Belkin F8GFPC200 Manuel utilisateur

n52te™

User Manual

P75561 F8GFPC200

n52te

TABLE OF CONTENTS

Table of Contents SECTIONS 1 2 3 4 5 6 7 8

Firmware Updates.....................................15

Update Instructions 15

Information...........................................16

Introduction ...........................................1

Features 1

System Requirements 1

Package Contents 1

Getting Started ........................................2

Driver Installation 2

Installation Verification 2

Configuring the n52te...................................3

The n52te Editor 3

n52te Editor Interface 4

Profiles 4

Single-Key Assignments 5

Multi-Key Assignments: Macros 6

Creating and Assigning a Macro 9

Using the n52te . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Keymaps 10

Profile Management 10

Profile Selection and Razer Synapse 11

Importing and Exporting Profiles 12

Using the n52te as a Default HID Device 12

Help .................................................13

Latest n52te Driver Software 13

Ergonomic Adjustments ...............................14

D-Pad Thumb-Stick 14

Palm Rest 14

n52te

Table of Contents SECTIONS 12 3 4 5 6 7 8

INTRODUCTION

System Requirements

Thank you for purchasing the Belkin n52 Tournament Edition (n52te) SpeedPad, the only purpose-built hybrid gaming tool you need

to dominate any game. Whether your passion is rooted in FPS, MMORPG, or RTS, the n52te will give you the winning edge!

The n52te is designed to work out of the box as a standard Human Interface Device (HID) keyboard. Please install and use the n52te

Editor and driver package for advanced programmability and portability.

Features

• 15programmablerapid-responsebuttons

• Programmable3-wayscrollwheel

• Buttonandscroll-wheelbacklighting

• Programmable8-waydirection-pad(d-pad)withremovablejoystick

• Adjustablesoft-touchhandrest

• RazerSynapse™onboardmemory

• Windows®XP/XP 64-bit or Windows Vista®/Vista 64-bit

• MacOS®X v10.2.8 or higher

• AfreeUSBport

• CDorDVDdrive

• 35MBfreehard-diskspace

• DirectX®Compatible Video Card

Package Contents

• Belkinn52te

• QuickStartGuide

• n52teEditorProgrammingSoftware,PoweredbyRazer

n52te

Table of Contents SECTIONS 1 23 4 5 6 7 8

GETTING STARTED

Installation Verification

1. To check if installation was successful, right-click on “My Computer”

and left-click on “Properties”. Then left-click on “Hardware” and then

on the “Device Manager” button.

2. Check to make sure that the Device Manager list includes:

a. A new entry under Human Interface Devices, “n52te”.

b. A new entry under Human Interface Devices, “Virtual HID Device”.

Driver Installation

1. Insert the n52te Installation CD into your PC’s CD/DVD drive.

2. Driver installation will begin shortly. If it does not, click the

“Start” button and choose “Run”. Click “Browse” and choose

your CD drive. Select “setup.exe” and click “OK”.

3. Follow the on-screen instructions to continue with the driver

installation.

4. After the installation is complete, click “Finish” and reboot

when prompted.

5. After your PC boots up, connect the n52te to an available USB

port on your computer.

6. Please allow Windows to detect and fully initialize the n52te.

Do not disconnect or reboot/shut down your system during

this process.

7. Once driver initialization has finished, please reboot your

system when prompted to do so by the installer.

n52te

Table of Contents SECTIONS 1 2 34 5 6 7 8

CONFIGURING THE n52te

Mouse – Program n52te to emulate mouse clicks or scroll-wheel

functions.

Polling Rate – Sets the polling rate to: 125Hz, 500Hz, or 1000Hz.

Tip: You need to reduce the polling rate if your computer does not

support USB 2.0.

Razer Synapse – Store one of your profiles in the onboard memory

to take it with you. The custom profile stored in the Synapse onboard

memory will be available on any PC or Mac computer, even without the

n52te driver or Editor application installed!

Tip: You will still need the driver and Editor software installed on the

host system if you want to make any changes to the stored profile.

The n52te Editor

The n52te Editor is the main programming and management tool for your

n52te. The n52te Editor allows you to customize the n52te to provide you

with the best gaming experience possible. Examples of programmable

functions are:

Single Key – Assign a single keyboard key to an n52te button.

Macros – Record a sequence of keyboard keystrokes, and/or mouse-

button presses that can be saved and played back by the n52te at a

later time.

