22" CORDLESS SNOW BLOWER

READ ALL INSTRUCTIONS BEFORE FIRST USE.

KEEP THIS MANUAL FOR FUTURE REFERENCE.

KEEP AWAY FROM CHILDREN.

Maximum initial battery voltage (measured without a load)

is 60 volts. Normal voltage is 54 volts.

WEAR CSA APPROVED

EYE PROTECTION

WEAR EAR

PROTECTION

WEAR A

FACE MASK

5 Year Limited Warranty on tool

3 Year on battery and charger

PRODUCT SPECIFICATIONS

22" CORDLESS SNOW BLOWER

Motor Brushless

Battery Voltage Max* 60V D.C.

Battery Capacity 4.0 Ah

Battery Runtime Max Working time up to 30 mins.

No-load running time up to 45 mins.

Charger Input 100-240V, 50/60Hz

Charger Output 63V D.C. 4A

Charge Time Max 1 hour

No Load Speed 2500 RPM

Impeller Size 8 in. (20cm)

Clearing Width 22 in. (56cm)

Clearing Depth 10 in. (25cm)

Discharge Distance Max 30ft (9m)

Plowing Capacity Max 25 Tons Per Hour

Stages Single Stage

Type of Snow Medium Usage

Directional Control 180oAdjustable Chute

LED Light 3 W

Tire size 7 in. (18cm)

Net Weight 41 lb (18.6kg)

NEED ASSISTANCE?

Call us on our toll-free customer support line:

1-833-818-4111

• Technical questions

• Replacement parts

• Parts missing from package

YF60VRX HAND-HELD TOOL HAS A 2-STEP BATTERY LATCH

INSTALLATION: The battery latch has 2 positions. Press down ﬁrmly

until battery is fully inserted. If the battery is not fully inserted and

secured in the deepest position #2 the tool will not run.

REMOVAL: Press the release button

once, the battery will release from the

ﬁrst latch position. Then hold the battery ﬁrmly, press the release

button again and pull battery out.

Latch

5554-514

TABLE OF CONTENTS

Product Speciﬁcations................................................................................... 1

YF60vRX Hand-held Tool has a 2-Step Battery Latch...................................... 1

Table of Contents .......................................................................................... 2

General Safety Instructions ........................................................................... 3

Battery & Charger Safety Instructions ............................................................ 4

Information about the battery ........................................................................ 6

Information about the charger and the charging process ................................ 7

Protection from environmental inﬂuences ..................................................... 8

Additional Safety Instructions ........................................................................ 9

Safety Instructions for Walk-Behind Snow Blowers ......................................... 9

Clearing a Clogged Discharge Chute ............................................................ 10

Electrical Safety .......................................................................................... 10

Safety Symbols ........................................................................................... 11

Know Your Cordless Snow Blower................................................................. 12

Functions .................................................................................................... 12

Getting Started ........................................................................................... 13

Assembling the Handle ............................................................................... 13

Discharge Chute Assembly .......................................................................... 14

Chute Crank Assembly ................................................................................ 15

Charging the Battery Pack ........................................................................... 16

Power Indicator ........................................................................................... 16

Starting and Stopping ................................................................................. 17

Powering on and O .................................................................................... 17

Moving the Machine & Plowing the Snow...................................................... 18

Changing Throw Direction and Throw Height ............................................... 19

Maintenance and Storage ........................................................................... 20

Servicing ..................................................................................................... 20

Storage ....................................................................................................... 20

Lifetime Lubrication (Motor and Paddle) ...................................................... 21

General Maintenance Tips ........................................................................... 21

Replacing the Rubber Plates ....................................................................... 21

Replacing the Scraper Bar ........................................................................... 22

Replacing the Belt and Pulley ...................................................................... 23

Automatic Reset ......................................................................................... 24

Troubleshooting........................................................................................... 24

Warranty...................................................................................................... 24

22" CORDLESS SNOW BLOWER

GENERAL SAFETY INSTRUCTIONS

Notice the personal safety alert symbol used in this manual to draw your attention

to a WARNING given along with the particular operating instruction. This means

that the operation requires special ATTENTION, CAUTION, and AWARENESS.

• Keep work area clean and well lit – Cluttered, dark areas invite accidents.

• Keep bystanders away – All bystanders and pets should be kept a safe distance

away from the work area.

• Dress properly – Do not wear loose clothing or jewelry. They can get caught in

moving parts. Protective rubber gloves and non-slip footwear are recommended

when working outdoors.

• Use the right product – Do not use this machine for any job except that for which

it is intended.

