Behringer MOTOR 49 Manuel utilisateur

Page 1

HOW TO

BEHRINGER MOTÖR61/49 Keyboards

How to use “MC mode” in your DAW

General Information:

Your MOTÖR Keyboard’s MC mode supports concurrent use as a MIDI performance keyboard and

remote controlling any MC compatible (Mackie Control) DAW (digital audio workstation).

MOTÖR achieves this by offering two separate USB MIDI devices to the computer’s OS.

The following guide explains how this combined MC mode is typically used.

Please note that some of the button labels, printed for standard MIDI keyboard use, deviate from their

function in MC mode.

In MC mode:

SUSTAIN

EXPR

Red area: Standard MIDI operation (MIDI port 1), “Motör49/61 Keyboard”

Green area: Mackie Control protocol (MIDI port 2), “MIDI In 2 (Motör49/61 Keyboard)” and

“MIDI Out 2 (Motör49/61 Keyboard)”

F DER B NKS

TR CK

SEND

P N/SURR

PLUG

ENCODER

B NKS

INSTRUM

< B NK

B NK >

ssignment of ENCODERS E1 – E8

Fader Bank Select for F DERS F1

–

Page 2

HOW TO

It is important to understand 4 steps for using the MC mode:

first switch the Operation Mode on MOTÖR to “MC” (with USB connected to your PC)

your DAW will show two separate MIDI devices (ports) related to MOTÖR (depends on your DAW)

the MC communication will always use the 2nd port, i.e. “MIDI In 2 (Motör Keyboard)” and “MIDI Out 2

(Motör Keyboard)”

when using the MOTÖR in MC mode, it is not recommended to toggle between MIDI and MC mode

when you switch from song-mixing to instrument-playing and vice versa. Please keep MC mode active,

which will transmit (keyboard) performance and MC commands concurrently.

Installation under

Mac OS X (El Capitan 10.11.3)

 Ableton Live 9 (9.6.1)

How to set-up bleton LIVE (English version):

1. Power on your MOTÖR keyboard

2. Connect it to your Mac via USB cable

3. Press the MC button on your MOTÖR keyboard

4. Start bleton LIVE

Page 3

HOW TO

5. Select Live > Preferences…

6. Go to the MIDI tab > select as Control Surface MackieControl > select as Input MOTÖR49

Keyboard ( nschluss 2) (Port 2)

Page 4

HOW TO

7. Now select as Output MOTÖR49 Keyboard ( nschluss 2) (Port 2) > and switch all MOTÖR related

MIDI Ports On

8. Please note that MIDI tracks which have no instrument assigned will make no use of the faders in

MC mode. If you move a fader up on your MOTÖR, it will fall down. If you insert an instrument, a

virtual fader will appear on the screen which can get controlled from the MOTÖR hardware:

Page 5

HOW TO

Example above:

MIDI track 1 has “MkI4 Simple Piano” assigned > virtual fader on the screen visible

> motor fader will work in MC mode

(same operation as for audio tracks)

MIDI track 4 has no instrument assigned > only “MIDI meter” visible

> motor fader will not work in MC mode

(if moving up fader 4 on the MOTÖR, it will fall back to its initial position)

Now you can control your DAW as explained on page 1 (General Information).

One final note to the motor fader control:

For best operation with the motor faders we recommend to move not more than 4 faders

simultaneously and to consider that you first have to touch the fader before you start moving. More

details can be found in a separate How To document about the motor faders operation.