Keymap Selector – Switch between the three color Keymaps (Blue,

Green, Red) and effectively triple the number of functions you can

program in a single profile. The default Keymap is Blue.

n52te

Table of Contents SECTIONS 1 2 34 5 6 7 8

CONFIGURING THE n52te

n52te Editor Interface

This is the user interface for the n52te Editor application.

The main screen consists of:

View of the Device – Displays which keys you are programming.

Macro Editor – Allows you to define and edit sequences of keyboard

keystrokes, and/or mouse-button presses to generate your own custom

macros.

Profile Selection – Allows you to select and load pre-saved

customizations to your n52te. For more profile management information,

please see the “Profile Management” section of this manual.

Help – Displays the Help guide for the n52te Editor.

Profiles

Profiles are customized button mappings and programmable functions

for a specific application that can be saved and loaded to the n52te.

This section will walk you through typical profile-creation steps using the

n52te Editor. In general, creating a profile consists of mapping button

functions, recording and assigning macros, configuring Auto-Switching

options, and saving those customizations as a profile.

n52te

Table of Contents SECTIONS 1 2 34 5 6 7 8

CONFIGURING THE n52te

Single-Key Assignments

Any n52te button, d-pad directions, and scroll-wheel directions can be

programmed to emulate any key on a typical computer keyboard.

1. For the n52te button you wish to configure, left-click to bring up a menu of

programmable functions.

2. Selecting “Single Key” from the menu will bring up the “Single Key”

assignment dialog box. This screen is used to assign a single keyboard key

to that n52te button.

3. At this point, press the desired keyboard key. The screen will display the

name of the key you just pressed.

4. Click “OK” if you are happy with the current assignment. Pushing that

button will now output the key with which it was just programmed.

n52te

Table of Contents SECTIONS 1 2 34 5 6 7 8

CONFIGURING THE n52te

Multi-Key Assignments: Macros

Macros are recorded sequences of keyboard keystrokes and/or mouse-

button presses that can be saved and played back by the n52te at a

later time.

The Macro Editor pane allows you to create, edit, and save macros.

Saved macros can then be assigned to any n52te button across the

three available Keymaps and can be used in any profile.

Macro Sequence List (Current Macro Assignment) – This is the

sequence of keystrokes, delays, and other functions that are played

back when the macro is executed. As you record a macro, the

keystrokes that you type, along with delays between each sequence of

events, will be listed in the “Current Macro Assignment” window.

Tip: You cannot record mouse-click commands during the recording

phase, but you can add them manually after the recording phase by

selecting from the mouse figure.

n52te

Table of Contents SECTIONS 1 2 34 5 6 7 8

CONFIGURING THE n52te

Record – Begins macro recording.

Stop – Stops macro recording.

Move Up – Move a macro event UP in the sequence list. Select the desired

event with your mouse and left-click on “Move Up” until it is in the desired

position.

Move Down – Move a macro event DOWN in the sequence list. Select the

desired event with your mouse and left-click on “Move Down” until it is in the

desired position.

Select All – Selects all events in the “Current Macro Assignment” sequence list.

Select All Delays – Selects all time delays in the sequence list.

Insert Delay – Allows you to manually insert a time delay in the sequence

list. Simply select the macro event you want the delay to follow, choose the

desired duration from the drop-down menu, and click the “Insert Delay”

button.

Ignore Delays Between Events – Toggles whether or not time delays

between each macro event should be played back when the macro is

executed. This feature is off by default.

Mouse Button – Allows you add mouse-button emulation into a macro by

choosing the desired button from the mouse figure.

n52te

Table of Contents SECTIONS 1 2 34 5 6 7 8

CONFIGURING THE n52te

Advanced functions that can be inserted into the “Current Macro

Assignment” sequence list from this window include:

1. Basic Commands – Allows you to insert operations from a list of basic

commands supported in Windows OS.

2. Additional Commands – Allows you to insert operations from a list of

additional commands supported in Windows OS.

3. Media Functions – Allows you to insert operations for the default

media player using a list of media commands.

4. Macro – Allows you to insert existing macros into the current one, thus

creating a complex nested macro.

Macro Behavior

The n52te can provide even deeper customization by allowing you to

determine how you want your macros to be played back when triggered.

1. Run Times: X – This setting determines how many times the macro

will be executed when triggered. The default is 1, meaning that the

macro will play back one time when triggered.

2. Repeat while pressed. – This setting will force the macro to repeat

continuously while the assigned button is held down.

3. Repeat until next key is pressed. – This setting will force the macro

to repeat continuously until the next n52te button is pressed.

Advanced – This is a list of advanced macro functions that can be

inserted into the macro sequence list.
