Beko FS 129930N Manuel utilisateur

58 5063 0000/ AB

1/2

EN / FR / BG / PL

Congélateur

Manuel d'utilisation

Фризер

Ръководство за употреба

Instrukcja użytkowania

Komora zamrażalnika

FS 129930N - FS 127330N

Freezer

User manual

Please read this user manual first!

Dear Customer,

We hope that your product, which has been produced in modern plants and

checked under the most meticulous quality control procedures, will provide you

an effective service.

Therefore, read this entire user manual carefully before using the product and

keep it as a reference. If you handover the product to someone else, give the

user manual as well.

The user manual will help you use the product in a fast and safe way.

• Read the manual before installing and operating the product.

• Make sure you read the safety instructions.

• Keep the manual in an easily accessible place as you may need it later.

• Read the other documents given with the product.

Remember that this user manual is also applicable for several other models.

Differences between models will be identified in the manual.

Explanation of symbols

Throughout this user manual the following symbols are used:

CImportant information or useful tips.

AWarning against dangerous conditions for life and property.

BWarning against electric voltage.

SUPPLIER’S NAME MODEL IDENTIFIER (*)

INFORMATION

The model information as stored in the product data base

can be reached by entering following website and searching

for your model identiﬁer (*) found on energy label.

https://eprel.ec.europa.eu/

1 Your freezer 3

2Important Safety Warnings4

Intended use ...............................................4

General safety ........................................... 5

For products with a water dispenser;9

Child safety ..................................................9

Compliance with WEEE Directive and

Disposing of the Waste Product: .......9

Package information................................9

HC warning.................................................10

Things to be done for energy saving10

3 Installation 11

Points to be paid attention to when the

relocation of the cooler/freezer........ 11

Before you start the cooler/freezer,11

Electrical connection ............................. 11

Disposing of the packaging.................12

Disposing of your old cooler/freezer12

Placing and Installation.........................12

Adjusting the legs...................................13

CONTENTS

4 Preparation 14

Reversing the doors...............................15

5 Using your cooler/freezer16

Setting the operating temperature.16

Freezing.......................................................17

Defrosting of the appliance................18

6 Maintenance and cleaning20

Protection of plastic surfaces .......... 20

7 Troubleshooting 21

1Your freezer

1. Control Panel

2. Flap (Fast-Freeze compartment)

3. Ice cube tray & Ice bank

4. Drawers

5. Adjustable front feet

CFigures that take place in this instruction manual are schematic and may not

correspond exactly with your product. If the subject parts are not included in the

product you have purchased, then it is valid for other models.

MAX.

2Important Safety Warnings

Please review the

following information.

Failure to observe this

information may cause

injuries or material

damage. Otherwise, all

warranty and reliability

commitments will

become invalid.

The service life of your

product is 10 years.

During this period,

original spare parts will

be available to operate

the product properly.

Intended use

WARNING:

Keep ventilation

openings, in the

appliance enclosure

or in the built-

instructure, clear of

obstruction.

WARNING:

Do not use

mechanical

devices or

other means to

accelerate the

defrostingprocess,

other than those

recommended by

the manufacturer.

WARNING:

Do not damage

the refrigerant

circuit.

WARNING:

Do not use

electrical

appliances inside

the food storage

compartments

of the appliance,

unless they

are of the type

recommended by

the manufacturer.

This appliance is intended

to be used in household

and similar applications

such as

– staff kitchen areas in

shops, offices and other

working environments;

– farm houses and by

clients in hotels, motels

and other residential type

environments;

– bed and breakfast type

environments;

– catering and similar

non-retail applications.

General safety

• When you want to

dispose/scrap the

product, we recommend

you to consult the

authorized service

in order to learn the

required information

and authorized bodies.

• Consult your

authorized service for

all your questions and

problems related to

the cooler/freezer. Do

not intervene or let

someone intervene

to the cooler/freezer

without notifying the

authorised services.

• For products with a

freezer compartment;

Do not eat cone ice

cream and ice cubes

immediately after you

take them out of the

freezer compartment!

(This may cause

frostbite in your mouth.)

• For products with a

freezer compartment;

Do not put bottled

and canned liquid

beverages in the

freezer compartment.

Otherwise, these may

burst.

