LARGE-DIAPHRAGM STUDIO CONDENSER MICROPHONE C-3

User’s Manual

Version 1.0 March 2006

LARGE-DIAPHRAGM STUDIO CONDENSER MICROPHONE C-3

1. SAFETY PRECAUTIONS

Please read all safety precautions and operating instructions

before attempting to operate the unit. Keep all safety precautions

and operating instructions for future reference.

Water and moisture:

Condenser microphones are extremely moisture-sensitive. Never

use your microphone in close proximity to water (e.g. bath tubs,

wash basins, sinks, washing machines, pools, etc.).

Power supply:

Always use the power supply specified in the operating

instructions.

Damage:

Take care not to drop your microphone as this can lead to severe

damage. BEHRINGER assumes no liability for any damage caused

by the user.

Service and care:

After each use, wipe the microphone down with a soft cloth and

place it back into its protective casing (included with the

microphone).

Caution:

Never dismount the screen holding the capsule, as this can

damage the microphone! Never try to modify the printed circuit

board inside your C-3! This can lead to microphone damage that

cannot be repaired. Any such attempt will void the warranty.

2. POWER SUPPLY

Your condenser mic C-3 needs a phantom power supply

(+48 V). If your C-3 is connected to a microphone preamp and

supplied with phantom power, the LED on the microphone lights

up. BEHRINGER assumes no liability for any damage caused by

a defective phantom power supply. Always mute the sound

reinforcement system before you switch on the phantom power

supply.

3. DIRECTIVITY

Your C-3 is a large-diaphragm microphone featuring a double mem-

brane. This allows you to choose between three different pickup

patterns - cardioid, omnidirectional and figure eight. Make your se-

lection using the switch located at the back of your microphone.

3. DIRECTIVITY

LARGE-DIAPHRAGM STUDIO CONDENSER MICROPHONE C-3

3.1 Cardioid

Microphones with this polar pattern (switch position: middle, )

are most sensitive to sound coming from in front of the

microphone, and also to a lesser extent from the sides. Sound

coming from behind the microphone will be greatly attenuated.

This makes the cardioid polar pattern most suitable for recording

individual instruments or vocals within a group.

3.2 Figure Eight

Microphones featuring the figure eight polar pattern (switch

position: left, ) are most sensitive to sound coming from either

directly in front of or directly behind the microphone. Sound

coming from either side or above / below is greatly attenuated.

This polar pattern is perfectly suited as a reporter mic for two

speakers. This pattern can also allow you to create a natural

reverb or delay effect. This is achieved by placing the

microphone between the sound source and a wall. The direct

sound reaches the „front“ membrane first, the reflected sound

reaches the „rear“ membrane a short time later. You can adjust

the delay / reverb time by changing the distance from the mic to

the wall.

3.3 Omnidirectional

If you use the C-3 with the omnidirectional polar pattern selected

(switch position: right, ), the microphone is equally susceptible

to sound coming from all directions. This polar characteristic is

particularly well suited to sessions in which a natural sounding

recording is sought, or when several sound sources surround

the C-3.

4. LOW CUT-FILTER AND SIGNAL LEVEL ATTENUATION

The low cut filter is activated via the left switch located at the

front of your C-3 (switch position: left, ). Disruptive, low-

frequency sounds such as subsonic noise, snapping and wind

sounds can be filtered out. When the low cut filter is active,

when recording a voice from a close distance, you get an almost

entirely linear frequency response.

The switch located on the front right side of your C-3 activates

the -10 dB signal level attenuation (switch position: right, -10 dB).

This function is particularly recommended when recording im-

pulse sound sources with high sound pressure (e.g. a bass

drum).

4. LOW CUT-FILTER AND SIGNAL LEVEL ATTENUATION

LARGE-DIAPHRAGM STUDIO CONDENSER MICROPHONE C-3

5. MICROPHONE INSTALLATION

A holder is screwed onto your micro-

phone, allowing you to attach it to mic

stands with a 3/8" or 5/8" thread. An

adapter has been included. First

dismantle the microphone from the

stand mount adapter by detaching

the fine-thread shoulder screw at

the bottom end of the microphone. Fas-

ten the adapter onto the microphone

stand, place the microphone into it and

tighten the screw again.

Basically, the microphone in the stand

mount adapter should stand upright and

face the sound source at a right angle.

The angle of the microphone to the

sound source influences the sound of

the recording; therefore, experiment

with different positions until you achieve

the desired sound. To this end, you can rotate the mic in the

stand mount adapter by loosening the screw somewhat and

tightening it again.