• CAUTION! – Exercise caution to avoid slipping or falling. Wear protective footwear

that will protect your feet and improve your footing on slippery surfaces.

• Use safety glasses – Also use safety footwear, snug-ﬁtting clothing, protective

gloves, hearing and head protection.

• Do not force the snow blower – Use the snow blower at the rate for which it was

designed to ensure optimal performance and safe operation.

• Stay alert – Watch what you are doing. Use common sense. Do not operate the

snow blower when you are tired or under the inﬂuence of alcohol or drugs.

• Do not overreach – Keep proper footing and balance at all times.

• Store indoors – When not in use, the snow blower should be kept dry and stored

out of the reach of children in a high or locked place.

• Maintain snow blower with care – Follow instructions for lubricating and changing

accessories.

WARNING: Always disengage the switch lever and remove the battery pack

before making any adjustments, inspecting, servicing, changing accessories,

cleaning the snow blower, or when any other dangerous conditions are present.

Any such operation should be performed after revolving parts inside the snow

blower stop completely. Such preventive safety measures reduce the risk of starting

the power tool accidentally.

WARNING: When replacing any parts, you must strictly observe the

instructions and procedures described in this user manual. Special care should

be paid to any rubber parts, since these parts may increase the motor load and

decrease its mechanical power if damaged.

WARNING: If you notice that the snow blower is not running properly or hear

abnormal sounds from the motor when it is in use, immediately stop the machine,

disconnect the battery, and contact your service centre.

• Surfaces – This snow blower is intended for use on paved surfaces. Do not use on

gravel, stone or other unpaved surfaces. unless the snow blower is adjusted for

such surfaces according to the instructions given in the operator’s manual.

• Moving parts present risks – Keep your face, hair, clothing, hands and feet away

from moving parts. All guards and safety attachments must be installed properly

before using the unit. Shut o and disconnect the battery before touching any

parts other than the handles and switch.

• Avoid unintentional starting – Make sure the safety switch and the switch lever are

in the o position before inserting the battery in the unit. Do not carry the snow

blower with the safety switch and the switch lever engaged.

• Do not overreach – Maintain proper footing and balance at all times. Place heels

ﬁrmly on the ground and tightly grasp the handle bar. Watch for uneven surfaces

and do not overreach. In case you fall or collide with the snow blower, inspect the

unit for any damages or cracks. When stepping backwards, be careful to avoid

obstacles beneath your feet or behind you to avoid falling.

WARNING: If the snow blower strikes any object, follow these steps: i) Stop the

snow blower. Remove the battery. ii) Inspect for damage. iii) Repair any damage

before restarting and operating the snow blower.

BATTERY & CHARGER SAFETY INSTRUCTIONS

We pay a great deal of attention to the design of every battery pack to ensure that

we supply you with batteries that are safe, durable and have a high energy density.

The battery cells have a wide range of safety devices. Each individual cell is initially

formatted and its electrical characteristic curves are recorded. This data is then

used exclusively to be able to assemble the best possible battery packs.

Despite all the safety precautions, caution must be exercised when handling

batteries. The following points must be obeyed at all times to ensure safe use.

Safe use can only be guaranteed if undamaged cells are used. Incorrect handling

of the battery pack can cause cell damage.

IMPORTANT: Analyses conﬁrm that incorrect use and poor care of high-

performance batteries are the main factors responsible for personal and/or

product damage.

WARNING: Read all safety warnings and instructions. Failure to follow the

warnings and instructions may result in electric shock, ﬁre and/or serious injury.

WARNING: Use only approved replacement batteries; other batteries may

damage the snow blower and cause it to malfunction.

CAUTION: To reduce the risk of injury, charge the 60V lithium-ion battery packs

only in their designated 60V lithium-ion charger. Other types of chargers present

risk of ﬁre, personal injury and damage. Do not wire a battery pack to a power

supply plug or car cigarette lighter. Such misuse will permanently disable or damage

the battery pack.

• Avoid dangerous environments – Do not charge the battery pack in rain, snow or

in damp or wet locations. Do not use the battery pack or charger in the presence

of explosive atmospheres (gaseous fumes, dust or ﬂammable materials) because

sparks may be generated when inserting or removing the battery pack, which

could lead to a ﬁre.

5554-514

22" CORDLESS SNOW BLOWER

• Charge in a well-ventilated area – Do not block the charger vents. Keep them

clear to allow for proper ventilation. Do not allow smoking or open ﬂames near a

charging battery pack. Vented gases may explode.

NOTE: The safe temperature range for the battery is -4oF – 113oF (-20oC – 45oC).

Do not charge the battery outside in freezing weather; charge it at room

temperature.