• Do not touch frozen

food by hand; they may

stick to your hand.

• Unplug your cooler/

freezer before cleaning

or defrosting.

• Vapor and vaporized

cleaning materials

should never be used in

cleaning and defrosting

processes of your

cooler/freezer. In such

cases, the vapor may

get in contact with the

electrical parts and

cause short circuit or

electric shock.

• Never use the parts

on your cooler/freezer

such as the door as a

means of support or

step.

• Do not use electrical

devices inside the

cooler/freezer.

• Do not damage the

parts, where the

refrigerant is circulating,

with drilling or cutting

tools. The refrigerant

that might blow out

• Do not use mechanical

devices or other means

to accelerate the

defrosting process,

other than those

recommended by the

manufacturer.

• This product is not

intended to be used by

persons with physical,

sensory or mental

disorders or unlearned

or inexperienced

people (including

children) unless they are

attended by a person

who will be responsible

for their safety or who

will instruct them

accordingly for use of

the product

• Do not operate a

damagedcooler/freezer.

Consult with the service

agent if you have any

concerns.

• Electrical safety of your

cooler/freezer shall be

guaranteed only if the

earth system in your

house complies with

standards.

• Exposing the product

to rain, snow, sun and

wind is dangerous with

when the gas channels

of the evaporator, pipe

extensions or surface

coatings are punctured

causes skin irritations

and eye injuries.

• Do not cover or block

the ventilation holes on

your cooler/freezer with

any material.

• Electrical devices must

be repaired by only

authorised persons.

Repairs performed by

incompetent persons

create a risk for the user.

• In case of any failure or

during a maintenance or

repair work, disconnect

your cooler/freezer’s

mains supply by either

turning off the relevant

fuse or unplugging your

appliance.

• Do not pull by the cable

when pulling off the

plug.

• Place the beverage with

higher proofs tightly

closed and vertically.

• Never store spray cans

containing flammable

and explosive

substances in the

cooler/freezer.

respect to electrical

safety.

• Contact authorized

service when there is a

power cable damage to

avoid danger.

• Never plug the cooler/

freezer into the

wall outlet during

installation. Otherwise,

risk of death or serious

injury may arise.

• This cooler/freezer

is intended for only

storing food items. It

must not be used for

any other purpose.

• Label of technical

specifications is located

on the left wall inside

the cooler/freezer.

• Never connect your

cooler/freezer to

electricity-saving

systems; they may

damage the cooler/

freezer.

• If there is a blue light on

the cooler/freezer, do

not look at the blue light

with optical tools.

• For manually controlled

cooler/freezers, wait

for at least 5 minutes to

start the cooler/freezer

after power failure.

• This operation manual

should be handed in to

the new owner of the

product when it is given

to others.

• Avoid causing damage

on power cable when

transporting the cooler/

freezer. Bending cable

may cause fire. Never

place heavy objects on

power cable.

• Do not touch the plug

with wet hands when

plugging the product.

• Do not plug the cooler/

freezer if the wall outlet

is loose.

• Water should not be

sprayed on inner or

outer parts of the

product for safety

purposes.

• Do not spray substances

containing inflammable

gases such as propane

gas near the cooler/

freezer to avoid fire and

explosion risk.

• Never place containers

filled with water on top

of the cooler/freezer; in

the event of spillages,

this may cause electric

shock or fire.

• Do not overload the

cooler/freezer with

food. If overloaded,

the food items may fall

down and hurt you and

damage cooler/freezer

when you open the

door.

• Never place objects

on top of the cooler/

freezer; otherwise,

these objects may fall

down when you open

or close the cooler/

freezer's door.

• As they require a precise

storage temperature,

vaccines, heat-sensitive

medicine and scientific

materials and etc.

should not be kept in

the cooler/freezer.

• If not to be used for

a long time, cooler/

freezer should be

unplugged. A possible

problem in power cable

may cause fire.

• Cooler/freezer may

move if adjustable legs

are not properly secured

on the floor. Properly

securing adjustable legs

on the floor can prevent

the cooler/freezer to

move.

• When carrying the

cooler/freezer, do not

hold it from door handle.

Otherwise, it may be

snapped.

• When you have to place

your product next to

another cooler/freezer

or freezer, the distance

between devices

should be at least 8cm.