If necessary, you can bend the microphone out of its vertical

position by using the hinge on the microphone stand.

Please make sure to handle the microphone shaft

with attention and care to avoid damaging the

screw thread. In no situation should you ever

apply excessive force.

Of course, you can detach the C-3 from the stand mount adapter

and attach it to a commercially available suspension mount.

6. AUDIO CONNECTION

Use a balanced XLR microphone cable with the following pin

assignment: pin 1 = shielding; pin 2 = +; pin 3 = -. Since your C-3

features gold-plated contact points throughout, we recommend

that you use only microphone cables with gold-plated connectors.

6. AUDIO CONNECTION

Fig. 5.1: Attaching

the microphone stand

LARGE-DIAPHRAGM STUDIO CONDENSER MICROPHONE C-3

7. LEVEL SETTING/ADJUSTING THE BASIC SOUND

Adjust the gain control in the microphone channel of your mixing

console so that the peak LED lights up only occasionally or never

at all. The EQ controls in the microphone channel should be set to

mid-travel position to start with; low cut filter and signal level

attenunation should be switched off. To get the sound you want,

try changing the mic position relative to the sound source or

even move the microphone around in the recording room of your

studio. Adjusting the angle at which walls face the sound source

can also be helpful. Only when the desired basic sound has

been achieved, should you start to use equalizers and signal

processors, if any at all (remember: less is often more!)

Due to the extremely linear frequency response and the high

sonic resolution of your C-3, there is no need for high-frequency

“EQing” that can heavily influence the signal and unnecessarily

increase the noise level. The C-3 provides that much-desired

transparency which often gets lost during recording and mixing.

8. WARRANTY

The currently applicable warranty conditions can

be found on our website at http://

www.behringer.com; alternatively via fax +49 2154

9206 4199 or telephone +49 2154 9206 4166.

9. SPECIFICATIONS

Transducer type: condenser, 16 mm

Polar pattern: cardioid, figure 8, omni

Connection: gold-plated balanced

XLR connector

Open circuit sensitivity: -40 dBV/pa (10 mV/pa)

Frequency response: 40 Hz - 18 kHz

Max. SPL (<0,5% THD @ 1 kHz): 142 dB

Equivalent noise level: 23 dBA (IEC 651)

Dynamic range: 119 dB

Rated Impedance 350 Ω

Supply voltage: +48 V

Supply current: 7.0 mA

Dimensions: ∅ shaft: 54 mm,

length: 180 mm

Weight: approx. 0.45 kg

9. SPECIFICATIONS

LARGE-DIAPHRAGM STUDIO CONDENSER MICROPHONE C-3

0º

180º

45º 45º

135º 135º

90º 90º

Super Cardioid

Figure 8

Omni

Polar pattern

-10

-20

20 50 100 200 500 1000 2000 5000 10000 20000 Hz

Cardioid

Figure 3

Omni

Low Cut

-10dB

Frequency response

BEHRINGER is constantly striving to maintain the highest professional standards. As a result

of these efforts, modifications may be made from time to time to existing products without prior

notice. Specifications and appearance may differ from those listed or illustrated.

Technical specifications and appearance subject to change without notice. The information

contained herein is correct at the time of printing. The names of companies, institutions or

publications pictured or mentioned and their respective logos are registered trademarks of

their respective owners. Their use neither constitutes a claim of the trademarks by BEHRINGER®

nor affiliation of the trademark owners with BEHRINGER®. BEHRINGER®accepts no liability

for any loss which may be suffered by any person who relies either wholly or in part upon any

description, photograph or statement contained herein. Colours and specification may vary

slightly from product. Products are sold through our authorised dealers only. Distributors and

dealers are not agents of BEHRINGER®and have absolutely no authority to bind BEHRINGER®

by any express or implied undertaking or representation. No part of this manual may be reproduced

or transmitted in any form or by any means, electronic or mechanical, including photocopying

and recording of any kind, for any purpose, without the express written permission of BEHRINGER

Spezielle Studiotechnik GmbH. BEHRINGER®is a registered trademark.

BEHRINGER Spezielle Studiotechnik GmbH,

Hanns-Martin-Schleyer-Str. 36-38,

47877 Willich-Münchheide II, Germany.

Tel. +49 2154 9206 0, Fax +49 2154 9206 4903

9. SPECIFICATIONS
