Important to remember ________________________________52
9.2 SQM damper motor _______________________________________________ 53
9.2.1 Technical specification _________________________________53
9.2.2 Mounting position________________________________________54
9.2.3 Choice of damper motor variant____________________ 54
9.2.4 Important to remember ________________________________54
10. Gas train__________________________________________________________________ 55
10.1 DMK gas butterfly damper ______________________________________55
10.1.1 Technical specification _________________________________55
10.1.2 Installation position ______________________________________ 56
10.1.3 Important to remember ________________________________56
10.2 MULTI-BLOCK VGD40… SKP15/25 ________________________ 57
10.2.1 Technical specification _________________________________57
10.2.2 Overview ____________________________________________________58
10.2.3 Installation position ______________________________________ 59
10.2.4 Adjusting the multi-block______________________________ 59
10.2.5 Actuator SKP15 __________________________________________ 59
10.2.6 Actuator SKP25 __________________________________________ 59
10.3 MULTI-BLOCK, MB-DLE 412-420 ___________________________61
10.3.1 Technical specification _________________________________61
10.3.2 Overview ____________________________________________________62
10.3.3 Pressure taps______________________________________________ 63
10.3.4 Electrical connection____________________________________ 63
10.3.5 Installation position ______________________________________ 64
10.3.6 Adjusting the multi-block______________________________ 64
11. Electric equipment___________________________________________________ 66
11.1 Safety system _______________________________________________________66
11.2 Wiring diagram ______________________________________________________ 67
11.3 Wiring diagram RWF 50:3 _______________________________________68
11.4 Wiring diagram RWF 50:2 _______________________________________69
11.5 Wiring diagram Jumo 316 _______________________________________70
11.7 List of components_________________________________________________71
11.6 Components, electrical cabinet________________________________ 71
12. LMV37 automatic control unit __________________________________ 72
12.1 System structure/function description_______________________72
12.2 General information ________________________________________________ 73
12.3 Technical Data Basic unit LMV37.4...________________________73
12.4 Connection and internal diagram _____________________________78
4Bentone
13. Operation _______________________________________________________________80
13.1 LMV37 automatic control unit__________________________________ 80
13.1.1 Explanation of display and buttons________________ 80
13.2 List of phase displays _____________________________________________82
13.3 Automatic control unit levels____________________________________83
13.3.1 Structure of parameter levels ________________________84
13.3.2 Parameter of level info__________________________________85
13.3.3 Parameter of level service_____________________________85
13.3.4 Access code for service engineer level___________ 86
13.4 Setting the automatic control unit_____________________________ 88
13.4.1 Setting an automatic control unit which has not
previously been set or lost its settings _________________88
13.4.2 The parameters below may need to be set ac-
cording to the nature of the installation._______________ 99
13.4.3 Adjusting settings of previously set automatic
control unit_____________________________________________________ 102
13.5 Backup and restore______________________________________________ 107
13.5.1 Backup ____________________________________________________ 107
13.5.2 Restore ____________________________________________________ 109
13.6 Fault status message, display of errors and info_______ 111
13.6.1 Display of errors (faults) with lockout____________ 111
13.6.2 Activating info / service mode from lockout __ 112
13.6.3 Error with safety shutdown _________________________ 113
13.6.4 Error history ______________________________________________ 114
13.7 Dispaly message of info ________________________________________ 117
13.7.1 General information ___________________________________ 117
13.7.2 Start prevention_________________________________________ 117
13.7.3 Safety loop _______________________________________________ 117
13.8 Resetting the automatic control unit _______________________ 118
13.9 Manual output _____________________________________________________ 119
13.9.1 Activation of Manually OFF in standby via the
display and operating unit________________________________ 119
13.9.2 Activation of Manually OFF in operation and ad-
justment of output via the display and operating unit
120
14. Parameter list ________________________________________________________ 121
15. Error code list________________________________________________________ 130
16. Declaration of conformity ______________________________________ 144
17. General instruction for gasburner___________________________ 146
5Bentone
4Bentone
1. General Information
This Installation and Maintenance manual:
• is to be regarded as part of the burner and must always be kept near
the installation site
• is intended for use by authorised personnel
• must be read prior to installation
• must be observed by all who work with the burner and associated
system components
• work with the burner may only be carried out by certified installers/
personnel
Enertech AB is not liable for any typographical errors and reserves the right
to make design changes without prior notice.