Otherwise, adjacent

side walls may be

humidified.

• The product shall never

be used while the

compartment which

is located at the top or

back of your product

and in which electronic

boards are available

(electronic board box

cover) (1) is open.

For products with a

water dispenser;

Pressure of water mains

should be minimum

1 bar. Pressure of

water mains should be

maximum 8 bars.

• Use only potable water.

Child safety

• If the door has a lock,

the key should be kept

away from reach of

children.

• Children must be

supervised to prevent

them from tampering

with the product.

Compliance with WEEE

Directive and Disposing of

the Waste Product:

This product complies

with EU WEEE Directive

(2012/19/EU). This product

bears a classification

symbol for waste electrical

and electronic equipment

(WEEE).

This product has been manufactured

with high quality parts and materials

which can be reused and are suitable

for recycling. Therefore, do not dispose

the product with normal domestic

waste at the end of its service life.

Take it to a collection point for the

recycling of electrical and electronic

equipment. Please consult your

local authorities to learn the nearest

collection point. Help protect the

environment and natural resources by

recycling used products. For children’s

safety, cut the power cable and break

the locking mechanism of the door, if

any, so that it will be non-functional

before disposing of the product.

Package information

Packaging materials of the product

are manufactured from recyclable

materials in accordance with our

National Environment Regulations. Do

not dispose of the packaging materials

together with the domestic or other

wastes. Take them to the packaging

material collection points designated

by the local authorities.

Autres manuels pour FS 129930N

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Beko Congélateur

Beko

Beko CDA 554 Manuel du propriétaire

Beko

Beko HSA 24540 Manuel utilisateur

Beko

Beko HSA32530N Mode d’emploi

Beko

Beko RFNE280K32S Manuel utilisateur

Beko

Beko HS22340 Mode d’emploi

Beko

Beko RFSM200T40WN Manuel utilisateur

Beko

Beko CDA751F Manuel utilisateur

Beko

Beko RFNE 271K30WN Manuel utilisateur

Beko

Beko FS5552W Manuel du propriétaire

Beko

Beko HSA47530N Mode d’emploi

Beko

Beko GF200M40WCHN Manuel utilisateur

Beko

Beko FSA13030N Manuel utilisateur

Beko

Beko HSA 47520 Mode d’emploi

Beko

Beko 7042 MB Manuel utilisateur

Beko

Beko CDA 664 F Instructions d'installation

Beko

Beko BFNA247E30SN Mode d’emploi

Beko

Beko CF374W Manuel utilisateur

Beko

Beko HSA20542 Manuel utilisateur

Beko

Beko BUFR2715PSIM Manuel utilisateur

Beko

Beko GTM30041CH Manuel utilisateur

Beko

Beko FFP3579 Mode d’emploi

Beko

Beko RSF 73350 FI Manuel utilisateur

Beko

Beko RFNE290L31WN Manuel utilisateur

Beko

Beko RFNE312K21X Manuel utilisateur

Manuels Congélateur populaires d'autres marques

Siemens

Siemens GU..D SERIES Manuel utilisateur

Omcan

Omcan FR-CN-0155 Manuel utilisateur

Electrolux

Electrolux ARCTIS G 8 60 50-6I Manuel utilisateur

Electrolux

Electrolux EUF2042AOX Manuel utilisateur

Dometic

Dometic CoolFreeze CFX95DZ Manuel utilisateur

Electrolux

Electrolux EUF7000W1 Manuel utilisateur

Polar Electro

Polar Electro CT330 Manuel utilisateur

MPM

MPM MPM-145-SK Series Manuel utilisateur

SAF

SAF PRESTOTIG 200AC/DC Guide rapide

Zanussi

Zanussi ZFT11407WA Manuel utilisateur

AEG

AEG A63190GT Manuel utilisateur

AEG

AEG A81000TNW0 Manuel utilisateur

Matsui

Matsui MUC50S15E Manuel utilisateur

NEFF

NEFF G4344X8 Manuel utilisateur

Frigidaire

Frigidaire FV 1246 H Manuel utilisateur

Frigidaire

Frigidaire FFC13K1AW Manuel utilisateur

Electrolux

Electrolux EU 2400C Manuel utilisateur

Electrolux

Electrolux SG235NFCN Manuel utilisateur