• Maintain charger cord – When unplugging the charger, pull the plug, not the cord,

from the receptacle to reduce the risk of damage to the electrical plug and cord.

Never carry the charger by its cord or yank it by the cord to disconnect it from the

receptacle. Keep the cord away from heat, oil and sharp edges. Make sure the

cord will not be stepped on, tripped over or subjected to damage or stress when

the charger is in use. Do not use the charger with a damaged cord or plug.

Replace a damaged charger immediately.

• Do not use an extension cord unless it is absolutely necessary – Using the wrong,

damages or improperly wired extension cord poses a risk of ﬁre and electric shock.

If an extension cord must be used, plug the charger into a properly wired 16 gauge

or larger extension cord with the female plug matching the male plug on the

charger. Make sure that the extension cord is in good electrical condition.

• Charger is rated for 120 volt AC only – The charger must be plugged into an

appropriate receptacle.

• Use only recommended attachments – Use of an attachment not recommended

or sold by the battery charger or battery pack manufacturer may result in risk

of ﬁre, electric shock or personal injury.

• Unplug charger when not in use – Make sure to remove battery packs from

unplugged chargers.

WARNING: To reduce the risk of electric shock, always unplug the charger

before performing any cleaning or maintenance. Do not allow water to ﬂow into the

charger. use a Ground Fault Circuit Interrupter (GFCI) to reduce shock hazards.

• Do not burn or incinerate battery packs – Battery packs may explode, causing

personal injury or damage. Toxic fumes and materials are created when battery

packs are burned.

• Do not crush, drop or damage battery packs – Do not use the battery pack or

charger if they have sustained a sharp blow, been dropped, run over or have been

damaged in any way (i.e. pierced with a nail, hit with a hammer, stepped on, etc.).

• Disconnect the battery pack from the tool before making any adjustments,

changing accessories, or storing tool – Such preventive safety measures reduce

the risk of starting the tool accidentally.

• Avoid unintentional starting – Make sure the safety switch and the switch lever

are in the o position before inserting the battery in the unit. Do not carry the

snow blower with the safety switch and the ON/OFF trigger engaged.

• When battery pack is not in use, keep it away from other metal objects – like

paper clips, coins, keys, nails, screws or other small metal objects that can make

a connection from one terminal to another. Shorting the battery terminals together

may cause burns or a ﬁre.

• Under abusive conditions, liquid may be ejected from the battery; avoid contact –

If contact accidentally occurs, ﬂush with water. If liquid contacts eyes, additionally

seek medical help. Liquid ejected from the battery may cause irritation or burns.

• Do not use a battery pack or tool that is damaged or modiﬁed – Damaged or

modiﬁed batteries may exhibit unpredictable behaviour resulting in ﬁre, explosion

or risk of injury.

• Do not expose a battery pack or tool to ﬁre or excessive temperature – Exposure

to ﬁre or temperature above 130oC (265oF) may cause explosion.

• Follow all charging instructions and do not charge the battery pack or tool outside

of the temperature reange speciﬁed in the instructions – Charging improperly

or at temperatures outside of the speciﬁed range may damage the battery and

increase the risk of ﬁre.

• Have servicing performed by a qualiﬁed repair person using only identical

replacement parts – This will ensure that the safety of the product is maintained.

• Do not modify or attempt to repair the tool or the battery pack – (as applicable)

except as indicated in the instructions for use and care.

• Do not disassemble – Incorrect reassembly may pose a serious risk of electric

shock, ﬁre or exposure to toxic battery chemicals. If the battery or charger are

damaged, please contact customer service center at 1-833-818-4111.

• Battery chemicals cause serious burns – Never let a damaged battery pack

contact the skin, eyes or mouth. If a damaged battery pack leaks battery

chemicals, use rubber or neoprene gloves to safely dispose of it. If skin is

exposed to battery ﬂuids, wash the aected area with soap and water and rinse

with vinegar. If eyes are exposed to battery chemicals, immediately ﬂush with

water for 20 minutes and seek medical attention. Remove and dispose of contam-

inated clothing.

• Store your battery pack and charger in a cool, dry place – Do not store the battery

pack or charger where temperatures may exceed 104oF (40oC), such as in direct

sunlight or inside a vehicle or metal building during the summer.

INFORMATION ABOUT THE BATTERY

1. The battery packs supplied with your cordless snow blower are only partially

charged. The battery packs have to be charged completely before you use the

tool for the ﬁrst time.

2. For optimum battery performance, avoid low discharge cycles by charging the

battery pack frequently.

