Installation and Operating instructions for

Control Cabinet Industrial PC

C6640, C6650

Version: 1.1

Date: 2010-04-08

Table of contents

General instructions 3

Notes on the Documentation 3

Liability Conditions 3

Description of safety symbols 3

Basic safety measures 4

Operator's obligation to exercise diligence 5

Operator requirements 5

Product Description 6

Appropriate Use 6

Opening the Housing 6

Configuration with 100-240 VAC Full Range Power Supply 8

Interfaces 9

PS/2 connections 9

Serial interface 9

Parallel interface 9

VGA connection 9

USB interfaces 9

Network connection 10/100MBit 9

Network connection 1Gbit (optional) 9

Sound-On-Board 9

Additional plug-in cards (optional) 9

Installation Instructions 10

Transport and Unpacking 10

Transport 10

Unpacking 10

Installation of the PC in the control cabinet 11

Earthing measures 11

Power Supply Connection with 100-240 VAC power supply unit 12

Mains Socket 12

Power supply cords 12

Power Supply Connection with 24 VDC power supply unit (optional) 13

Beckhoff power supply technology 13

Electrical Data 14

Pin assignment of the connectors 14

Pin assignment power supply 14

Pin assignment external wiring 15

Fitting the Cables 15

Fitting the connector 15

Connecting Power Supply 16

Cable Cross Sections 16

Configuration for shutting down the PC 16

PC_ON and Power Status functions 16

UPS output 16

UPS output function 16

Wiring diagram 17

Connecting devices 18

Connecting cables 18

Check voltage rating and connect. 18

Operating Instructions 19

Switching the Industrial PC on and off 19

First switching on and driver installation 19

Servicing and Maintenance 20

Cleaning the Industrial PC 20

Replacing the battery on the motherboard 20

Replacing the fan 20

Servicing 21

C6640, C6650 1

Table of contents

Shutting down 21

Disposal 21

UPS Software Components (optional) 21

Installation on the PC 21

Help files 21

Troubleshooting 22

Fault correction 22

Beckhoff Support & Service 23

Beckhoff branches and partner companies 23

Beckhoff Headquarters 23

Beckhoff Support 23

Beckhoff Service 23

Assembly dimensions 24

C6640, Configuration with 100-240 VAC Power Supply 24

C6640, Configuration with 24 VDC-Power Supply (optional) 25

C6650, Configuration with 100-240 VAC Power Supply 26

C6650, Configuration with 24 VDC-Power Supply (optional) 27

Appendix 28

Technical data 28

Approvals 28

FCC: Federal Communications Commission 28

Radio Frequency Interference Statement 28

FCC: Canadian Notice 28

2C6640, C6650

General instructions

Notes on the Documentation

This description is only intended for the use of trained specialists in control

and automation engineering who are familiar with the applicable national

standards. It is essential that the following notes and explanations are

followed when installing and commissioning these components.

Liability Conditions

The responsible staff must ensure that the application or use of the

products described satisfy all the requirements for safety, including all the

relevant laws, regulations, guidelines and standards.

The documentation has been prepared with care. The products described

are, however, constantly under development. For that reason the

documentation is not in every case checked for consistency with

performance data, standards or other characteristics. None of the

statements of this manual represents a guarantee (Garantie) in the

meaning of § 443 BGB of the German Civil Code or a statement about the

contractually expected fitness for a particular purpose in the meaning of

§ 434 par. 1 sentence 1 BGB. In the event that it contains technical or

editorial errors, we retain the right to make alterations at any time and

without warning. No claims for the modification of products that have

already been supplied may be made on the basis of the data, diagrams

and descriptions in this documentation.

this publication, whether in whole or in part, without the written permission

of Beckhoff Automation GmbH, is forbidden.

Description of safety symbols

The following safety symbols are used in this operating manual. They are

intended to alert the reader to the associated safety instructions.

Danger

This symbol is intended to highlight risks for the life or health of personnel.

Warning

This symbol is intended to highlight risks for equipment, materials or the

environment.

