Beko BLSD3577 Manuel utilisateur
Built-In Cooler
Instruction of use
BLSD3577
EN
Please read these instructions first before using your
appliance
Thank you for choosing a Beko appliance.
Please take some time to read this user manual before using your appliance,
to ensure you know how to safely operate the controls and functions.
Carefully follow all unpacking and installation instructions to ensure the
appliance is correctly connected and fitted prior to use.
Please write your product model and serial number on the last page of this
user manual, and store in a safe location close to the appliance for easy
future reference.
This user manual may also be applicable for several other models.
Differences between models will be listed.
If you have any questions or concerns, please call our contact centre or find
help and information online at www.beko.co.uk.
Explanation of symbols used throughout this User Manual
C
- The terminal in the plug is marked with the symbol.
-Important information or useful usage tips.
-Symbol for waste electrical and electronic equipment.
-Some installation steps in furniture are marked with the symbol
of attention.
WARNING!
In order to ensure a normal operation of your refrigerating appliance, which uses
a completely environmentally friendly refrigerant the R600a (flammable only
under certain conditions) you must observe the following rules:
•
•
•
•
Do not hinder the free circulation of the air around the appliance.
Do not use mechanical devices in order to accelerate the defrosting,
others than the ones recommended by the manufacturer.
Do not destroy the refrigerating circuit.
Do not use electric appliances inside the food keeping compartment, other
than those that might have been recommended by the manufacturer.
EN
3
CONTENTS
1 Your refrigerator 4
2 Warnings 5
Electrical requirements .......................6
Warning! This appliance must be
earthed ..............................................6
Energy saving tips .............................7
Compliance with WEEE Directive and
Disposing of the Waste Product: .......7
Compliance with RoHS directive: .......7
Package information ..........................7
3 Installation 8
Disposing of the packaging ...............8
Disposing of your old refrigerator .......8
Placing and Installation ......................8
Installation instructions .......................9
Transportation instructions ...................8
Replacing the interior light bulb...........9
Reversing the door ..........................13
4 Before operating 14
Final Check .....................................14
5 Operating the product 15
Control Panel .................................. 15
Suggested arrangement of food in the
appliance .........................................16
Problem solving .............................. 18
6 Maintenance and
cleaning 17
7 Do’s and Don’ts 18
Defrosting ........................................ 15
Standard guarantee terms and
conditions......................................19
How to obtain service..................21
Built-in appliances guarantee
terms and conditions....................20
EN
4
1 Your refrigerator
C Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in
the product you have purchased, then it is valid for other models.
1. Control Panel
2. Interior light
3.Movable shelves
4.Wine rack
5.Vegetable drawers
6. Defrost water collection channel -
drain tube
7. Crisper cover
8. Front feet
9. Adjustable door shelves
10. Bottle shelf
Congratulations on your choice of a Beko quality Appliance which has been designed
to give you service for many years.
3
2
9
9
9
9
10
1
4
3
3
3
3
6
5
5
7
8
EN
5
2 Warnings
• Do not connect your appliance to the
electricity supply until all packing and
transit protectors have been
removed.
• If transported horizontally leave
to stand upright for at least 4
hours before switching on to allow
compressor oil to settle.
• If you are discarding an old
refrigerator with a lock or latch fitted
to the door, disable the lock/latch,
ensure that it is left in a safe condition
to prevent the entrapment of young
children.
• This fridge must only be used for its
intended purpose i.e. the storing and
cooling of edible foodstuff.
• Do not dispose of the appliance
on a fire. At Beko, the care and
protection of our environment is an
ongoing commitment. This appliance
which is among the latest range
introduced is particularly environment
friendly. Your appliance contains non
CFC / HFC natural substances in the
cooling system (called R600a) and in
the insulation (called cyclopentane)
which are potentially flammable if
exposed to fire. Therefore, take care
not to damage, the cooling circuit /
pipes of the appliance in
transportation and in use. In case of
damage do not expose the appliance
to fire or potential ignition source and
immediately ventilate the room where
the appliance is situated.
• We suggest you contact your local
authority for disposal information and
facilities available.
• See 'Installation instructions' on page
9 for information on suitable location.
• To obtain the best possible
performance and trouble free
operation from your appliance it is
very important to carefully read these
instructions.
