Bellpal BP01 Manuel utilisateur
Draft 1
Bellpal One
User manual
Model number BP01
FCC ID 2AQQN-BP01
Draft 2
Regulatory information
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
BP01 is only compliant if no changes or modifications are made to the device.
BP01 is compliant with the requirement for RF exposure in US with < 5 mm separation distance
between the user and/or bystander of the device.
Client hereby declares that this product is in compliance with the essential requirements and other
relevant provisions of Directive 2014/53/EU. See http://www.bellpal.se for more information.
Draft 3
Table of contents
Regulatory information ........................................................................................................................... 2
Table of contents..................................................................................................................................... 3
Description and Intended use ................................................................................................................. 4
User guide................................................................................................................................................ 5
Usage................................................................................................................................................... 5
Pages in the App.................................................................................................................................. 6
Alarm handling in the App................................................................................................................... 9
False alarms....................................................................................................................................... 11
Updating app..................................................................................................................................... 12
Restoring ........................................................................................................................................... 13
Technical specifications......................................................................................................................... 14
Draft 4
Description and Intended use
Bellpal One is a watch with a fall detection alarm and positioning system for seniors and their
caregiver ecosystem including relatives, care providers and senior homes. Bellpal One detects and
prevents falls and enables personalized, preventative care improving the quality of life for seniors
and their loved ones. Bellpal One is for seniors living in their own homes or in senior care facilities.
The watch connects with BLE to a smartphone which in turn connects to the internet.
Figure 1. The parts of the watch
1. Case back
2. Alarm button
3. LED (RGB)
4. Winding crown
5. Bracelet attachment pins
6. Battery for the sensor
7. PCBA with sensors
8. Quartz movement
Draft 5
User guide
Usage
Pairing the watch and the app (for the first time)
1. Make sure Bluetooth is switched on in
your smartphone
2. Open the BellPal app
3. Follow the instructions in the app, i.e.
press the button on the watch for 2
seconds until the LED starts flashing
blue
Start alarm manually
1. Press and hold the button for 3 seconds
and release; the LED will start flashing
RED.
Draft 6
Cancel manual alarm
1. Press and hold the button for 10
seconds until the LED starts flashing
green and then stops.
Pages in the App
Testflight: app för att ladda ner BellPal appen för
iPhone
Bellpal: appen du använder med BellPal-klockan.
Alerts
Notifications of active alarms (your own and they you are following)
Draft 7
Followers
The people that follow you (and can see your alarms)
Alarm
Here you can start and stop your alarms
Draft 8
Following
Other users you are following
Settings
Here you can update your information, etc.
Draft 9
Alarm handling in the App
Starting and cancelling alarms
To start an
alarm, sweep the
alarm button to
the right
Draft 10
Initiated alarm with 45 seconds countdown.
During this time the alarm is only visible in your
app.
Confirmed alarm that has been sent to the
Response Center and the followers' apps.
🔔
🔔
To cancel an
alarm,
sweep the
alarm button
to the left