Safety instructions
• The burner may only be used for its intended purpose in accordance
with the product’s technical data.
• The burner may only be installed and operated by authorised
personnel.
• The product is packaged to prevent damage from occurring during
handling. Handle the product with care. Lifting equipment must be
used to lift larger packages.
• The products must be transported/stored on a level surface in a dry
environment, max. 80% relative humidity, no condensation.
Temperature -20 to +60 °C.
• Check that the burner is compatible with the boiler’s output range.
• All components must be installed without being bent, twisted or
subjected to mechanical or thermal forces which can affect the
components.
• The burner must be installed so that it complies with local regulations
for fire safety, electrical safety, and fuel distribution.
• The gas outlet from the pressure regulator shall be configured in
accordance with applicable regulations and lead to a safe area.
• Make sure when installing the equipment that there is enough space to
service the burner.
• Permitted temperature during operation -10 to +60 °C. Max 80%
relative humidity, no condensation.
• The installer must ensure that the room has adequate air supply.
• The room must comply with local regulations pertaining to its intended
use.
• The installation site must be free of chemicals.
• Burner pipes, fan wheels and air dampers may contain sharp edges.
• The surface temperature of the burner’s components can exceed 60
°C.
• Caution: The burner has moving parts, and there is risk of crushing
injuries.
172 515 01 2018-01-02
1. General Information
6Bentone
5Bentone
• The electrical installation must be professionally carried out in
accordance with applicable high voltage regulations, as per Enertech’s
recommendations.
• Before servicing, shut off the fuel supply and turn off the power to the
burner.
• Seal inspections must be performed during installation and servicing to
prevent gas leakage.
• Care should be taken by the installer to ensure that no electrical cables
or fuel lines are crushed or otherwise damaged during installation or
servicing.
• If the boiler is equipped with an access hatch, this must be equipped
with a hatch opening switch connected to the burner's safety system.
• When in operation, the burner’s noise level can exceed 85 dBA.
Use hearing protection.
• The burner must not be put into operation without proper safety and
protection devices.
• A Class BE fire extinguisher is recommended.
• It is forbidden to alter thedesign or use accessories which have not
been approved by Enertech in writing.
• Prior to operation, the following points must be checked:
-fitting and installation work has been completed and approved
-electrical installation has been correctly performed
-flue gas ducts and combustion air ducts are not blocked
-all actuators and control and safety devices are in working order and
correctly set
Actions to take if you smell gas
Turn off the equipment and the boiler. Open windows and doors. Prevent
open flames or sparking, e.g. do not turn lights on or off, do not use any
electrical appliances, do not use mobile phones. Open windows and doors.
Close the gas ball valve. Warn residents; do not use doorbells. Evacuate
the building. Notify the installer or gas supplier once the building has been
evacuated.
7Bentone
6Bentone
Control system 10 years 250,000 starts
Valve control system 10 years 250,000 starts
Pressure switch 10 years 250,000 starts
Ignition system with flame guard 10 years 250,000 starts
UV flame sensor 10000 hrs N/A
Gas pressure regulators 15 years N/A
Gas valve without seal testing 10 years 250,000 starts
Gas valve with seal testing Replacement upon fault detection N/A
Gas pressure switch 10 years 250,000 starts
Safety blow-off system 10 years N/A
Damper motor N/A 500,000 starts
Contactor 10 years 500,000 starts
Burner 1 year 3000 hrs
Inspection of electrical installation 1 year 3000 hrs
Leakage check 1 year 3000 hrs
Filter 1 year replacement at ∆p>10 mbar 3000 hrs replacement at ∆p>10
mbar
Electrodes Replacement/Cleaning 1 year Replacement/Cleaning 3000 hrs
Brake disc Replacement/Cleaning 1 year Replacement/Cleaning 3000 hrs
Motor 1 year 3000 hrs
Fan wheel 1 Year
Replacement when cleaning
needed/ imbalance
3000 h
Replacement when cleaning
needed/ imbalance
The burner and its components must be recycled according to applicable regulations.
