Beko VCS 6135 AR Manuel utilisateur

Upright

Vacuum Cleaner

User Manual

01M-8837693200-1118-01

01M-8837683200-1118-01

VCS 6135 AR

VCS 6135 AB

Please read this user manual first!

Dear Valued Customer,

Thank you for selecting this Beko appliance. We hope that you get the best results from

your appliance which has been manufactured with high quality and state-of-the-art

technology. Therefore, please read this entire user manual and all other accompanying

documents carefully before using the appliance and keep it as a reference for future

use. If you handover the appliance to someone else, give the user manual as well.

Follow the instructions by paying attention to all the information and warnings in the

user manual.

Remember that this user manual may also apply to other models. Differences between

models are explicitly described in the manual.

Meanings of the Symbols

Following symbols are used in various sections of this manual:

Important information and useful

hints about usage.

AWARNING:

Warnings against

dangerous situations concerning the

security of life and property.

Protection class for electric shock.

This product has been produced in environmentally friendly modern facilities.

This product does

not contain PCB’s

Upright Vacuum Cleaner / User Manual

3 / 15 EN

CONTENT

1 Important safety and

environmental instructions 4-6

1.1 General safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.2 Compliance with WEEE Directive and

Disposing of the Waste Product. . . . . . . . . . . . . . . . 5

1.3 Compliance with RoHS Directive . . . . . . . . . . . 5

1.4 Package information . . . . . . . . . . . . . . . . . . . . . . . 5

1.5 Plug Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2 Your stick vacuum cleaner 7-8

2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

2.2 Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

3 Usage 9-11

3.1 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.2.1 Installation of the body and the handle . . 9

3.3 Operating the appliance. . . . . . . . . . . . . . . . . . . . 9

3.3.1 Using the brush roller . . . . . . . . . . . . . . . . . . . . 9

3.4 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

4 Cleaning and care 12-14

4.1 Cleaning the dust container. . . . . . . . . . . . . . . 12

4.2 Cleaning the pre-motor filter . . . . . . . . . . . . . 12

4.3 Cleaning the post motor filter. . . . . . . . . . . . . 13

4.4 Cyclone seperator. . . . . . . . . . . . . . . . . . . . . . . . . 13

4.5 Replace the brush and belt. . . . . . . . . . . . . . . . 13

4.6 Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

5 Guarantee 15

4 / 15 EN

Upright Vacuum Cleaner / User Manual

This section contains safety

instructions that will help protect

from risk of personal injury or

property damage.

Failure to follow these instructions

voids any granted warranty.

1.1 General safety

•This appliance complies with

international safety standards.

This appliance can be used by

children aged from 8 years and

above and persons with reduced

physical, sensory or mental

capabilities or lack of experience

and knowledge if they have been

given supervision or instruction

concerning use of the appliance

in a safe way and understand

the hazards involved. Children

shall not play with the appliance.

Cleaning and user maintenance

shall not be made by children

without supervision.

•If the power cable or the appliance

itself is damaged, do not use it.

Contact an authorised service.

•Your mains power supply should

comply with the information

supplied on the rating plate of the

appliance.

•The mains plug is fitted with

a 13A fuse. Ensure the same

rating fuse is used should it need

replacement.

•Do not use the appliance with an

extension cable.

•Prevent damage to the power

cable by not squeezing, bending,

or rubbing it on sharp edges.

•Do not touch the appliance or its

plug when it is plugged in if your

hands are damp or wet.

•Do not pull the power cable when

unplugging the appliance.

•Do not vacuum flammable

materials (cigarette ash, fireplace

ash).

•Do not vacuum water or other

liquids.

•Keep turbo brush away from hair,

face, fingers, uncovered feet, or

loose clothing.

•Protect the appliance from rain,

humidity and heat sources.

•Never use the appliance in or

near places where combustible or

inflammable ambience or places

are present.

•Unplug the appliance before

cleaning and maintenance.

1Important safety and environmental instructions

Upright Vacuum Cleaner / User Manual

5 / 15 EN

•Do not immerse the appliance

or its power cable in water for

cleaning.