3. Store the battery pack in a cool place, ideally at 59oF (15oC) and charged fully.

4. Lithium-ion batteries are subject to a natural aging process. The battery pack

must be replaced at the latest when its capacity falls to just 80% of its capacity

when new. Weakened cells in an aged battery pack are no longer capable of

meeting the high power requirements needed for the proper operation of your

snow blower, and therefore pose a safety risk.

5. Do not throw battery packs into an open ﬁre as this poses a risk of explosion.

6. Do not ignite the battery pack or expose it to ﬁre.

5554-514

22" CORDLESS SNOW BLOWER

7. Do not exhaustively discharge batteries. Exhaustive discharge will damage

the battery cells. The most common cause of exhaustive discharge is lengthy

storage or non-use of partially discharged batteries. Stop working as soon as the

performance of the battery falls noticeably or the electronic protection system

triggers. Place the battery pack in storage only after it has been fully charged.

8. Protect the battery and the tool from overloads. Overloads will quickly result in

overheating and cell damage inside the battery housing even if this overheating

is not apparent externally.

9. Avoid damage and shocks. Immediately replace batteries that have been

dropped from a height of more than one meter or those that have been

exposed to violent shocks, even if the housing of the battery pack appears to

be undamaged. The battery cells inside the battery may have suered serious

damage. In such instances, please read the waste disposal information for

proper battery disposal.

10. If the battery pack suers overloading and overheating, the integrated

protective cuto will switch o the equipment for safety reasons. If this

situation happens, stop the tool and let the battery cool down for a few

minutes before restarting.

IMPORTANT! Do not press the ON/OFF trigger any more if the protective

cut-o has been activated. This may damage the battery pack.

11. Use only original battery packs. The use of other batteries poses a ﬁre risk

and may result in injuries or an explosion.

INFORMATION ABOUT THE CHARGER AND THE CHARGING PROCESS

1. Please check the data marked on the rating plate of the battery charger.

Be sure to connect the battery charger to a power supply with the voltage

marked on the rating plate. Never connect it to a dierent mains voltage.

2. Protect the battery charger and its cord from damage. Keep the charger and

its cord away from heat, oil and sharp edges. Have damaged cords repaired

without delay by a qualiﬁed technician or call the customer service center at

1-833-818-4111.

3. Electrical plugs must match the outlet. Never modify the plug in any way.

Do not use any adapter plugs with grounded tools. unmodiﬁed plugs and

matching outlets will reduce the risk of electric shock.

4. Keep the battery charger, battery pack(s) and the cordless tool out of the

reach of children.

5. Do not use the supplied battery charger to charge other cordless tools.

6. During periods of heavy use, the battery pack will become warm. Allow the

battery pack to cool to room temperature before inserting it into the charger

to recharge.

7. Do not overcharge batteries. Do not exceed the maximum charging times.

These charging times only apply to discharged batteries. Frequent insertion

of a charged or partially charged battery pack will result in overcharging and

cell damage. Do not leave batteries in the charger for days on end.

8. Never use or charge batteries if you suspect that it has been more than

12 months since the last time they were charged. There is a high probability

that the battery pack has already suered dangerous damage (exhaustive

discharge).

9. Charging batteries at a temperature below 41oF (5oC) will cause chemical

damage to the cells and may cause a ﬁre.

10. Do not use batteries that have been exposed to heat during the charging

process, as the battery cells may have suered dangerous damage.

11. Do not use batteries that have suered curvature or deformation during the

charging process or those that exhibit other atypical symptoms (gassing,

hissing, cracking, etc.)

12. Never fully discharge the battery pack (maximum recommended depth of

discharge is 80%) A complete discharge of the battery pack will lead to

premature aging of the battery cells.

PROTECTION FROM ENVIRONMENTAL INFLUENCES

1. Wear suitable work clothes. Wear safety goggles.

2. Protect your cordless tool and the battery charger from moisture and rain.

Moisture and rain can cause dangerous cell damage.

3. Do not use the cordless tool or the battery charger near vapors and

ﬂammable liquids.

4. Use the battery charger and cordless tools only in dry conditions and at an

ambient temperature of 50oF - 104oF (10oC - 40oC).

5. Do not keep the battery charger in places where the temperature is liable to

reach over 105oF (40.5oC). In particular, do not leave the battery charger in

a car that is parked in the sunshine.

6. Protect batteries from overheating. Overloads, overcharging and exposure

to direct sunlight will result in overheating and cell damage. Never charge or

work with batteries that have been overheated – replace them immediately,

if possible.