Burner servicing schedule
Servicing must be carried out once a year or after 3000 hours of operation
Component replacement intervals
Delivery check
• Make sure everything is delivered and the goods have not been
damaged during transit.
• If something is wrong with a delivery, report it to the supplier.
• Transport damage must be reported to the shipping company.
8Bentone
I
H
E
**J
AD
E
F
G
B
C
2. Technical data
2.1 Burners are intended for use at:
• Water heating generators
• Steam generators
• Industrial applications
• Hot air generators
2.2 Dimensions
D E F G H I **J
BG 450 538 252 328 *500 *640 262 200
K
L
M
* The above dimensions are max. measurements. Depending on the
components used, the measurements may vary.
** Min. recommended distance to floor.
K L M
BG 450 M12 (Ø 210) Ø 255-290 Ø 170
2.2.1 Heat generator connection dimensions
Dimensions stated in mm
Type Length of burner
tube
Flange
measure A
Burner tube
measure B
Burner tube
measure C
BG 450
1 256 226 ø160 ø162
2 356 326 ø160 ø162
3 456 426 ø160 ø162
9Bentone
2.2.2 Capacity range
Capacity kW Gas quantity
at min. power
Nm3/h 1)
Gas quantity
at max. power
Nm3/h 1)
Max. connection
pressure mbar
Min connection
pressure mbar
see data plate
Lower heat value Hu at normal state 15°C and 1013.25 mbar EN676
Grade of gas
Natural gas
Natural gas
Propane
Butane
Gas quantity and capacity vary according to grade of gas and connection
pressure.
BG450
G20 120-550 12 55 360
G25 120-550 15 69 360
G30 120-550 5 21 360
G31 120-550 4 16 360
kWh/Nm3MJ/Nm3kcal/Nm3
G20 9.5 34.02 8126
G25 8.2 29.25 6986
G30 32.5 116.09 27728
G31 24.6 88.00 21019
2.2.3 Appliance categories
Only dry gas is permitted for use
Gerätekategorien
Appliance categories
Versorgungsdrücke
Supply pressures
Besimmungsländer
Countries of desinaion
II
2R/3R
20-360mBar
BG, CZ, DE, EE, ES, FR, GR, HU, IS,
IT, LU, LV, NO, PT, SI,
All countries
II
2H3B/P
20-360mBar AT, CH, CY, DK, FI, LT, RO, SE,
SK
II
2H3P
20-360mBar GB, IE,
II
2L3B/P
20-360mBar NL, RO
II
2E3B/P
20-360mBar PL
I
2E(R)B
20-360mBar BE
I
3P
20-360mBar BE
10 Bentone
Burner correspond to IP20
Type BG 450
Motor 450W 230V 3,3A 50Hz
The recommended main fuse
motor C10A
Fitting Naturgas, Propan, Butan
1 ½”-2”
Control power 230V 3,3A 50Hz
Sound 89 dBA ± 0,5 dBA
2.2.4 Working field
BG 450
120-550 kW
-1
0
1
2
3
4
5
6
7
8
9
100 150 200 250 300 350 400 450 500 550 600
Mbar
kW
2.2.5 Electric Specification
!Do not exceed working
field
Measurements according to EN 3746: 2010
Alt.1 The sound level of the burner can be reduced by equipping the burner
with silencer. Installation must be done so it does not prevent air supply
to the burner.
Alt.2 The burner’s noise level can be reduced by connecting the burner’s air
intake to the air duct that opens into an appropriate location. Installation
must be done so it does not prevent air supply to the burner.