• On delivery, check to make sure that
the product is not damaged and that
all the parts and accessories are in
perfect condition.
• Ensure that the plug remains readily
accessible. Do not use multiple
adapter or extension cable.
• Failure to observe these instructions
may invalidate your right to free
service during the guarantee period.
• Keep ventilation openings, in the
appliance enclosure or in the built-in
structure, clear of obstruction.
• Do not use mechanical devices
or other means to accelerate the
defrosting process, other than those
recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Do not use electrical appliances
inside the food storage
compartments of the appliance,
unless they are of the type
recommended by the manufacturer.
• We suggest you keep these
instructions in a safe place for easy
reference.
• This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way
and understand the hazards
involved. Children shall not play with
the appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
• Children should be supervised to
ensure that they do not play with the
appliance.
EN
6
Important! Fitting A Different Plug
As the colours of the wires in the mains
lead of this appliance may not
correspond with the coloured markings
identifying the terminals in your plug
proceed as follows: (see diagram).
1. Connect the green-yellow or green
(Earth) wire to the terminal in the plug
marked ‘E’ or with the symbol or
coloured green and yellow or green.
2. Connect the blue (Neutral) wire to
the terminal in the plug marked ‘N’ or
coloured black.
3. Connect the brown (Live) wire to the
terminal in the plug marked ‘L’ or
coloured red.
With alternative plugs a 13 A fuse must
be fitted either in the plug or adaptor
or in the main fuse box. If in doubt
contact a qualified electrician.
Electrical requirements
Before you insert the plug into the wall
socket make sure that the voltage and
the frequency shown on the rating
plate inside the appliance corresponds
to your electricity supply.
Rating label is on the left hand side of
fridge inner liner.
We recommend that this appliance be
connected to the mains supply via a
suitable switched and fused socket.
The appliance must be positioned so
that the plug is accessible.
WARNING: When positioning the
appliance ensure the supply cord is not
trapped or damaged.
Should the mains lead of the appliance
become damaged or should it need
replacing at any time, it must be
replaced by a special purpose made
mains lead which can only be obtained
from a Beko authorised service agent.
Warning! This appliance
must be earthed
If the fitted moulded plug is not
suitable for your socket, then the plug
should be cut off and an appropriate
plug fitted. Destroy the old plug which
is cut off as a plug with bared cord
could cause a shock hazard if inserted
into a socket elsewhere in the house.
The moulded plug on this appliance
incorporates a 13 A fuse. Should
the fuse need to be replaced an
ASTABEAB approved BS 1362 fuse of
the same rating must be used. Do not
forget to refit the fuse cover. In the
event of losing the fuse cover the plug
must not be used until a replacement
fuse cover has been fitted.
Colour of the replacement fuse cover
must be the same colour as that
visible on the pin face of the plug.
Fuse covers are available from any
good electrical store.
FITTED WITH
BS 1362 13A FUSE ALWAYS
FIT BS 1362 REPLACEMENT
CARTRIDGE FUSE
GREEN &
YELLOW
OR
GREEN
N
BLUE
OR
BLACK
L
BROWN
OR
RED
22 mm.
6 mm.
6 mm.
6 mm. 32 mm.
12 mm.
FUSE
CORD GRIP
EN
7
Energy saving tips
1. Ensure your appliance is installed in a
well ventilated area.
2. Ensure the time between buying
chilled/frozen food and placing them
in your appliance is kept at minimum,
particularly in summer. We
recommend you use a cool bag or a
special carrier bag to carry perishable
food.
3. Do not leave the door (s) of your
appliance open longer than
necessary and ensure they are
closed properly after each opening.
4. Defrost frozen food in the fridge, so
that frozen food acts as an ice pack
to assist cooling in the fridge.
Compliance with WEEE
Directive and Disposing of
the Waste Product:
This product complies with EU WEEE
Directive (2012/19/EU). This
product bears a
classification symbol for
waste electrical and
electronic equipment
(WEEE). This product has
been manufactured with
high quality parts and materials which
can be reused and are suitable for
recycling. Do not dispose of the waste
product with normal domestic and other
wastes at the end of its service life.
Take it to the collection center for the
recycling of electrical and electronic
equipment. Please consult your local
authorities to learn about these
collection centers.