•Do not attempt to dismantle the

appliance in any way other than

that shown in the Cleaning and

Care section of this user manual.

•Only use the original parts or

parts recommended by the

manufacturer.

•Do not clean the particles such as

cement, plaster and compressed

paper in order to prevent the filter

from being clogged and the motor

being damaged.

•Do not use the appliance without

filters; otherwise it can get

damaged.

•If you keep the packaging

materials, store them out of the

reach of children.

1Important safety and environmental instructions

1.2 Compliance with WEEE

Directive and Disposing of the

Waste Product

This product complies with EU WEEE

Directive (2012/19/EU). This product

bears a classification symbol for waste

electrical and electronic equipment

(WEEE).This product has been manufactured with

high quality parts and materials which can be

reused and are suitable for recycling. Do not

dispose of the waste product with normal

domestic and other wastes at the end of its service

life. Take it to the collection center for the recycling

of electrical and electronic equipment.

Please consult your local authorities to learn about

these collection centers.

1.3 Compliance with RoHS

Directive

The product you have purchased complies with EU

RoHS Directive (2011/65/EU). It does not contain

harmful and prohibited materials specified in the

Directive.

1.4 Package information

Packaging materials of the product are

manufactured from recyclable materials

in accordance with our National

Environment Regulations. Do not dispose of the

packaging materials together with the domestic or

other wastes. Take them to the packaging material

collection points designated by the local

authorities.

6 / 15 EN

Upright Vacuum Cleaner / User Manual

1.5 Plug Wiring

The moulded plug on this appliance incorporates

a 13 A fuse. Should the fuse need to be replaced

an ASTA approved BS1362 fuse of the same rating

must be used. Do not forget to refit the fuse cover.

In the event of losing the fuse cover, the plug must

not to be used until a replacement fuse cover has

been fitted. Colour of the replacement fuse cover

must be the same colour as that visible on the pin

face of the plug Fuse covers are availabe from any

good electrical store.

•

Fiting a different plug

•As the colours of the wires in the mains lead

of this appliance may not correspond with the

coloured markings identifying the terminals on

your plug, proceed as follows:

•Brown cable = L (Live)

•Blue cable = N (Neutral)

•Green/yellow cable must be connected to

ground (E) line

•With the alternative plugs a 13 A fuse must be

fitted either in the plug or adaptore or in the

main fuse box. If in doubt contact a qualified

electrician.

1Important safety and environmental instructions

Upright Vacuum Cleaner / User Manual

7 / 15 EN

2Your stick vacuum cleaner

2.1 Overview

11 17

8 / 15 EN

Upright Vacuum Cleaner / User Manual

2Your stick vacuum cleaner

1. Handle

2. Turbo brush storage hook

3. Tube

4. Special Turbo/Animal Brush (VCS 6135 AR)

5. Hose

6. Dust brush

7. Nozzle crevice tool

8. Handle release button

9. Dust container release button

10. Dust container handle

11. Hose and vacuum suction button

12. Brush switch button

13. Dust container

14. Exhaust filter

15. Brush

16. Hose / floor suction knob

17. Cord storage hook

2.2 Technical data

Supply voltage :

220-240V~ 50-60 Hz

Power :

700 W

Upright Vacuum Cleaner / User Manual

9 / 15 EN

3.1 Intended use

This appliance is intended for domestic use. It is

not suitable for industrial use.

3.2 Installation

3.2.1 Installation of the body

and the handle

1. Remove the hose from the hose socket.

2. Fit the hose into the handle part and fix it by

turning the hose clockwise.

3. Insert the handle into the main body (you will

hear a click tone).

Click!

4. To remove the handle, press the handle release

button and pull out the handle from the main

body.

3Usage

3.3 Operating the appliance

1. Pull out the power cord from the cord storage

hook.

2. Plug in the appliance.

3. Adjust the hose / floor suction knob according

the use of brush roller or tools.

4. Press the on/off button to switch on your

appliance.

5. When you press on/off button to start the

appliance.

