DDL-TW1/Pro/Max Instruction ManualIntelligentAstronomical Telescope TW1Special Reminder:Do not observe the sun directly when not wearing "Bud ﬁlm sunglasses".Otherwise, the image sensor will burn out.Image Collector: WIFI Password: 12345678Please read this manual carefully before using the product!Please keep the instruction manual properly!

1.Product Overview2.Instructions For Use3.Installation Instructions4.Usage Procedure5.Accessories And Tools6.The Fault Is Rectiﬁed7. Trademarks And Legal Statements8.Overall Parameters0103040816171819Directory

Thank you for purchasing Intelligent Astronomical Telescope.Please read this manual carefully before use and keep it properly. Do not use the telescope withoutknowing how to use it In order to avoid unnecessary loss caused by wrong use.Description of telescope compositionDust coverThe primarymirrorholderLocking knobThe tripodThe focuser knobsPitch locking handleImageacquisition unitFind the star mirrorQuick releasescrew rod0101 Product Overview

02Description of telescope knobsStarﬁnder red dot left andright ﬁne-tuning knobStarﬁnder red dot up anddown ﬁne-tuning knobFine tune the red dotclockwise to the leftFine tune the red dotcounterclockwise to the rightFine tune the red dot clockwise upwardsbackwards Needle down to ﬁne tune the red dotStarﬁnder red dot switchBrightness trim knobFine tune the red dot to lightenreverse time clockwise Needleﬁne tuning red dots to darkencloseStar ﬁnder ﬁxed locking knobLock the star ﬁnder clockwisecounterclockwise Release the starﬁnderTilt lock handleLock pitch clockwiseloosen counterclockwise Open, can be bent through the grip Their operations.

03Lock knob in horizontal direction of gimbalFocal length adjustment knobClockwise lock for horizontal turncounterclockwise release.The rack at the bottom of the focusing seat is coatedwith grease. Do not touch it.02 Usage InstructionsProtect the lens of the objective lens and close the dust cover after use to avoid dust or foreign objects.Pay attention to protect the image collector. Please put the protective cover on after use to avoid dust or foreign matter.The telescope is suspended from the side, without heavy weight.When you do not use this product, please lock the various institutions of the gimbal to avoid the rotation of the astronomical telescope under the action of gravity.Please use in the environment of -10℃-45℃.This product is not waterproof, please avoid getting wet by any liquid.Keep away from ﬁre and heat sources.Please keep dust out of the lens.This product is a precision instrument, please avoid collision and violent vibration.In the case of low temperature, the available capacity of the battery will have diﬀerent degrees of decay, this is the characteristics of lithium batteries, is a normal phenomenon.In case of any abnormal phenomenon, please refer to the troubleshooting manual in time. In case of any unsolvable fault, please refer to the after-sales instructions.Disassembling telescopes without permission is not covered by the warranty policy and may result in irreparable damage.

After receiving the product, users are required to complete the overall assembly of the product bythemselves.Install the tripod1. Take out the tripod, loosen the fastening knob of the tripod, and pull out each leg to a uniform length.2. Flatten the folded structure in the middle of the tripod.Special WarningDo not directly observe the sun without properly installed Bader ﬁlm sunglasses. This will cause theimage collector chip to burn.Minors should be accompanied by an adult.Private modiﬁcation of the telescope is prohibited.When the telescope is not in use, please cover the dustproof cover to keep the machine clean.0403 Installation InstructionsProtect the lens of the objective lens and close the dust cover after use to avoid dust or foreign objects.Pay attention to protect the image collector. Please put the protective cover on after use to avoid dust or foreign matter.The telescope is suspended from the side, without heavy weight.When you do not use this product, please lock the various institutions of the gimbal to avoid the rotation of the astronomical telescope under the action of gravity.Please use in the environment of -10℃-45℃.This product is not waterproof, please avoid getting wet by any liquid.Keep away from ﬁre and heat sources.Please keep dust out of the lens.This product is a precision instrument, please avoid collision and violent vibration.In the case of low temperature, the available capacity of the battery will have diﬀerent degrees of decay, this is the characteristics of lithium batteries, is a normal phenomenon.In case of any abnormal phenomenon, please refer to the troubleshooting manual in time. In case of any unsolvable fault, please refer to the after-sales instructions.Disassembling telescopes without permission is not covered by the warranty policy and may result in irreparable damage.

05Install primary mirror barrel with tripod1. Prepare the main mirror, the whole head, the tripod, and the quick detachable rod, as shown below.2. Take out the main mirror and the cradle head, and align the three positioning pins of the cradle head base with the corresponding three holes on the tripod.3. Insert the quick disconnecting rod into the hole at the bottom of the tripod and tighten it clockwise. During the removal, it is necessary to hold the head of the gimbal and the mirror barrel by hand while loosening the quick detachable rod to prevent falling.HolderThe tripodQuick releasescrew rod

06Installation of image collector1. Get the image collector ready.2. Align the locking clip on the side of the image collector with the notch of the telescopic cylinder andinsert it, and then rotate the image collector to align the mark point to ﬁx and jam.② Insert the image collector① Take oﬀ the dust cover③ Rotate clockwise to thelocking positionInstall the star ﬁnder1. Prepare the star ﬁnder and align the star ﬁnder with the support port. Note the gap in the port.2. Tighten the ﬁxing knob of the star ﬁnder.Tip: Pay attention to the installation direction of the star ﬁnder.① Insert the star ﬁnder into the support interface② Tighten the ﬁxing knob of the star ﬁnderPay attention to thebayonet position

07Replace the battery1. Take out the star ﬁnder, place the battery in the interface where the star ﬁnder is inserted into the support, and remove the battery holder with your ﬁngers or tweezers.2. The star ﬁnder uses CR-2032 battery. When replacing the button battery, pay attention to the positive and negative terminals of the battery.Calibrate the red dot star ﬁnder1. Find a target more than 100 meters away with your naked eye.2. Adjust the primary mirror of the telescope to ﬁnd the target as a whole and move to the center of the ﬁeld of view.3. Turn on the star ﬁnder red dot switch and turn on the light.4. Find the red dot inside the circular observation mouth at the back of the star ﬁnder.5. Adjust the position of the red dot through the knob next to the star ﬁnder mirror. The whole assemblyis not ﬁnished until the red dot coincides with the target and the calibration is completed.Tip: After the observation, please turn oﬀ the red dot of the ﬁnderscope.①Take out the battery holder together(Be careful to loosen the locking knob)②Replace the battery,Pay attention tothe positive and negative electrodes③Put the battery holder back, payattention to the direction and position
