Behringer U-CONTROL UCA200 Manuel utilisateur
Operating Manual
Version 1.0 January 2006
U-CONTROL UCA200
2
U-CONTROL UCA200
CAUTION: To reduce the risk of electric
shock, do not remove the top
cover (or the rear section). No
user serviceable parts inside;
refer servicing to qualified
personnel.
WARNING: To reduce the risk of fire or
electric shock, do not expose
this appliance to rain and
moisture. The apparatus shall
not be exposed to dripping or
splashing and no objects filled
with liquids, such as vases, shall
be placed on the apparatus.
This symbol, wherever it appears,
alerts you to the presence of unin-
sulated dangerous voltage inside the
enclosure—voltage that may be
sufficient to constitute a risk of shock.
This symbol, wherever it appears,
alerts you to important operating and
maintenanceinstructionsintheaccom-
panying literature. Please read the
manual.
IMPORTANT SAFETY INSTRUCTIONS
DEUTSCH
3
U-CONTROL UCA200
DETAILEDSAFETYINSTRUCTIONS:
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
8) Only use attachments/accessories specified by the manufacturer.
9) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in
any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
10) CAUTION - These service instructions are for use by qualified service personnel only. To reduce the risk of
electric shock do not perform any servicing other than that contained in the operation instructions unless you are
qualified to do so.
4
U-CONTROL UCA200
UCA200UCA200
UCA200UCA200
UCA200
VUltra-flexible audio interface connects your instruments, mixer etc. with your computer for
recording and playback
VHigh-resolution 48 kHz converters for high-end audio quality
VWorks with your PC or Mac–no setup or drivers required. Free audio recording and editing
software downloadable at www.behringer.com
VPowered via USB bus–no external power supply needed
VHigh-quality components and exceptionally rugged construction ensure long life
VConceivedand designedby BEHRINGERGermany
All Trademarks mentioned belong to their respective owners and are not affiliated with BEHRINGER®
Ultra low-latency 2 In/2 Out USB/Audio Interface
U-CONTROL
DEUTSCH
5
U-CONTROL UCA200
FOREWORD
Dear Customer,
welcome to the team of U-CONTROL users, and thank you very much
for expressing your confidence in us by purchasing the UCA200. It is
one of my most pleasant tasks to write this letter to you, because it is the
culmination of many months of hard work delivered by our engineering
team to reach a very ambitious goal: to develop a first rate unit, which is
flexible enough to be used mobile as well as within studio setups.
The task to design our new UCA200 certainly meant a great deal of
responsibility. You, the discerning user and musician, were the focus
of our entire development efforts. It also meant a lot of work and night
shifts to accomplish this goal. But it was fun, too. Developing a pro-
duct usually brings a lot of people together, and what a great feeling
it is when everybody who participated in such a project can be proud
of what we’ve achieved.
It is our philosophy to share our joy with you, because you are the
most important member of the BEHRINGER family. With your highly competent suggestions for new
products you’ve greatly contributed to shaping our company and making it successful. In return, we
guarantee you uncompromising quality as well as excellent technical and audio properties at an
extremely favorable price. All of this will enable you to fully unfold your creativity without being
hampered by budget constraints.
We are often asked how we can make it to produce such high-grade devices at such unbelievably
low prices. The answer is quite simple: it’s you, our customers! Many satisfied customers means
large sales volumes enabling us to get better conditions of purchase for components, etc. Isn’t it only
fair to pass this benefit back to you? Because we know that your success is our success, too!
6
U-CONTROL UCA200
I would like to thank all people whose help on U-CONTROL UCA200 has made it all possible.
Everybody has made very personal contributions, starting from the designers of the unit via the
many staff members in our company to you, the user of BEHRINGER products.
My friends, it’s been worth the trouble!
Thank you very much,
UliBehringer
DEUTSCH
7
U-CONTROL UCA200
INHALTSVERZEICHNIS
1.INTRODUCTION ........................................................................................... 8
1.1 Before you started .............................................................................................................. 9
1.1.1 Shipment ..................................................................................................................... 9
1.1.2 Initial operation ............................................................................................................ 9
1.1.3 Online registration .................................................................................................... 10
2.SYSTEM REQUIREMENTS......................................................................... 11
2.1 Hardware connection .........................................................................................................11
3.OPERATING ELEMENTSANDCONNECTIONS ......................................... 12
3.1 Top view ............................................................................................................................. 12
3.2 Connections........................................................................................................................ 13
4. WORKING WITH THE UCA200 .................................................................. 14
4.1 Application example............................................................................................................ 14
5.AUDIO CONNECTIONS .............................................................................. 16
5.1 Wiring .................................................................................................................................. 16
6. SPECIFICATIONS ...................................................................................... 17
7.WARRANTY ............................................................................................... 19
8
U-CONTROL UCA200
1. INTRODUCTION
Welcome to the family of U-CONTROL users and thank you for expressing your confidence in
BEHRINGER products by purchasing the UCA200. With the UCA200 you have purchased a high-
performance audio interface that includes a USB connector. It is thus an ideal sound card for your
laptop computer or an essential recording/playback component for studio environments that invol-
ve desktop computers.
The UCA200 is PC and Mac-compatible. Therefore, no separate installation procedure is required,
while the operating system drivers ensure an extremely short latency.
Thanks to its robust construction and compact dimensions, the UCA200 is also ideal for traveling.
2 inputs and outputs give you total connecting flexibility to mixing consoles and loudspeakers.
Power is supplied to the unit via the USB interface. The LED gives you a quick check that the
UCA200 is properly connected to the computer. The UCA200 is the ideal extra for every computer
musician.
1.INTRODUCTION
DEUTSCH
9
U-CONTROL UCA200
1.INTRODUCTION
1.1 Before you started
1.1.1 Shipment
Your UCA200 was carefully packed at the assembly plant to assure secure transport. Should the
condition of the cardboard box suggest that damage may have taken place, please inspect the unit
immediately and look for physical indications of damage.
Damaged equipment should NEVER be sent directly to us. Please inform the
dealer from whom you acquired the unit immediately as well as the transporta-
tion company from which you took delivery. Otherwise, all claims for replace-
ment/repair may be rendered invalid.
Please always use the original packaging to avoid damage due to storage or
shipping.
Never let unsupervised children play with the equipment or with its packaging.
Please dispose of all packaging materials in an environmentally friendly fashion.
1.1.2 Initial operation
Please make sure the unit is provided with sufficient ventilation, and never place the UCA200 on top
of an amplifier or in the vicinity of a heater to avoid the risk of overheating.
The current supply is made via the USB connecting cable, so that there is no external power supply
unit required. All required safety precautions have been adhered to.
10
U-CONTROL UCA200
1.INTRODUCTION
1.1.3 Online registration
Please do remember to register your new BEHRINGER equipment right after your purchase by
visiting www.behringer.com (alternatively www.behringer.de) and kindly read the terms and con-
ditions of our warranty carefully.
Should your BEHRINGER product malfunction, our goal is to have it repaired as quickly as possible.
To arrange for warranty service, please contact the retailer from whom the equipment was pur-
chased. Should your BEHRINGER dealer not be located in your vicinity, you may directly contact one
of our subsidiaries. Corresponding contact information is included in the original equipment packag-
ing (Global Contact Information/European Contact Information). Should your country not be listed,
please contact the distributor nearest you. A list of distributors can be found in the support area of
our website (www.behringer.com/support).
Registering your purchase and equipment with us helps us process your repair claims quicker and
more efficiently.
Thank you for your cooperation!