6. After using the appliance, switch it off by

pressing the On/off button.

3.3.1 Using the brush roller

Adjust the hose / floor suction knob to the floor type.

Floor

Hose

You can adjust the brush roller by using the brush

switch button.

Push the brush switch button for carpet.

– The brush roller is in use.

10 / 15 EN

Upright Vacuum Cleaner / User Manual

3Usage

Push the brush switch button for hard floor again.

– The brush roller is not in use.

The brush roller is not in use when

the appliance is in upright position.

3.4 Accessories

You can store the 3in1 accessory tool on the main

body tool holder.

Use the accessories with the tube

1. Remove the tube from the main body by

pushing the tube release button.

2. Assemble the required accessory onto the tube.

3. Adjust the hose / floor suction knob to the floor

type.

Floor

Hose

Use the accessories with the hose

1. To use the accessories remove the hose from

the handle part.by turning it anticlockwise.

2. Assemble the required accessory onto the hose.

3. Adjust the hose / floor suction knob to the hose

type.

Floor

Hose

Crevice tool

Attach the crevice tool to the inner side of the

hose/tube.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Beko Aspirateur

Beko

Beko 01M-8911633200-3021-02 Manuel utilisateur

Beko

Beko VCO 62602 AB Manuel utilisateur

Beko

Beko BKS 1410 Manuel utilisateur

Beko

Beko VCM 71602 AD Manuel utilisateur

Beko

Beko BKS 2420 Manuel utilisateur

Beko

Beko VCW 30915 WR Manuel utilisateur

Beko

Beko SD 8041 K Manuel utilisateur

Beko

Beko BKS 1310 EY Manuel utilisateur

Beko

Beko VRW 80318 VB Manuel utilisateur

Beko

Beko VRR 84314 VB Manuel utilisateur

Beko

Beko BKS 1330 C Manuel utilisateur

Beko

Beko VRT 94929 VV Manuel utilisateur

Beko

Beko VRR 60314 VW Manuel utilisateur

Beko

Beko VCO 42701 AB Manuel utilisateur

Beko

Beko VRR 60110 VW Manuel utilisateur

Beko

Beko 01M-8837863200-4719-08 Manuel utilisateur

Beko

Beko 01M-8912603200-2322-01 Manuel utilisateur

Beko

Beko VRT 74225 VI Manuel utilisateur

Beko

Beko 01M-8911833200-1722-08 Manuel utilisateur

Beko

Beko VRR 60314 VW Manuel utilisateur

Beko

Beko VCC 7324 WI Manuel utilisateur

Beko

Beko VCO32801AR Manuel utilisateur

Beko

Beko VRT 94929 VI Manuel utilisateur

Beko

Beko VCO 62607 AD Manuel utilisateur

Manuels Aspirateur populaires d'autres marques

Bissell

Bissell LittleGreen Proheat 1425 Series Manuel utilisateur

Panasonic

Panasonic MC-YL637S147-AE Manuel utilisateur

NEFF

NEFF N17XH10 0 Series Manuel utilisateur

LG A9 Series Manuel utilisateur

Oreck

Oreck Cordless Captura BK51700 Series Manuel utilisateur

Kogan

Kogan KAVACROBVWA Manuel utilisateur

Kränzle

Kränzle VENTOS 50 ID Guide de l'utilisateur

EVVO

EVVO Ai35 Manuel utilisateur

DeWalt

DeWalt DWH200D Manuel utilisateur

Pontec

Pontec Pondomatic Vacuum Cleaner Manuel utilisateur

Cleanmaxx

Cleanmaxx PC-P007E Manuel utilisateur

Exido

Exido 240-114 Manuel utilisateur

RIDGID

RIDGID WD1685AU0 Manuel utilisateur

Ezviz

Ezviz RE4P Manuel utilisateur

STG global

STG global TANVAC HDV3000 Manuel utilisateur

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuel utilisateur

Factory

Factory M3340 Manuel utilisateur

Shop-Vac

Shop-Vac VN92 SERIES Manuel utilisateur