7. Store the charger and your cordless tool only in dry locations with an ambient

temperature of 50oF - 104oF (10oC - 40oC). Store your lithium-ion battery pack

in a cool, dry place at a temperature of 50oF - 68oF (10oC - 20oF). Protect the

battery pack, charger and cordless tool from humidity and direct sunlight.

Only place fully charged batteries in storage.

8. Prevent the lithium-ion battery pack from freezing. Battery packs that were

stored below 32oF (0oC) for more than 60 minutes must be discarded.

9. When handling batteries, be wary of electrostatic charge. Electrostatic

discharges can damage the electronic protection system and the battery

cells. Avoid electrostatic charging and never touch the battery poles.

5554-514

22" CORDLESS SNOW BLOWER

ADDITIONAL SAFETY INSTRUCTIONS

SAFETY INSTRUCTIONS FOR WALK-BEHIND SNOW BLOWERS

• Read the operator’s manual carefully – Learn your snow blower’s applications

and limitations as well as the speciﬁc potential hazards related to this machine.

Do not use this machine for any purpose other than the one for which it was

designed. Failure to adhere to these precautions may cause mechanical defaults,

serious damage, or personal injury.

• Preliminary unit inspection – Thoroughly inspect the unit before use. Make sure

all the parts are secure and installed correctly. If you notice any abnormalities, do

not use the machine until it has been properly repaired. Always perform a test run

the ﬁrst time you use the snow blower or after replacing parts to ensure that the

unit is functioning properly.

• Preliminary area inspection – Clear the area to be plowed before each use.

Remove all objects such as rocks, broken glass, nails, wire, or string, which can

be thrown by or become entangled in the snow blower. Keep the area of operation

clear of all people, children, and pets.

• Excessive force – The snow blower was designed to respond at a certain rate for

various snow conditions for optimal safety and performance. Do not force it; keep

the applied pressure constant throughout its operation.

• Malfunctioning switch – Do not use the snow blower if the switch does not turn

it on and o. Any tool that cannot be controlled by the switch is not safe to use

and must be repaired.

• Hitting an object – If the snow blower accidentally strikes an object, ﬁrst stop the

snow blower and remove the battery; next, inspect for damage; ﬁnally repair or

replace any damaged part before restarting and operating the snow blower.

• Discharge chute safety – Never direct the snow discharge chute at the operator,

at bystanders, at vehicles, or at windows. The discharged snow, which may

contain foreign objects accidentally picked up by the snow blower, can cause

serious damage and personal injury. Do not use your hands to unclog the

discharge chute. Stop the motor before removing debris.

• Hand-held operating position – Operation of the snow blower in the hand-held

position is unsafe.

• Abnormal operation – If you ﬁnd that the snow blower is not running properly or

hear abnormal sounds or feel abnormal vibrations from the motor, immediately

stop the machine, remove the battery, and contact the customer service center

at 1-833-818-4111 for assistance.

• Noise control – When using the snow blower, respect the local laws and

regulations regarding noise control and environmental protection. To avoid

noise disturbance, you should carefully decide upon an appropriate operation

time and consider the surrounding conditions.

• When work is completed – Remove the battery pack from the snow blower

when not in use, when changing accessories, and before performing any

maintenance task.

Table des matières

Autres manuels Benchmark Souffleuse à neige

Benchmark

Benchmark 5554-513 Manuel utilisateur

Benchmark

Benchmark BS7680 Manuel utilisateur

Manuels Souffleuse à neige populaires d'autres marques

Murray

Murray 624504X4A Manuel utilisateur

Blizzard

Blizzard POWER PLOW 8100PP Manuel utilisateur

Craftsman

Craftsman 486.24837 Manuel utilisateur

Yard-Man

Yard-Man E2B5 Manuel utilisateur

ST ST 526 A Manuel utilisateur

MTD

MTD 3AA Manuel utilisateur

Toro

Toro Power TRX 1428 OHXE Manuel utilisateur

Ryobi

Ryobi RYAC800 Manuel utilisateur

Poulan Pro

Poulan Pro 416829 Manuel utilisateur

Poulan Pro

Poulan Pro 437986 Manuel utilisateur

MTD

MTD 319-180-00 Manuel utilisateur

Brute

Brute 1695565 Manuel utilisateur

Egholm

Egholm City Ranger 2250 Manuel utilisateur

Poulan Pro

Poulan Pro 420915 Manuel utilisateur

GreenWorks

GreenWorks SNF402 Manuel utilisateur

LOFTNESS

LOFTNESS 601D1 Manuel utilisateur

LOFTNESS

LOFTNESS 1082I Manuel utilisateur

LOFTNESS

LOFTNESS 481EL Manuel utilisateur