Note

This symbol indicates information that contributes to better understanding.

C6640, C6650 3

General instructions

Basic safety measures

Only switch the PC off after

closing the software

Before the Industrial PC is switched off, software that is running must

be properly closed.

Otherwise it is possible that data on the hard disk is lost. Please read the

section on Switching the Industrial PC on and off.

Warning

Switch off all parts of the equipment, then uncouple the fieldbus!

Before opening the housing of the PC, and whenever the PC is being used

for purposes other than plant control, such as during functional tests

following repair, all parts of the equipment must first be switched off, after

which the Industrial PC can be uncoupled from the plant.

Pulling out the fieldbus connection plug uncouples the PC (optional).

Items of equipment that have been switched off must be secured against

being switched on again.

The Industrial PC’s power supply unit must be supplied with

100 VAC - 240 VAC or 24 VDC (optional).

Danger

Do not open the power supply unit while voltage is applied!

The supply voltage must be switched off before the power supply unit

housing is opened.

Warning

Do not exchange any parts when under power!

When components are being fitted or removed, the supply voltage must be

switched off.

Fitting work on the Industrial PC can result in damage:

• If metal objects such as screws or tools fall onto operating circuit

boards.

• If connecting cables internal to the PC are removed or inserted

during operation.

• If plug-in cards are removed or inserted when the PC is switched

on.

4C6640, C6650

General instructions

Operator's obligation to exercise diligence

The operator must ensure that

• the Industrial PC is only used for its intended use (see also

Product Description).

• the Industrial PC is in a sound condition and in working order

during operation.

• the operation manual is in good condition and complete, and

always available for reference at the location of the Industrial PC.

• the Industrial PC is operated, maintained and repaired only by

sufficiently qualified and authorised personnel.

• the personnel is instructed regularly about relevant occupational

safety and environmental protection aspects, and is familiar with

the operating manual and in particular the safety notes contained

herein.

• none of the safety and warning notes attached to the Industrial PC

are removed, and that all notes remain legible.

National regulations

depending on the machine

type

Depending on the type of machine and plant in which the Industrial PC is

being used, there will be national regulations for the control of such

machines and plant that the operator must observe. These regulations

cover, amongst other things, the intervals between inspections of the

controller.

The operator must initiate such inspections in good time.

Warning

Only trained persons may open the Industrial PC housing!

The operator is responsible for ensuring that only trained electrical staff

opens the housing of the Industrial PC.

Procedure in the event of a

fault

In the event of a fault in the Industrial PC, appropriate measures can be

determined with the aid of the list in the Fault correction section.

Operator requirements

Read the operating

instructions

Every user of the Industrial PC must have read these operating

instructions.

Software knowledge Every user must be familiar with any of the functions of the software

installed on the PC that he can reach.

C6640, C6650 5

Product Description

Appropriate Use

The C6640 and C6650 Industrial PCs are designed for mounting in control

cabinets for machine and plant engineering applications.

Opening the Housing

View of the C6650,

configuration with

100-240 VAC power supply

The housing cover is locked by a latch. After pressing the key (1) the cover

can be fold up a little in the region of the connectors.

Opening the housing

After folding up the cover as shown, it can be pulled out of the slides in

direction of the arrow.

unlock key (1)

6C6640, C6650

Product Description

Taking off the housing

cover

Now the housing cover can be taken off completely, so providing access to

the components.

The reassembly of the cover takes place in reverse order. Ensure that the

cover engages into the slides (2).

slides on both sides (2)

C6640, C6650 7

Product Description

Configuration with 100-240 VAC Full Range Power Supply

View of the C6650 with 100-240 VAC full range power supply.

Removing the card holder

After loosening the knurled screw the card holder can be lifted off

(see arrow).