Compliance with RoHS
directive:
The product you have purchased
complies with EU RoHS Directive
(2011/65/EU). It does not contain
harmful and prohibited materials
specified in the Directive.
Package information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging
material collection points designated
by the local authorities.
EN
8
3 Installation
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose of them by
classifying them in accordance
with the waste instructions. Do not
dispose of them along with the normal
household waste.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
refrigerator
Dispose of your old refrigerator without
giving any harm to the environment.
• You may consult your authorised
dealer or waste collection center of
your municipality about the disposal of
your refrigerator.
Before disposing of your refrigerator,
cut off the electric plug and, if there are
any locks on the door, make them
inoperable in order to protect children
against any danger.
Placing and Installation
1.
Install your refrigerator to a place that
allows ease of use.
2.
Keep your refrigerator away from heat
sources, humid places and direct
sunlight.
3.
There must be appropriate air
ventilation around your refrigerator in
order to achieve an efficient operation.
4.
Place your refrigerator on an even
floor surface to prevent jolts.
5.
Do not keep your refrigerator in
ambient temperatures under 10°C.
WARNING: Do not locate extension
sockets or charging transformers/
power supplies or Lithium-Iron battery
operated products adjacent to the
compressor as they could overheat.
Transportation instructions
1. The appliance should be transported
only in a vertical upright position. The
packing as supplied must be intact
during transportation.
2. If during the course of transport the
appliance has to be transported
horizontally, it must only be laid on its
right hand side when standing in the
front of the appliance. After bringing
it to upright position, it must not be
operated for at least 4 hours to allow the
system to settle.
3.
Failure to comply with the above
instructions could result in damage
occurring to the appliance. The
manufacturer will not be held responsible
if these instructions are disregarded.
4. The appliance must be protected
against rain, moisture and other
atmospheric influences.
5.
When positioning your appliance take
care not to damage your flooring, pipes,
wall coverings etc. Do not move the
appliance by pulling by the door or handle.
6. Empty any water in the drain
tray before moving. See section
‘Defrosting’ and ‘Maintenance and
cleaning’ for further information.
7. Make sure that the defrost water pipe
at the back of the product is fixed to the
plastic evaporating pan on the top of the
compressor, to avoid defrost water
spillage on the floor.
IMPORTANT: Care must be taken while
cleaning / carrying the appliance to
avoid touching the bottom of the
condenser metal wires at the back of
the appliance as you might injure your
fingers and hands.
Do not attempt to sit or stand on top of
your appliance as it is not designed for
such use. You could injure yourself or
damage the appliance.
EN
9
Installation instructions
1. The space in the room where the
appliance is installed must not be
smaller than 10 cubic metres.
If the ambient temperature is below
0°C, the food in the fridge will freeze.
So, we recommend you don’t use the
appliance in such low ambient
conditions.
2. Do not place the appliance near
cookers, radiators or in direct sunlight
as this will cause your appliance to
work harder. If installed next to a
source of heat or freezer, maintain the
following minimum side clearances:
From Cookers 50 mm (2”)
From Radiators 300 mm (12”)
From Freezers
25 mm (1”)
3. Refer to "Maintenance and
cleaning" section to prepare your
appliance for use.
4. A special receptacle is supplied to
store the mains plug during transit.
The receptacle is fixed at the back
of the cabinet, on the side of the
compressor (see diagram). Gently
remove the plug from the receptacle.
Never pull the mains cord, you may
damage the appliance. In the case of
transportation, ensure you locate the
plug in the receptacle provided to
avoid transit damage.
IMPORTANT: Make sure that mains
cable is not caught under the appliance
during and after carrying / moving the
appliance, to avoid the mains cable
becoming cut or damaged.
Do not allow children to play with the
appliance or tamper with the controls.
Beko plc declines to accept any
liability should the instructions not be
followed.
Replacing the interior light
bulb
To change the Bulb/LED used for
illumination of your refrigerator, call
your Authorised Service. The lamp(s)
used in this appliance is not suitable
for household room illumination. The
intended purpose of this lamp is to
assist the user to place foodstuffs in
the refrigerator in a safe and
comfortable way. The lamps used in
this appliance have to withstand
extreme physical conditions such as
temperatures below -20°C.
(only chest and upright freezer)
C
Autres manuels pour BLSD3577
1
Table des matières
Autres manuels Beko Accessoires