Components of the PCs

Under the housing cover there is a 7 slot computer core with standard ATX

motherboard and different processor configuration.

he following configuration options of the motherboard are available:

Order option Intel®

Celeron®M

Intel®

Pentium M

Intel®

Core™ Duo

Intel®

Core™ 2 Duo

Intel®

Core™ 2 Quad

C6640-0000 1,5 GHz 1,8 GHz

C6640-0010 2,0 GHz 2,16 GHz

C6640-0020 2,53 GHz 2,26 GHz

C6650-0010 2,0 GHz 2,16 GHz

C6650-0020 2,53 GHz 2,26 GHz

The connections of the Industrial PC are located on top of the housing.

card holde

knurled scre

2 mobile racks for

3 ½“ serial-ATA HDD

(C6650 only) 3 ½“ serial-ATA HDD

(C6640 only)

position of the

CF card (optional)

fan

100-240 VAC full

range power supply

7-Slot-AT

motherboard

main switch

interfaces

8C6640, C6650

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Beckhoff PC industriel

Beckhoff

Beckhoff CX2000 Series Manuel utilisateur

Beckhoff

Beckhoff CX1000-0 SERIES Manuel de l'opérateur

Beckhoff

Beckhoff C6920 Manuel utilisateur

Beckhoff

Beckhoff C6250-0070 Manuel utilisateur

Beckhoff

Beckhoff MIC3110 Manuel utilisateur

Beckhoff

Beckhoff CX1010 Series Manuel de l'opérateur

Beckhoff

Beckhoff CX5130 Manuel utilisateur

Beckhoff

Beckhoff C6025 Manuel utilisateur

Beckhoff

Beckhoff C6240-1007 Manuel utilisateur

Beckhoff

Beckhoff C7015 Manuel utilisateur

Beckhoff

Beckhoff CP6500-2000-0100 Manuel utilisateur

Beckhoff

Beckhoff C6025 Manuel utilisateur

Beckhoff

Beckhoff C6250-0060 Manuel utilisateur

Beckhoff

Beckhoff CX9020 Manuel utilisateur

Beckhoff

Beckhoff C6905 Manuel utilisateur

Beckhoff

Beckhoff C6017-0010 Manuel utilisateur

Beckhoff

Beckhoff MIC3210 Manuel utilisateur

Beckhoff

Beckhoff CX20 0 Series Manuel utilisateur

Beckhoff

Beckhoff EP6224 Manuel de l'opérateur

Beckhoff

Beckhoff CPX37**-0010 Series Manuel utilisateur

Beckhoff

Beckhoff C6240 Manuel utilisateur

Beckhoff

Beckhoff C6915 Manuel utilisateur

Beckhoff

Beckhoff TF5200 Manuel utilisateur

Beckhoff

Beckhoff MIC3200 Manuel utilisateur

Manuels PC industriel populaires d'autres marques

Chipsee

Chipsee PPC-A72-101 Manuel utilisateur

Advantech

Advantech UNO-2184G Manuel utilisateur

MSI

MSI MS-9A76 Manuel utilisateur

Stackrack

Stackrack THOR200 Manuel utilisateur

Moxa Technologies

Moxa Technologies DA-682C Series Manuel utilisateur

Nodka

Nodka eBOX-3000-ETC Manuel utilisateur

Siemens

Siemens SIMATIC IPC627E Manuel utilisateur

MSI

MSI MS-9A89 Manuel utilisateur

Artila

Artila Matrix-516 Manuel utilisateur

Siemens

Siemens SIMATIC Rack PC 840 V2 Manuel utilisateur

Advantech

Advantech IPPC-6152A Manuel utilisateur

Dell

Dell Embedded Box PC 5000 Manuel utilisateur

IBASE Technology

IBASE Technology ASB200-918 Series Manuel utilisateur

Lenovo

Lenovo ThinkCentre M90q Manuel du propriétaire

IXXAT

IXXAT Econ 100 Manuel utilisateur

Kontron

Kontron KBox A-151-TGL Manuel utilisateur

AXIOMTEK

AXIOMTEK ICO500-518 Series Manuel utilisateur

JLT

JLT 1214N Manuel utilisateur
